F E A T U R E S & F U N C T I O N S G U I D E w w w . k i a . c o m Consumer - Roadside Assistance 1-800-333-4KIA (4542) See Back Cover for Vehicle Maintenance Schedule Always check the Owner’s Manual for complete operating information and safety warnings.
Page 2
This Features & Functions Guide and the specific operational and safety information it provides is not a substitute for your Owner’s Manual. In the interest of your safety and that of your family, and to help you avoid risks that may result in death or serious injury, Kia reminds you to carefully read your Owner’s Manual in order to fully familiarize yourself with the important information it contains.
VIDEOS & QR CODES - SMARTPHONES, TABLETS AND COMPUTERS Kia provides a number of video resources at your disposal to assist you with becoming familiar with the features and functions QR CODE found in your Kia vehicle . You can access these resources by snapping the QR Codes with your smartphone/tablet (mobile One-Click Fuel Cap Video devices) or by visiting the following website: www.KuTechVideos.com/vg13/2015.
INSTRUMENT CLUSTER Instrument Cluster Overview Tachometer AFLS Turn Signal Indicators 9999 RANGE Speedometer x 1000 rpm 38.4 120 140 Engine Temperature Gauge km/h Long : Reset Next -14 °F 123456mi. Indicators & Warning Lights Gear Shift Position Indicator Odometer/Trip Computer/Tripmeter AUTO HOLD Fuel Gauge...
INSTRUMENT CLUSTER Indicators & Warning Lights REMINDER: Your vehicle’s instrument cluster & indicator AUTO light locations may differ from those in the illustrations . x 1000 rpm HOLD See your Owner’s Manual for more details . RANGE 44.4 QUICK TIP SET 27MPH For more information on the function of all : Next...
INSTRUMENT CLUSTER Tire Pressure Monitoring System (TPMS) QUICK TIPS QR CODES • Even with TPMS, tire pressure should be checked To view a video on your The TPMS indicator functions as both Low Tire Pressure Light and manually at least once a month . Only adjust tire mobile device, snap this TPMS Malfunction Indicator .
INSTRUMENT CLUSTER Trip Computer / Tripmeter LCD Instrument Cluster Modes* The Trip Computer is a driver information Press Mode/Select button to scroll through different LCD Instrument system that displays information related Cluster Modes: to driving on the display when the ENGINE RANGE (Buttons located START/STOP button is in the ON position .
INSTRUMENT CLUSTER User Settings Service Mode QR CODES To view a video on your To enter Service Mode, press the Mode/Select To enter the User Settings mobile device, snap these mode in the LCD Instrument button , scroll to Service Mode by pressing Move/ QR Codes or visit the listed Reset button...
DRIVER'S PANEL Electronic Stability Control (ESC) Hill-Start Assist Control (HAC) The ESC system is designed to help stabilize the vehicle during cornering HAC helps prevent the vehicle from rolling backwards when accelerating maneuvers . It is a good idea to keep the ESC turned on for daily driving from a stop while on a steep incline .
DRIVER'S PANEL Blind Spot Detection (BSD) System* QR CODE Blind Spot Detection The BSD system uses radar sensors to help alert the driver before changing System w/RCTA Video lanes . The light on the BSD button will illuminate when turned ON . The outside rearview mirror warning lights will also illuminate for 3 seconds .
DRIVER'S PANEL Lane Departure Warning System (LDWS)* QR CODE Lane Departure Warning With the ENGINE START/STOP button in the ON position, press System Video the LDWS button to turn system ON . The instrument cluster indicator will illuminate green . LDWS LDWS LDWS...
DRIVER'S PANEL Power Windows, Window Lock & Central Door Lock Pull/Press to operate Driver’s Window Auto Up/Down* Press to Unlock/Lock All Doors Press to disable Rear Passenger Windows Power Folding Outside Mirrors Toggle switch left or right to select mirror . Then press arrows to adjust Power Folding Outside Mirror position .
DRIVER'S PANEL Reverse Parking Aid Function* Fuel Door and Trunk Release Buttons Press the button to release the fuel door . When the gear shift lever is moved into R (Reverse) and while the vehicle is moving backwards, the outside rearview mirrors will rotate downward to Press the button to open the trunk .
DRIVER'S PANEL Engine Start/Stop Button QR CODE To start the engine: Engine Start/Stop Button & Smart Key Video 1 . Depress the brake pedal 2 . Press the ENGINE START/STOP button while in Park or Neutral To view a video on your ENGINE START mobile device, snap this...
STEERING WHEEL CONTROLS Manual Tilt/Telescoping Steering Wheel* Power Tilt/Telescoping Steering Wheel* To adjust the Steering Wheel, press the Lock-Release Lever down and To adjust the Steering Wheel angle , move the switch up or down . adjust to desired angle and distance .
When the light switch is in the AUTO Light position, the AFLS will activate . REMINDER: When the AFLS indicator illuminates on the Instrument Cluster, the AFLS is not working properly . See authorized Kia dealer for service . *IF EQUIPPED ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS.
STEERING WHEEL CONTROLS Turn Signals & Fog Lights* To operate: • Turn Signals - Move lever Up/Down for Right/Left Turn Signal • Fog Lights - Push toggle switch to turn Fog Lights ON/OFF REMINDER: Headlights must be ON for Fog Light operation . One-Touch Lane Change Signal is activated by moving the Turn Signal Lever slightly for less than 1 second and then releasing .
STEERING WHEEL CONTROLS Windshield Wipers & Washers To operate: • Move lever Up/Down to change Wiper modes MIST: Single wipe • Pull level to spray and wipe OFF: Wiper off AUTO: Auto Control wipe Auto Rain Sensing LO: Slow wipe The rain sensor located on the upper end of the HI: Fast wipe windshield glass senses the amount of rainfall and...
End Call button: Press to end a call or cancel a function For more information, if equipped, refer to the Car Multimedia System User's Manual. For Bluetooth Wireless Technology FAQs, go to www.kia.com, Owners section, or call Consumer Information for ®...
Page 21
Voice Recognition and Phone Contact Tips Bluetooth Wireless Technology ® QR CODE The Kia Voice Recognition System may Pairing a Phone Voice Recognition Tips Video have difficulty understanding some accents For instructions on how to pair a phone, refer to the Car Multimedia System or uncommon names .
STEERING WHEEL CONTROLS Advanced Smart Cruise Control (ASCC)* QR CODE Advanced Smart Cruise The Advanced Smart Cruise Control (ASCC)* system allows you to set the Control Video vehicle to maintain a speed so long as it is not limited by traffic . When traffic is encountered, the vehicle will be slowed to maintain a set distance behind traffic To view a video on your without depressing the accelerator or brake pedal .
CENTER PANEL Navigation System QR CODE – FM/AM/Sirius /Media (CD, MP3, USB, iPod , Aux, Bluetooth Audio Streaming, My Music) Navigation Audio ® ® ® System Videos To view a video on your mobile device, snap this QR Code or visit the listed website .
CENTER PANEL Surround View Monitor (SVM)* QR CODE The Surround View Monitor (SVM) is a parking support system that shows the areas around the front, rear, left, and Surround View Monitor Video right sides of the vehicle via four cameras displayed onto the Navigation screen . •...
CENTER PANEL Clock Aux/USB/iPod Port ® QR CODE & Power Outlets USB Port Video To view a video on your PASS AUTO AIR BAG FRONT mobile device, snap this QR Code or visit the listed CLIMATE REAR website . Refer to page 2 for more information .
CENTER PANEL Automatic Climate Control Air conditioning button Front windshield Mode selection button defroster button Dual temperature control Automatic climate selection button control button PASS AUTO AIR BAG FRONT Driver’s/Dual temperature Passenger’s temperature control buttons control buttons CLIMATE REAR OFF button Recirculated Air ON/OFF button Climate information screen Rear window...
CENTER PANEL Automatic Gear Shift with Sportmatic Shifting ® QR CODES To view a video on your P: Park mobile device, snap these QR Codes or visit the listed R: Reverse website . N: Neutral Refer to page 2 for more information .
A click or electric brake motor sound may be heard while operating or releasing the EPB, but these conditions are normal and indicate that the EPB is functioning properly be a system malfunction . Take your vehicle to a local Kia dealer . QUICK TIPS •...
CENTER PANEL Heated Steering Wheel* Press Heated Steering Wheel button to turn ON/OFF Steering Wheel Heater, while the ENGINE START/STOP button is in the ON position . Steering Wheel Heater will turn off automatically in 30 minutes, or when button is pressed again to deactivate .
CENTER PANEL Seat Warmers / Ventilated Seats* QR CODE Seat Warmers and Seat Warmers only* Seat Warmers / Ventilated Seats* Ventilated Seats Video • Press button once for high setting (2 LEDs lit) Seat Warmers To view a video on your •...
SEATING Power Adjustable Driver’s Seat* Move/Press controls to adjust Seat forward/backward, Seat Cushion, Seatback, Lumbar or Cushion Extension Seat forward/backward Seat Cushion Seatback Cushion Extension Lumbar CADENZA F E A T U R E S & F U N C T I O N S G U I D E *IF EQUIPPED...
SEATING Driver Position Memory System* Front Seat Headrest Adjustment The integrated system stores into memory the position To adjust headrest forward: Pull headrest forward at an angle . of the Driver’s Seat, Outside Rearview Mirrors and the To adjust headrest back: Pull forward at a slight angle to the Steering Wheel .
OTHER KEY FEATURES Smart Key QR CODE Engine Start/Stop Button Press to lock All Doors & Smart Key Video Press to unlock Driver’s Door . Press twice in 4 seconds to unlock All Doors To view a video on your Press and hold for more than 1 second to unlock Trunk and manually open mobile device, snap this QR Code or visit the listed...
OTHER KEY FEATURES How to Sync Transmitter with HomeLink ® HomeLink with Auto-Dimming Rearview Mirror ® If programming for the first time, begin with Step 1 (repeating this step will Glare detection sensor HomeLink button ® delete all information) . Automatic dimming ON/OFF HomeLink button...
OTHER KEY FEATURES Map/Room Lamps Automatic turn off function* The interior lights automatically turn off approximately 30 seconds after the ENGINE START/ STOP button is OFF . Map/Room Lamp Operation Press the lens to turn the Map Lamp ON/OFF . This light produces a spot beam for convenient use as a map lamp or as a personal lamp for the driver or the front passenger .
OTHER KEY FEATURES Panoramic Sunroof Operation* The Sunroof and Sunshade operation is controlled through a multidirectional switch/lever . The ignition needs to be in the ON position to operate the sunroof/sunshade . Slide the Sunshade and Sunroof: • Auto Open: Slide lever backward to the farthest position and release • Auto Close: Slide the lever forward to the farthest position and release Slide the Sunshade: • Auto Open: Slide the lever partially backward to the first detent position...
OTHER KEY FEATURES Back-Up Warning System (Rear Parking Rear-Camera Display Assist System)* The Rear-Camera Display system is not a safety device . It is a supplemental system that displays the view behind the vehicle through the Navigation The Back-Up Warning System is not a safety device . The Back-Up screen while the vehicle is in Reverse .
OTHER KEY FEATURES Trunk Release Button Fuel Cap/Malfunction Indicator QR CODE (Check Engine Light) One-Click Fuel Cap Video Located underneath the Trunk lid . With Trunk unlocked, press the Trunk Release button and pull the Trunk lid up by the Tighten for ONE CLICK To view a video on your handle to open .
OTHER KEY FEATURES Hood Release Lever and Latch Opening the Hood: 1 . Pull the Hood Release Lever to unlatch the Hood 2 . In the front of the vehicle, lift the Hood slightly, push the secondary Latch to the left inside of the Hood’s center and lift the Hood (Lever located near floor below Driver's Panel) Closing the Hood: Lower the Hood about halfway and then press down to securely lock in place .
SAFETY FEATURES Occupant Detection System (ODS) / Passenger Airbag Off Indicator ODS detects the presence and position of the front passenger and adjusts or turns off airbag deployment accordingly . Depending on the situation and type of accident, the system may: • Deploy airbag (Adult) • Not deploy the airbag (Unoccupied) If the system determines that the airbag should not be deployed, the “PASS AIR BAG OFF”...
SAFETY FEATURES Seat Belts Seat Belt Retractor Locks To properly fasten your seat belts: Retractor locks allow lap/shoulder safety belts to remain unlocked during normal vehicle operation for freedom of movement and increased comfort . 1 . Insert the tongue belt plate into the buckle until it clicks During a STRONG STOP, SUDDEN TURN OR CERTAIN COLLISIONS, seatbelt...
Page 43
Seat Belts / Airbags: For maximum protection, always wear your Seat Belt. Navigation: GPS maps and directions are for information purposes only, and Kia does not make any warranties about the accuracy of that information. Kia is not responsible for loss or delay resulting from the use of the navigation system.
Page 44
N O R M A L M A I N T E N A N C E S C H E D U L E When your vehicle requires service, remember that your dealer knows your vehicle best. Your dealer has factory-trained technicians, recommended special tools, genuine Kia replacement parts, and is dedicated to your complete satisfaction.
Page 45
Dealership Name: _______________________________________Sales Consultant: _________________Date: ________________________ BEFORE DELIVERY Test and confirm “Good Battery” using the Kia GR8-1299 battery tester and affix Results Label Verify all tire pressures are to spec (see driver’s door label) LF Verify proper operation of Remote Keyless Entry and Smart Key lock/unlock...
Page 46
DURING DELIVERY Explain first service process and schedule first service appointment Tour Parts & Service departments, introduce staff and explain value of Kia Parts and Service Review recommended maintenance schedule and maintenance requirements to validate warranty Review business hours and Customer 360° Care...
