Page 2 Thank you for becoming the owner of a new Kia vehicle. As a global car manufacturer focused on building high-quality, value for money prices, Kia Motors is dedicated to providing you with a customer service experience that exceeds your expectations.
Page 3 Thank you for choosing a Kia vehicle. The information and specifications provided in this manual were accurate at the time of printing. Kia reserves the right to When you require service, remember that your Kia Dealer discontinue or change specifications or design at any time knows your vehicle best.
Page 4: Table Of Contents
Introduction How to use this manual / Fuel requirements / Vehicle break-in process / Vehicle data collection and event data recorders / Indicator symbols on the instrument cluster Your vehicle at a glance Exterior overview / Interior overview / Instrument panel overview / Engine compartment Safety features of your vehicle Seats / Seat belts / Child restraint system / Air bag Features of your vehicle...
Page 5: Introduction
Introduction How to use this manual ..... . 1-2 Fuel requirements ......1-3 •...
Page 6: How To Use This Manual
Introduction HOW TO USE THIS MANUAL We want to help you get the greatest The general layout of the manual is You will find various types of safety possible driving pleasure from your provided in the Table of Contents. instructions in this manual. These vehicle.
Page 7: Fuel Requirements
Introduction FUEL REQUIREMENTS ✽ ✽ NOTICE Your new Kia vehicle is designed to WARNING - Refueling use only unleaded fuel having a Tighten the cap until it clicks one pump octane number ((R+M)/2) of • Do not "top off" after the noz-...
Page 8: Do Not Use Methanol
Manganese Tricarbonyl). Detergent Gasoline, which help pre- vent deposit formation in the engine. 1. Gasoline or gasohol containing Kia does not recommend the use of These gasolines will help the engine methanol. gasoline containing MMT. run cleaner and enhance perform- 2.
Page 9: Operation In Foreign Countries
Introduction VEHICLE BREAK-IN PROCESS Operation in foreign countries No special break-in period is need- ed. By following a few simple precau- If you are going to drive your vehicle tions for the first 600 miles (1,000 in another country, be sure to: km) you may add to the perform- •...
Page 10: Vehicle Data Collection And Event Data Recorders
Introduction VEHICLE DATA COLLECTION AND EVENT DATA RECORDERS This vehicle is equipped with an These data can help provide a bet- To read data recorded by an EDR, event data recorder (EDR). The ter understanding of the circum- special equipment is required, and main purpose of an EDR is to stances in which crashes and access to the vehicle or the EDR is...
Page 11: Indicator Symbols On The Instrument Cluster
Introduction INDICATOR SYMBOLS ON THE INSTRUMENT CLUSTER Charging system warning Air bag warning light ESC indicator light Trunk (tailgate) open ajar ABS warning light ESC OFF indicator warning light Electric power steering Seat belt warning light Door ajar warning light (EPS) system warning light* Turn signal indicator Immobilizer indicator*...
Page 12: Your Vehicle At A Glance
Your vehicle at a glance Exterior overview I ......2-2 Exterior overview II......2-3 Interior overview .
Page 13 Your vehicle at a glance EXTERIOR OVERVIEW I ■ ■ Front 1. Hood ............4-30 5. Outside rearview mirror......4-42 2. Headlamp ..........7-68 6. Sunroof ..........4-35 7. Wiper blade ..........7-36 3. Fog light ..........7-68 4. Tires and wheels ........7-42 8. Windows ..........4-25 OUB021003K...
Page 14 Your vehicle at a glance EXTERIOR OVERVIEW II ■ ■ Rear 9. Door ............4-16 13. Rear wiper blade ........7-37 10. Fuel filler lid ........4-32 14. Center high mounted stop light ..7-78 11. Rear combination lamp ......7-73 15. Rear window defroster......4-86 12.
Page 15 Your vehicle at a glance INTERIOR OVERVIEW 1. Door lock/unlock button ....4-17 2. Central door lock switch....4-18 3. Power window switches ....4-25 4. Power window lock button ....4-28 5. Outside rearview mirror control switch ..........4-42 6. Hood release lever......4-30 7. Fuel filler lid release lever ....4-32 8.
Page 16 Your vehicle at a glance INSTRUMENT PANEL OVERVIEW 1. Instrument cluster......4-45 2. Horn ..........4-41 3. Driver’s front air bag......3-42 4. Light control/Turn signals ....4-76 5. Wiper/Washer........4-80 6. Ignition switch or ENGINE START/ STOP button .........5-5, 5-7 7. Hazard warning flasher switch ..4-76, 6-2 8.
Page 17 Your vehicle at a glance ENGINE COMPARTMENT 1. Engine Coolant Reservoir ....7-27 2. Engine Oil Filler Cap ......7-26 3. Brake/Clutch Fluid Reservoir ...7-30 4. Air Cleaner ........7-32 5. Fuse Box ..........7-56 6. Negative Battery Terminal..6-5, 7-39 7. Positive Battery Terminal ..6-5, 7-39 8.
Page 18: Safety Features Of Your Vehicle
Safety features of your vehicle Seats........3-2 •...
Page 19: Seats
Safety features of your vehicle SEAT Driver’s seat (1) Forward and rearward (2) Seatback angle (3) Seat cushion height* (4) Seat warmer* (5) Headrest Front passenger’s seat (6) Forward and rearward (7) Seatback angle (8) Seat warmer* (9) Headrest Rear seat (10) Headrest* (11) Seatback folding* ■...
Page 20 Safety features of your vehicle WARNING WARNING - Loose - Driver WARNING - Driver’s seat objects responsibility for passen- • Never attempt to adjust the seat while the vehicle is mov- gers Do not place anything in the dri- ing of your vehicle. This could ver's foot well or under the front result in loss of control of seats.
Page 21: Front Seat
Safety features of your vehicle WARNING WARNING - Seat - Unexpected adjustment seat movement • Do not adjust the seat while After adjusting a manual seat, wearing seat belts. Moving the always check that it is locked by seat forward will cause strong shifting your weight to the front pressure on the abdomen.
Page 22 Safety features of your vehicle OUB031003 OUB031004 OUB031042N Seatback angle Seat height (if equipped) Headrest (for driver’s seat) To recline the seatback: The driver's and front passenger's seats are equipped with a headrest To change the height of the seat, 1.Lean forward slightly and lift up the for the occupant's safety and com- move the lever upwards or down-...
Page 23 Safety features of your vehicle Also, adjust the headrest as close to your head as possible. For this reason, the use of a cushion that holds the body away from the seatback is not recommended. WARNING - Headrest removal/adjustment • Do not operate the vehicle with the headrests removed.
Page 24 Safety features of your vehicle OYFH034205 OUB034100 OUB034101 Removal and installation To reinstall the headrest : CAUTION To remove the headrest: 1. Put the headrest poles (2) into the holes while pressing the release If you recline the seatback 1. Recline the seatback (2) with the button (1).
Page 25 Safety features of your vehicle CAUTION - Seat damage WARNING - Seat warmer burns • When cleaning the seats, do not use an organic solvent The seat warmer may cause such as paint thinner, ben- burns, even at low tempera- zene, alcohol and gasoline.
Page 26: Rear Seat
Safety features of your vehicle Generally, the center of gravity of most people's head is similar with the height as the top of their eyes. Also adjust the headrest as close to your head as possible. For this rea- son, the use of a cushion that holds the body away from the seatback is not recommended.
Page 27 Safety features of your vehicle Folding the rear seat The rear seatbacks may be folded to facilitate carrying long items or to increase the luggage capacity of the vehicle. WARNING - Folded Seatback Never allow passengers to sit on top of the folded down seatback while the vehicle is moving.
Page 28 Safety features of your vehicle OUB031049K OUB031051K OUB032049 To fold down the rear seatback: 4.Pull the lock release lever (1) and • 5 door fold the rear seatback forward and 1.Make sure the rear seat belt web- • 4 door down firmly.
Page 29 Safety features of your vehicle To unfold the rear seat WARNING - Rear seat- 1.To use the rear seat, lift and pull back the seatback backward. Pull the seatback firmly until it clicks into When returning the rear seat- place. Make sure the seatback is back from a folded to an upright locked in place.
Page 30: Seat Belts
Safety features of your vehicle SEAT BELTS Seat belt restraint system • Never allow children to ride in the WARNING - Twisted seat front passenger seat. See child Seat belts are designed to bear upon belt restraint system section for further the bony structure of the body, and discussion.
Page 31 Safety features of your vehicle Conditions Warning Pattern Vehicle Chime- Seat Belt Light-Blink Speed Sound Unbuckled 6 seconds Buckled 6 seconds None Below 3 mph 6 seconds None (5 km/h) Buckled → 3 mph~ 6 seconds Unbuckled 6 mph Above 6 mph 6 sec.
Page 32 Safety features of your vehicle • You can find the front passenger's Conditions Warning Pattern seat belt warning light on the cen- Vehicle Seat Belt Light-Blink ter fascia panel. Speed • Although the front passenger seat Unbuckled 6 seconds is not occupied, the seat belt warn- Above 6mph Unbuckled Continuously...
Page 33 Safety features of your vehicle The seat belt automatically adjusts to To raise the height adjuster, pull it up Front seat the proper length only after the lap (1). To lower it, push it down (3) while belt portion is adjusted manually so pressing the height adjuster button that it fits snugly around your hips.
Page 34 Safety features of your vehicle Seat belts - Front passenger and It automatically adjusts to the proper rear seat 3-point system with length only after the lap belt portion of the seat belt is adjusted manually combination locking retractor so that it fits snugly around your hips. To fasten your seat belt: When the seat belt is fully extended Combination retractor type seat belts...
Page 35: Pre-Tensioner Seat Belt
Safety features of your vehicle OUB031020N B210A01NF-1 OMG035300 Pre-tensioner seat belt When using the rear center seat belt, To release the seat belt: the buckle with the “CENTER” mark The seat belt is released by pressing Your vehicle is equipped with driver's must be used.
Page 36 Safety features of your vehicle When the vehicle stops suddenly, or Both the driver's and front passen- if the occupant tries to lean forward ger's pre-tensioner seat belts may be too quickly, the seat belt retractor will activated in certain frontal collisions. lock into position.
Page 37 This must be Child and/or infant seats must be ignition switch has been turned to the done by an authorized Kia dealer. properly placed and installed in the ON position, and then it should turn rear seat. For more information off.
Page 38 Safety features of your vehicle Larger children If the shoulder belt portion slightly Restraint of pregnant women touches the child’s neck or face, try Children who are too large for child Pregnant women should wear placing the child closer to the center restraint systems should always lap/shoulder belt assemblies when- of the vehicle.
Page 39: Care Of Seat Belts
Kia dealer. the rear seat or if the front seat is in a reclined position.
Page 40: Child Restraint System
Safety features of your vehicle CHILD RESTRAINT SYSTEM Children riding in the car should sit in Children could be injured or killed in WARNING - Hot child the rear seat and must always be a crash if their restraints are not restraint properly restrained to minimize the properly secured.
Page 41: Using A Child Restraint System
Safety features of your vehicle Rearward-facing child restraint system WARNING WARNING - Holding - Seat belt children Never hold a child in your arms Do not use one seat belt for two or lap when riding in a vehicle. occupants at the same time. The violent forces created dur- This will eliminate any safety ing a crash will tear the child...
Page 42 Placing a passenger seat belt authorized Kia dealer. result in the improper installa- into the auto lock mode tion of the child restraint sys- The auto lock mode will help prevent...
Page 43 Safety features of your vehicle OEN036101 OEN036102 OEN036103 3.Pull the shoulder portion of the 4.Slowly allow the shoulder portion To install a child restraint system on seat belt all the way out. When the of the seat belt to retract and listen the outboard or center rear seats, do shoulder portion of the seat belt is for an audible “clicking”...
Page 44: Automatic Locking Mode
Safety features of your vehicle The lap/shoulder belt automatically ■ 4 door returns to the “emergency lock mode” whenever the belt is allowed to retract fully. Therefore, the preceding seven steps must be followed each time a child restraint is installed. To remove the child restraint, press the release button on the buckle and then pull the lap/shoulder belt out of...
Page 45 Safety features of your vehicle Securing a child restraint seat 2.Connect the tether strap hook to with tether anchorage system the appropriate child restraint hook holder and tighten to secure the Child restraint hook holders are child restraint seat. located on the floor behind the rear seats.
Page 46: Lower Anchor System
Safety features of your vehicle Lower Anchor Lower Anchor Position Indicator 1SAE3090A OUB031039N OUN036140L Securing a child restraint seat Child restraint symbols are located LATCH anchors have been provided on the left and right rear seat backs with child seat lower anchor sys- in your vehicle.
Page 47 Safety features of your vehicle ✽ ✽ NOTICE When you install your child's restraint WARNING - LATCH system using the LATCH anchors The recommended weight for the lower anchors buckle the shoulder lap belt, then LATCH system is under 65 lb (30 lock the retractor and pull the belt to Never attempt to attach a kg).
Page 48: Air Bag - Advanced Supplemental Restraint System
Safety features of your vehicle AIR BAG - ADVANCED SUPPLEMENTAL RESTRAINT SYSTEM (1) Driver’s front air bag (2) Passenger’s front air bag (3) Side impact air bag (4) Curtain air bag Even in vehicles with air bags, you and your passengers must always wear the safety belts provided in order to minimize the risk and sever- ity of injury in the event of a collision...
Page 49: How Does The Air Bag System Operate
Safety features of your vehicle How does the air bag system • The front air bags will completely • There are even circumstances inflate and deflate in an instant. under which contact with the operate steering wheel air bag can cause It is virtually impossible for you to •...
Page 50 Safety features of your vehicle Noise and smoke WARNING When the air bags inflate, they make - Hot components a loud noise and they leave smoke and powder in the air inside of the Do not touch the air bag storage vehicle.
Page 51: Air Bag Warning Light
6 seconds, then go off. 4.Curtain air bag modules Have the system checked by an 5.Retractor pre-tensioner assem- authorized Kia dealer if: blies* • The light does not turn on briefly 6.Air bag warning light when you turn the ignition ON.
Page 52 If any of the following conditions occurs, this indicates a malfunction of the SRS. Have an authorized Kia dealer inspect the air bag system as soon as possible. 3 35...
Page 53 Safety features of your vehicle Driver’s front air bag (2) Driver’s front air bag (3) Passenger’s front air bag B240B02L B240B03L B240B05L Upon deployment, tear seams mold- A fully inflated air bag, in combina- ed directly into the pad covers will tion with a properly worn seat belt, WARNING - Air bag...
Page 54 Safety features of your vehicle ✽ ✽ NOTICE Main components of occupant detection system Before you replace a fuse or discon- • A detection device located within nect a battery terminal, turn the the front passenger seat track. ignition switch to the LOCK posi- tion and remove the ignition key.
Page 55 Safety features of your vehicle If the front passenger seat is occu- Always be sure that you and all vehi- (5) Improperly wearing the safety pied by a person that the system cle occupants are seated and belt. determines to be of adult size, and restrained properly (sitting upright (6) Reclining the seat back.
Page 56 Safety features of your vehicle Condition and operation in the front passenger occupant detection WARNING - ODS system system Riding in an improper position Indicator/Warning light Devices adversely affects the occupant Condition detected by the occupant PASSENGER AIR detection system (ODS) and Front passenger SRS warning detection system...
Page 57 Safety features of your vehicle (Continued) B990A08O 1KMN3663 1KMN3665 - Never sit with the hips shifted - Never place the feet on the - Never put a heavy load in the towards the front of the seat. dashboard. front passenger seat. OVQ036014N 1KMN3662 1KMN3664...
Page 58 Safety features of your vehicle ✽ ✽ NOTICE If the PASSENGER AIR BAG “OFF” indicator is still on, ask the passen- The PASSENGER AIR BAG “OFF” ger to move to the rear seat. indicator illuminates for about 4 sec- onds after the ignition switch is WARNING - “AIR BAG turned to the ON position or after...
Page 59: Driver's Front Air Bag
Safety features of your vehicle Any child age 12 and under should If the occupant detection system is Driver’s front air bag ride in the rear seat. Children too not working properly, the SRS air large for child restraints should use bag warning light on the instru- the available lap/shoulder belts.
Page 60 Safety features of your vehicle The indications of the system's pres- The advanced SRS offers the ability Additionally, your vehicle is equipped ence are the letters "AIR BAG" to control the air bag inflation with with an occupant detection system in embossed on the air bag pad cover two levels.
Page 61 That contact is Kia’s toll-free can be provided by the pre-tensioner Customer Assistance center at 1- seat belt alone.
Page 62: Side Impact Air Bag
Safety features of your vehicle The purpose of the air bag is to pro- Rear impact Front vide the vehicle's driver and/or the front passenger with additional pro- tection than that offered by the seat belt alone. The side impact air bags are designed to deploy only during cer- tain side-impact collisions, depend- ing on the crash severity, angle,...
Page 63: Curtain Air Bag
Kia dealer. a substitute for them. Therefore your Inform that your vehicle is equipped seat belts must be worn at all times with side impact air bags and an while the vehicle is in operation.
Page 64 This should only be done by sions. an authorized Kia dealer. The curtain air bags are designed to deploy only during certain side impact collisions, depending on the crash severity, angle, speed and impact.
Page 65 Safety features of your vehicle Why didn’t my air bag go off in a collision? (Inflation and non-infla- tion conditions of the air bag) There are many types of accidents in which the air bag would not be expected to provide additional protection.
Page 66 Therefore, do not try to per- impact of the front collision. form maintenance around the air bag sensors. Have the vehicle checked and repaired by an authorized Kia dealer. 3 49...
Page 67 Safety features of your vehicle Side air bags Side air bags (side impact and/or curtain air bags) are designed to inflate when an impact is detected by side collision sensors depending on the strength, speed or angles of impact resulting from a side impact collision.
Page 68 Safety features of your vehicle OUN036087 OUB031045N 1VQA2089 • Air bags are not designed to inflate • Front air bags may not inflate in • In a slant or angled collision, the in rear collisions, because occu- side impact collisions, because force of impact may direct the pants are moved backward by the occupants move to the direction of...
Page 69 Safety features of your vehicle 1VQA2090 OUB031046N 1VQA2092 • Just before impact, drivers often • Air bags do not inflate in most • Air bags may not inflate if the vehi- brake heavily. Such heavy braking rollover accidents, even though the cle collides with objects such as lowers the front portion of the vehi- vehicle is equipped with side...
Page 70: Srs Care
Kia deal- ation of your vehicle's air bag sys- bags or by rendering the SRS tem. inoperative. Any work on the SRS system, such...
Page 71: Air Bag Warning Label
Safety features of your vehicle OAM039041 OUB031035N Air bag warning label Air bag warning labels, some required U.S. National Highway Traffic Safety Administration (NHTSA), are attached to alert the driver and passengers of potential risks of the air bag system.
Page 72: Features Of Your Vehicle
Features of your vehicle Keys ........4-3 Steering wheel .
Page 73 Lighting........4-76 Interior features ......4-102 .
Page 74: Keys
Should lose your keys, this number will enable an authorized Kia dealer to duplicate the keys easily. After recording the key code number, remove the tag and store it in a safe place.
Page 75: Smart Key
WARNING - Aftermarket - Ignition key keys (Smart key) Use only Kia original parts for Never leave the keys in your the ignition key in your vehicle. vehicle with unsupervised chil- If an aftermarket key is used, dren. Leaving children unat-...
Page 76: Smart Key Functions
Features of your vehicle SMART KEY (IF EQUIPPED) Smart key functions Carrying the smart key, you may lock and unlock the vehicle doors. Also, you may start the engine. Refer to the following, for more details. OYDDCO2004 OUB041004 Locking With a smart key, you can lock or unlock a door and even start the Pressing the button of the front out- engine without inserting the key.
Page 77 Features of your vehicle Even though you press the button, Pressing the button in the front pas- Tailgate unlocking (5 door) the doors will not lock and the chime senger's outside door handle with all (if equipped) will sound for 3 seconds if any of the doors closed and locked, unlocks all If you are within 0.7 m (28 in.) from following occurs:...
Page 78: Smart Key Precautions
1.This device may not cause harmful contact an authorized Kia dealer. interference, and • A maximum of 2 smart keys can be • If the smart key is in close proximi- registered to a single vehicle.
Page 79: Remote Keyless Entry
Features of your vehicle REMOTE KEYLESS ENTRY (IF EQUIPPED) Lock (1) Unlock (2) ■ Type A All the doors will locked if the lock The driver's door will unlocked if the button is pressed. If all the doors unlock button is pressed once. The (and trunk or tailgate) are closed, the hazard warning lights will blink (for hazard warning lights will blink once...
Page 80: Transmitter Precautions
When the transmitter (or smart key) does not work properly, open and close the door with the ignition key. If you have a problem with the trans- mitter (or smart key), contact an authorized Kia dealer. (Continued)
Page 81: Battery Replacement
A battery should last for several warranty. years. If the transmitter or smart key is not working properly, first try replacing the battery. If you are unsure how to use or replace the battery, contact an authorized Kia dealer.
Page 82: Immobilizer System
If you are unsure how to use or replace the battery, contact an To deactivate the immobilizer authorized Kia dealer. system: Using the wrong battery can cause Insert the ignition key into the key...
Page 83 1.This device may not cause harmful If you need additional keys or lose interference, and your keys, consult an authorized Kia 2.This device must accept any inter- dealer. ference received, including inter- ference that may cause undesired operation.
Page 84: Theft-Alarm System
Features of your vehicle THEFT-ALARM SYSTEM (IF EQUIPPED) Armed stage • The doors can be locked by pressing the button on the front Park the vehicle and stop the engine. outside door handles while the Arm the system as described below. Armed smart key is in your possession.
Page 85 Features of your vehicle Do not arm the system until all Theft-alarm stage Disarmed stage passengers have left the vehicle. If The alarm will be activated if any of The system will be disarmed when: the system is armed while a pas- the following occurs while the system senger(s) remains in the vehicle, Transmitter...
Page 86 ON position and wait for 30 seconds. Then the system will be disarmed. • If you lose your keys, consult your authorized Kia dealer. 4 15...
Page 87: Door Locks
Features of your vehicle DOOR LOCKS ✽ ✽ • If you lock/unlock the door with a NOTICE ■ Type A key, vehicle doors will • In cold and wet climates, door lock lock/unlock automatically and door mechanisms may not equipped with power door locks). work properly due to freezing con- •...
Page 88: Inside The Vehicle
Features of your vehicle • If the inner door handle of the front door is pulled when the door lock button is in the lock position, the button will unlock and the door will open. (if equipped) • Front doors cannot be locked if the ignition key is in the ignition switch (or if the smart key is in the vehi- cle) and any front door is opened.
Page 89: Central Door Lock Switch
Features of your vehicle If a power door lock ever fails to func- Driver’s door Passenger’s door WARNING - Doors tion while you are in the vehicle, try one or more of the following tech- The doors should always be niques to exit: fully closed and locked while •...
Page 90: Child-Protector Rear Door Lock
Features of your vehicle Impact sensing door unlock An authorized Kia dealer can acti- vate or deactivate some auto door system (if equipped) lock/ unlock features as follows; All doors will automatically unlock • Auto door unlock by using the dri-...
Page 91 Features of your vehicle 3.Close the rear door. To open the rear door, pull the out- side door handle (3). Even though the doors may be unlocked, the rear door will not open by pulling the inner door handle (2) until the rear door child safety lock is unlocked.
Page 92 Features of your vehicle TRUNK (4 DOOR) WARNING The trunk swings upward. Make sure no objects or people are near the rear of the vehicle when opening the trunk. CAUTION Make certain that you close the trunk before driving your vehi- ORB040006 OUB041203K cle.
Page 93: Trunk
Features of your vehicle Closing the trunk To close, lower the trunk lid, then press down on it until it locks. To be sure the trunk lid is securely fas- tened, always check by trying to pull it up again. WARNING - Exhaust Fumes...
Page 94: Tailgate
Features of your vehicle TAILGATE The tailgate swings upward. Make sure no objects or people are near the rear of the vehicle when opening the tailgate. CAUTION - Tailgate lift cylinders Make certain that you close the tailgate before driving your vehicle.
Page 95 Features of your vehicle WARNING - Exhaust fumes Driving with the tailgate open is advisable. Dangerous exhaust fumes can enter the passenger compartment. If you must drive with the tail- gate opened, keep the air vents and all windows open so that additional outside air can enter.
Page 96: Windows
Features of your vehicle WINDOWS (1) Driver’s door power window switch* (2) Front passenger’s door power window switch* (3) Rear door (left) power window switch* (4) Rear door (right) power window switch* (5) Window opening and closing (6) Automatic power window down* (7) Power window lock button* *: if equipped OUB041016...
Page 97 Features of your vehicle ✽ ✽ NOTICE In cold and wet climates, power win- Window opening and closing dows may not work properly due to (if equipped) While driving with the rear windows freezing conditions. The driver’s door has a master power down or with the sunroof (if window switch that controls all the equipped) in an open (or partially...
Page 98 Features of your vehicle 1.Turn the ignition switch to the ON position. 2.Close the window and continue pulling up on the driver’s power window switch for at least 1 second after the window is completely closed. OTA040015 OUN026013 Auto up/down window (if equipped) Automatic reversal Pressing or pulling up the power win- If the upward movement of the win-...
Page 99: Power Window Switches
Features of your vehicle And if the power window switch is CAUTION - Opening / pulled up continuously again within 5 closing Window seconds after the window is lowered by the automatic window reversal To prevent possible damage to feature, the automatic window rever- the power window system, do sal will not operate.
Page 100 Features of your vehicle OSA028222 Manual windows (if equipped) To raise or lower the window, turn the window regulator handle clockwise or counterclockwise. When closing the windows, make sure your passenger's arms, hands and body are safely out of the way. 4 29...
Page 101: Hood
Features of your vehicle HOOD OUB041021 OUB041022 OUB041023 Opening the hood 2.Go to the front of the vehicle, raise 3.Pull out the support rod from the the hood slightly, push the second- hood. 1.Pull the release lever to unlatch the ary latch (1) inside of the hood 4.Hold the hood opened with the hood.
Page 102 Features of your vehicle Closing the hood WARNING - Unsecured 1.Before closing the hood, check the engine hood following: Always double check to be sure • All filler caps in the engine com- that the hood is firmly latched partment must correctly before driving away.
Page 103: Fuel Filler Lid
Features of your vehicle FUEL FILLER LID Closing the fuel filler lid 1.To install the cap, turn it clockwise until it “clicks” one time. This indi- cates that the cap is securely one time tightened. 2.Close the fuel filler lid and push it in lightly and make sure that it is securely closed.
Page 104 Features of your vehicle Always check that the fuel cap is WARNING WARNING - Static installed securely to prevent fuel electricity spillage in the event of an accident. When using approved • Before touching the fuel noz- portable fuel container, be sure zle, you should eliminate to place the container on the WARNING...
Page 105 When refueling, always shut the If the fuel filler cap requires replace- engine off. Sparks produced by ment, use only a genuine Kia cap or electrical components related the equivalent specified for your vehi- to the engine can ignite fuel cle.
Page 106 Features of your vehicle SUNROOF (IF EQUIPPED) In cold and wet climates, the sunroof may not work properly due to freez- ing conditions. After the vehicle is washed or in a rainstorm, be sure to wipe off any water that is on the sun- roof before operating it.
Page 107 Features of your vehicle To open the sunroof automatically: Pull the sunroof control lever back- ward to the second detent position and then release it. The sunroof will slide all the way open. To stop the sunroof sliding at any point, pull or push the sunroof control lever momentarily.
Page 108: Sunroof
Features of your vehicle Do not extend the face, neck, arms WARNING - Sunroof or body outside the sunroof while operation driving. When closing the sunroof, make With the sunroof open for an extend- sure there are no body parts in ed period of time, dirt may accumu- the movement range of the slid- late on the guide rails causing noise...
Page 109 Features of your vehicle ❈ For more detailed information, Resetting the sunroof contact an authorized Kia dealer. Whenever the vehicle battery is dis- connected or discharged, or related ✽ ✽ NOTICE fuse is blown, you must reset your sunroof system as follows:...
Page 110: Steering Wheel
Take your vehicle to an vehicle may still be steered, but it will switch on. This happens as the sys- authorized Kia dealer and have the require increased steering effort. tem performs the EPS system vehicle checked as soon as possible.
Page 111: Tilt And Telescoping Steering
Features of your vehicle Tilt and telescoping (if equipped) steering Tilt steering allows you to adjust the steering wheel before you drive. You can also raise it to give your legs more room when you exit and enter the vehicle. The steering wheel should be posi- tioned so that it is comfortable for you to drive, while permitting you to...
Page 112: Horn
Features of your vehicle If the ignition is turned off and then on again within a half hour (while the heated steering wheel button is pressed), the steering wheel heating system will remain on. CAUTION • Do not install any grip to oper- ate the steering wheel.
Page 113: Mirrors
Features of your vehicle MIRRORS Inside rearview mirror Outside rearview mirror Adjust the rearview mirror so that the Be sure to adjust the mirror angles center view through the rear window before driving. is seen. Make this adjustment before Your vehicle is equipped with both Night you start driving.
Page 114 Features of your vehicle The right outside rearview mirror is ■ Move the lever (1) to R or L to select Type A convex. Objects seen in the mirror the right side mirror or the left side are closer than they appear. mirror, then press a corresponding point on the mirror adjustment con- Use your interior rearview mirror or...
Page 115 Features of your vehicle CAUTION - Electric type outside rearview mirror electric type outside rearview mirror operates even though the ignition switch is in the OFF position. However, to prevent unnecessary battery discharge, do not adjust the mirrors longer than necessary while the engine is not running.
Page 116: Instrument Cluster
Features of your vehicle INSTRUMENT CLUSTER ■ ■ Type A 1. Tachometer 2. Turn signal indicators 3. Speedometer 4. Fuel gauge 5. Engine coolant temperature gauge 6. Warning and indicator lights ■ ■ Type B 7. Shift position indicator (A/T) or Manual transaxle shift indicator (M/T) 8.
Page 117: Instrument Panel Illumination
Features of your vehicle ■ Type A OUB041041 ■ Type B OUB041038 OUB041045N Tachometer Instrument panel illumination The tachometer indicates the When the vehicle’s parking lights or approximate number of engine revo- headlights are on, push upward or lutions per minute (rpm). downward the illumination control knob to adjust the brightness of the Use the tachometer to select the cor-...
Page 118 Features of your vehicle CAUTION - Red zone Do not operate the engine with- in the tachometer's RED ZONE. This may cause severe engine damage. OUB042048N OUB042047N Engine coolant temperature gauge Fuel gauge This gauge shows the temperature The fuel gauge indicates the approx- of the engine coolant when the igni- imate amount of fuel remaining in the tion switch is ON.
Page 119 Features of your vehicle ✽ ✽ NOTICE ■ ■ Type A Type B WARNING - Fuel gauge It is against the law to alter the Stop and obtain additional fuel odometer on all vehicles with the as soon as possible after the intent to change the mileage regis- warning light comes on or when tered on the odometer.
Page 120: Trip Computer
Features of your vehicle ■ Type A All stored driving information (except ■ ■ Cluster Type A distance to empty and instant fuel TRIP A consumption) will reset if the battery is disconnected. TRIP B Distance to empty OUB041049 Average fuel consumption ■...
Page 121 Features of your vehicle ■ ■ Cluster Type B ■ ■ ■ ■ Type A Type B Type A Type B TRIP A TRIP B Distance to empty Average fuel consumption OUB041051N OUB041052N Tripmeter Distance to empty Instant fuel consumption TRIP A: Tripmeter A This mode indicates the estimated distance to empty based on the cur-...
Page 122 Features of your vehicle • If the vehicle is not on level ground If the vehicle speed exceeds 0.6 ■ ■ Type A Type B or the battery power has been MPH (1 km/h) after refueled more interrupted, “Distance than 6 l, the average fuel consump- empty”...
Page 123 Features of your vehicle ■ ■ ■ ■ ■ ■ Type A Type B Type A Type B Type A Type B OUB042054N OUB041055N OUB041056C Instant fuel consumption Average speed Driving time This mode calculates the instant fuel This mode calculates the average This mode indicates the total time consumption during the last few sec- speed of the vehicle since the last...
Page 124 Features of your vehicle Type A ■ ■ ■ ■ Type A Type B Type A Type B To change the outside temperature display unit (°C ↔ °F), press the RESET button more than 1 second in this mode. Type B To Change the outside temperature display unit (°C ↔...
Page 125: User Settings
Features of your vehicle ■ ■ ■ ■ ■ Type A Type B Type A Type B Type B OUB041177N OUB041062 OUB041069 Automatic transaxle shift posi- Illumination intensity User Settings (only for Type B tion indicator (if equipped) cluster, if equipped) The illumination intensity of the instrument panel is shown when The indicator displays which auto-...
Page 126 Features of your vehicle OUB041064 OUB041065 OUB041066 Align steering wheel Outside temperature unit Car option (only for Type B cluster, if equipped) (Steering position) (if equipped) (if equipped) On - The warning illuminates on the You can exchange the outside tem- 1.When the vehicle is at a standstill, perature unit °C ↔...
Page 127: Maintenance System
Features of your vehicle OUB041067 OUB042068 OUB041069 Language Maintenance Maintenance system (only for Type B cluster, Choose a language you prefer within 1.When the vehicle is at a standstill, if equipped) the LCD display. pressing the TRIP button for more than 2 seconds with the ENGINE The Maintenance system informs the START/ STOP button in the ON...
Page 128 Features of your vehicle OUB042070 OUB042071 OUB041072 Maintenance schedule Engine Oil(Tire Rotation) Service 2.If you would like to reset or inacti- Required vate the maintenance system 1.Select the desired engine oil (tire press the RESET button for more rotation) maintenance schedule. 1.If service is required, the message than 1 second.
Page 129: Warnings And Indicators
ON If this occurs, have your vehicle position or started the engine, or if it checked by an authorized Kia dealer comes on while driving, have the as soon as possible. The normal SRS inspected by an authorized Kia braking system will still be opera- dealer.
Page 130 In this case, have your light vehicle checked by an authorized Kia As a reminder to the driver, the seat dealer as soon as possible. If these two warning lights illuminate belt warning light will blink for...
Page 131 Features of your vehicle If the driver's seat belt is disconnect- Turn signal indicator Front fog light indicator ed after the ignition switch is turned (if equipped) to the ON position, the seat belt warning light will blink for approxi- mately 6 seconds.
Page 132 If the warning light remains on after adding oil or if oil is not available, call an authorized Kia dealer. CAUTION - Engine damage If the engine is not stopped...
Page 133 Have the vehicle towed to any electrical charging system. Have fluid warning light illuminates when authorized Kia dealer for a brake an authorized Kia dealer correct the ignition switch is in the ON posi- system inspection and necessary the problem as soon as possible.
Page 134 Features of your vehicle Trunk lid (or tailgate) Immobilizer indicator • When the battery is weak, if the open warning light (if equipped) ENGINE START/STOP button is pressed, the indicator will blink and you are not able to start the engine.
Page 135 Kia dealer. switch is turned to the ON position, take your vehicle to the nearest authorized Kia dealer and have the system checked. Generally, your vehicle will continue to be drivable, but have the system checked by an authorized Kia dealer promptly.
Page 136 This warning light will also illuminate ESC may have a malfunction. Take if one or more of your tires is signifi- your car to an authorized Kia dealer cantly under-inflated. You should and have the system checked. stop and check your tires as soon as possible.
Page 137 Features of your vehicle Cruise indicator (if equipped) Cruise SET indicator WARNING - Low tire CRUISE indicator pressure CRUISE Significantly low tire pressure makes the vehicle unstable and The indicator illuminates when the can contribute to loss of vehicle cruise function switch (SET- or control and increased braking The indicator illuminates when the RES+) is ON.
Page 138 EPS has malfunctioned. If it comes instrument panel when you are on while driving, have your vehicle WARNING - driving efficiently in the ECO ON inspected by an authorized Kia deal- ® ECOMINDER indicator mode. If you don't want the indicator dis- Don't keep watching the “ECO”...
Page 139 Features of your vehicle ✽ ✽ NOTICE Auto stop indicator (if equipped) When the engine automatically starts by the ISG system, some warning lights (ABS, ESC, ESC OFF, ESC or Parking brake warn- This indicator will illuminate when the ing light) may turn on for a few sec- engine enters the Idle Stop mode of onds.
Page 140 Features of your vehicle LCD display warning (if equipped) • For vehicle’s equipped with smart key system Key is not in vehicle Key is not detected Press start with smart key OUB043073 OUB043074 OUB043075 If the smart key is not in the vehicle If the smart key is not in the vehicle If you press the engine start/stop and if any door is opened or closed...
Page 141 Features of your vehicle • For vehicle’s equipped with smart key system Low key battery Press brake pedal to start engine Press clutch pedal to start engine (for automatic transaxle) (for manual transaxle) OUB043076 OUB041077 OUB041078 If the engine start/stop button changes to the OFF position when If the engine start/stop button If the engine start/stop button turns...
Page 142 Also, the warning chime sounds for If the warning illuminates each time about 10 seconds. (if equipped) you press the engine start/stop but- ton, take your vehicle to an author- ized Kia dealer and have the system checked. 4 71...
Page 143 Features of your vehicle Press start button while turn steering Check steering wheel lock system Check stop lamp fuse (if equipped) OUB041082 OUB041084 OUB041085 If the steering wheel does not unlock If the steering wheel does not lock When the stop lamp fuse is discon- normally when the engine start/stop normally when the engine start/stop nected, the warning illuminates for...
Page 144 Features of your vehicle Door open! (if equipped) Fuel cap open warning (if equipped) Align steering wheel (if equipped) OUB041087 OUB041088 OUB041170 It displays the corresponding door or This warning light indicates the fuel If you start the engine when the tailgate that is not closed securely.
Page 145 In this case, we recommend that you the LCD display for 5 seconds. have the vehicle inspected by an Turn the steering wheel to the left authorized Kia dealer as soon as and make it turned to the right less possible. than 30 degrees.
Page 146: Rear-Camera Display
Features of your vehicle REAR-CAMERA DISPLAY (IF EQUIPPED) ■ Type A Always keep the camera lens clean. If WARNING - Backing & lens is covered with foreign matter, using cam- the camera may not operate normally. Never rely solely on the rear WARNING - Rear Camera view camera when backing.
Page 147: Hazard Warning Flasher
Features of your vehicle HAZARD WARNING FLASHER LIGHTING Battery saver function • The purpose of this feature is to prevent the battery from being dis- charged. The system automatically turns off the parking lights when the driver removes the ignition key and opens the driver- side door.
Page 148 Features of your vehicle OAM049041 OAM049042 OFS040084 Auto light position (if equipped) Parking light position ( Headlight position ( When the light switch is in the AUTO When the light switch is in the park- When the light switch is in the head- light position, the taillights and head- ing light position (1st position), the light position (2nd position) the head,...
Page 149: High Beam Operation
Features of your vehicle WARNING - High beams Do not use high beam when there are other vehicles. Using high beam could obstruct the other driver's vision. OAM049044 OAM049043 High beam operation To flash the headlights, pull the lever towards you. It will return to the nor- To turn on the high beam headlights, (low-beam) position...
Page 150: Turn Signals And Lane Change Signals
Features of your vehicle If an indicator stays on and does not flash or if it flashes abnormally, one of the turn signal bulbs may be burned out and will require replace- ment. If an indicator flash is abnormally quick or slow, a bulb may be burned out or have a poor electrical connec- tion in the circuit.
Page 151: Wipers And Washers
Features of your vehicle WIPERS AND WASHERS A : Wiper speed control (front) Front Rear (if equipped) (5 door) · HI – High wiper speed · LO – Low wiper speed · INT – Intermittent wipe · AUTO* – Automatic control wipe ·...
Page 152 Features of your vehicle Windshield wipers To vary the speed setting, turn the speed control knob (1). Operates as follows when the igni- If the wiper switch is set in AUTO tion switch is turned ON. mode when the ignition switch is ON, MIST : For a single wiping cycle, the wiper will operate once to per- move the lever upward and...
Page 153 Features of your vehicle Windshield washers CAUTION CAUTION - Wiper - Washer In the OFF position, pull the lever position pump gently toward you to spray washer When washing the vehicle, set To prevent possible damage to fluid on the windshield and to run the the wiper switch in the off posi- the washer pump, do not oper- wipers 1-3 cycles.
Page 154 Features of your vehicle CAUTION - Wipers & windshields • To prevent possible damage to the wipers or windshield, do not operate the wipers when the windshield is dry. • To prevent damage to the wiper blades, do not use gaso- line, kerosene, paint thinner, or other solvents on or near them.
Page 155: Interior Light
Features of your vehicle INTERIOR LIGHT Do not use the interior lights for extended periods when the engine is not running. It may cause battery discharge. WARNING - Interior light Do not use the interior lights when driving in the dark. The glare from the interior lights may obstruct your view and cause an accident.
Page 156: Luggage Room Lamp
Features of your vehicle ■ 4 door ORBC040059 ■ 5 door OLM049105 OUB041100 Vanity mirror lamp Glove box lamp (if equipped) The glove box lamp comes on when the glove box is opened. Push the switch to turn the light on or off.
Page 157: Defroster
Features of your vehicle DEFROSTER activate rear window CAUTION - Conductors defroster, press the rear window defroster button located in the center To prevent damage to the con- facia switch panel. The indicator on ductors bonded to the inside the rear window defroster button illu- surface of the rear window, minates when the defroster is ON.
Page 158: Manual Climate Control System
Features of your vehicle MANUAL CLIMATE CONTROL SYSTEM 1. Fan speed control knob 2. Mode selection knob 3. Temperature control knob 4. Air conditioning button (if equipped) 5. Rear window defroster button 6. Air intake control button OUB041103 4 87...
Page 159 Features of your vehicle Heating and air conditioning 1.Start the engine. 2.Set the mode to the desired posi- tion. To improve the effectiveness of heating and cooling : - Heating: - Cooling: 3.Set the temperature control to the desired position. 4.Set the air intake control to the out- side (fresh) air or recirculated air position.
Page 160 Features of your vehicle Face-Level (B, D) Floor/Defrost-Level (A, C, D, E) Most of the air flow is directed to the Air flow is directed toward the upper floor and the windshield with a small body and face. Additionally, each amount directed to the side window outlet can be controlled to direct the defrosters.
Page 161 Features of your vehicle OUB041106 OUB041107 OUB041108 Temperature control MAX A/C-Level (B, D) (if equipped) Instrument panel vents The MAX A/C mode is used to cool The outlet vents can be opened or The temperature control knob allows the inside of the vehicle faster. closed separately using the thumb- you to control the temperature of the wheel.
Page 162 Features of your vehicle Recirculated air position Prolonged operation of the heater in the recirculated air position (without The indicator light on the air conditioning selected) may cause button illuminates when fogging of the windshield and side the recirculated air posi- windows and the air within the pas- tion is selected.
Page 163 Features of your vehicle WARNING - Reduced visibility Continuous use of the climate control system in the recirculat- ed air position may allow humidity to increase inside the vehicle which may fog the glass and obscure visibility. OUB041110 OUB043208 Fan speed control To turn off the blowers The ignition switch must be in the ON To turn off the blowers, turn the fan...
Page 164 Features of your vehicle System operation Operation Tips • To prevent dust or unpleasant Ventilation fumes from entering the vehicle 1.Set the mode to the position. through the ventilation system, 2.Set the air intake control to the out- temporarily set the air intake con- side (fresh) air position.
Page 165 Air conditioning (if equipped) • During air conditioning system CAUTION - Excessive operation, you may occasionally Kia Air Conditioning Systems are notice a slight change in engine filled with environmentally friendly speed as the air conditioning com- While using the air conditioning R-134a refrigerant.
Page 166 Kia dealer. technicians." air position is selected. If this hap- The air conditioning system should pens, have the climate control air fil- be serviced by an authorized Kia ter replaced by an authorized Kia The air conditioning system should dealer. dealer.
Page 167: Windshield Defrosting And Defogging
Features of your vehicle WINDSHIELD DEFROSTING AND DEFOGGING • For maximum defrosting, set the WARNING - Windshield temperature control to the extreme heating right/hot position and the fan speed control to the highest speed. Do not use the posi- tion during cooling operation in •...
Page 168 Features of your vehicle Defogging logic To reduce the probability of fogging up inside of the windshield, the air intake or air conditioning are con- trolled automatically according to certain conditions such as position. To cancel or return to the defogging logic, do the followings.
Page 169: Storage Compartments
Features of your vehicle STORAGE COMPARTMENT These compartments can be used to ■ Type A store small items. To avoid possible theft, do not leave valuables in the storage compart- ment. Always keep the storage compart- ment covers closed while driving. Do not attempt to place so many items in the storage compartment that the storage compartment cover can not...
Page 170: Cool Box
Features of your vehicle ✽ ✽ NOTICE ■ 4 door Do not put perishable food in the cool box because it may not main- tain the necessary consistent tem- perature to keep the food fresh. ✽ ✽ NOTICE If the temperature control knob is in the warm or hot position, warm or hot air will flow into the glove box.
Page 171: Luggage Tray
Features of your vehicle If necessary, contact your authorized Kia dealer to obtain a luggage net. To prevent damage to the goods or the vehicle, care should be taken when carrying fragile or bulky objects in the luggage compartment. WARNING...
Page 172: Increase Cargo Space
Features of your vehicle OUB041148 OUB041151 OUB041149 OUB041150 OUB041178 Increase cargo space (if equipped) If you want to increase cargo space, 1.Grasp the handle on the top of the cover and lift it 2.Fold the rear part of the luggage tray board frontward 3.Lift the luggage tray board hinge and pull it to the end of sliding slot.
Page 173: Interior Features
“ready” position. Putting lit cigarettes or matches in an ashtray with other com- If it is necessary to replace the ciga- bustible materials may cause a rette lighter, use only a genuine Kia fire. replacement or its approved equiva- lent.
Page 174: Cup Holder
Features of your vehicle ■ Type A Cup holder WARNING - Hot liquids Do not place uncovered cups of hot liquid in the cup holder while the vehicle is in motion. If the hot liquid spills, you may burn yourself. Such a burn to the driver could lead to loss of control of the vehicle.
Page 175: Photo Frame
Features of your vehicle CAUTION - Vanity mirror lamp If you use the vanity mirror lamp, turn off the lamp before return the sunvisor to its origi- nal position. It could result in battery discharge and possible sunvisor damage. OUB041144N OVG049174 Photo frame (if equipped) Sunvisor...
Page 176: Power Outlet
Features of your vehicle Adjust the air-conditioner or heater to the lowest operating level when using the power outlet. Close the cover when not in use. Some electronic devices can cause electronic interference when plugged into a vehicle’s power outlet. These devices may cause excessive audio static and malfunctions in other elec- tronic systems or devices used in...
Page 177: Digital Clock And Calendar
Features of your vehicle Digital clock and calendar With audio on (if equipped) 1.Press the [SETUP] or [Clock] but- ton (1) until the clock adjust mode Whenever the battery terminals or displayed. related fuses are disconnected, you must reset the clock and the calen- 2.Set the clock by turning the knob dar.
Page 178: Clothes Hanger
Kia recommends that only Do not install aftermarket floor the Kia floor mat designed for use in mats that are not capable of your vehicle be installed. being securely attached to the vehicle's floor mat anchors.
Page 179: Navigation System
Features of your vehicle OUB041182N Navigation system (if equipped) The navigation system ascertains the present position of your vehicle by using information from satellites and guides you to the place you assign as the destination. Detailed information for the naviga- tion system is described in a sepa- rately supplied manual.
Page 180: Audio System
Features of your vehicle AUDIO SYSTEM If you install an aftermarket HID CAUTION - Antenna head lamp, your vehicle’s audio and electronic device may malfunction. Before entering a place with a low height clearance or a car wash, remove the antenna by rotating it counter-clockwise.
Page 181: Steering Wheel Audio Control
Features of your vehicle MODE (3) If the SEEK button is pressed for less than 0.8 second, it will work as fol- Press the button to select Radio or lows in each mode. CD (compact disc). RADIO mode MUTE (4) It will function as the PRESET STA- •...
Page 182: Aux, Usb And Ipod
When a strong radio signal has arately. Connectivity may require use reached your vehicle, the precise of the Kia accessory cable. engineering of your audio system ensures the best possible quality When using a portable audio device reproduction.
Page 183 Features of your vehicle AM reception FM radio station JBM002 JBM003 JBM004 AM broadcasts can be received at FM broadcasts are transmitted at • Fading - As your vehicle moves away from the radio station, the greater distances than FM broad- high frequencies and do not bend to signal will weaken and sound will casts.
Page 184 Features of your vehicle Satellite radio reception • If you are driving on a mountain road where is the signal blocked by You may experience difficulties in mountains. ® receiving SiriusXM Satellite Radio signals in the following situations. JBM005 • Station Swapping - As a FM signal weakens, another more powerful signal near the same frequency SATELITE2...
Page 185 Features of your vehicle Using a cellular phone or a two- Care of disc (if equipped) • Keep CDs in their cases after use way radio to protect them from scratches or • If the temperature inside the car is dirt.
Page 186 Features of your vehicle NOTE: Order of playing files (folders) : 1. Song playing order : sequentially. 2. Folder playing order : ❋ If no song file is contained in the folder, that folder is not dis- played. 4 115...
Page 187 Features of your vehicle ❋No logo will be shown if the Bluetooth Wireless Technology feature is not supported. ®...
Page 188 Features of your vehicle ❈ In Setup>Display, the radio pop up SYSTEM CONTROLLERS SEEK TRACK screen will be displayed when AND FUNCTIONS • Radio Mode Automatically [Mode Pop up] is turned searches for broadcast frequen- When the pop up screen is dis- cies.
Page 189 Features of your vehicle - Press and hold the key (over 0.8 MENU seconds): Previews the broad- • Displays menus for the current casts saved in Preset mode. for 5 seconds each. ❈ iPod ® List : Move to parent category ❈...
Page 190 Features of your vehicle (SIRIUS Satellite Radio) • Changes to SIRIUS Satellite Radio mode. • Each time the key is pressed, the mode is changed in order of SAT1 ➟ SAT2 ➟ SAT3 FM/AM • Changes to FM/AM mode. • Each time the key is pressed, the ➟...
Page 191 Features of your vehicle DISPLAY SETTINGS Mode Pop up [Mode Pop up] Changes selection mode Press key Select SETUP [Display] through TUNE knob or • During On state, press the RADIO key to display the mode MEDIA key Select menu through change pop up screen.
Page 192 Features of your vehicle SOUND SETTINGS Sound Settings Virtual Sound This menu allows you to set the The PoewrBass, PowerTreble, and ‘Bass, Middle, Treble’ and the Sound Surround can be set. Press key Select SETUP Fader and Balance. Select [Virtual Sound] Set menu [Sound] through TUNE knob or Select...
Page 193 Features of your vehicle Speed Dependent Volume Voice Recognition Volume Control Adjusts voice recognition volume. This feature is used to automatically Select [Voice Recognition Vol.] Set control the volume level according to volume of TUNE knob the speed of the vehicle. Select [SDVC] Set in 4 levels [Off/ Low/Mid/High] of TUNE knob...
Page 194 Features of your vehicle ❈ Adjust the number currently in CLOCK SETTINGS Clock Settings focus to make the settings and This menu is used to set the time. press the TUNE knob to move to Select [Clock Settings] Set through the next setting.
Page 195 Features of your vehicle SYSTEM SETTINGS Memory Information • Expert : This mode is for expert users and omits some information Displays currently used memory and during voice command operation. total system memory. (When using Expert mode, guid- Press key Select SETUP Select [Memory Information] OK ance instructions can be heard...
Page 196 Features of your vehicle RADIO : FM, AM OR SIRIUS Preset SEEK Selecting through manual search Press the RADIO Turn the TUNE knob left/right to • Briefly pressing the key (under 0.8 adjust the frequency. seconds): Plays the frequency saved in the corresponding key. •...
Page 197 Features of your vehicle MENU Within key are the A.Store MENU (Auto Store). A.Store Press the key Set [A.Store] MENU through TUNE knob or key. Saves broadcasts with superior reception to keys. If no frequencies are received, then the most recently received frequency will be broadcast.
Page 198 Features of your vehicle SIRIUS Satellite Radio information (if equipped) Satellite Radio channels: • Terrain: Hills, mountains, tall build- For information on extended sub- ings, bridges, tunnels, freeway over- scription terms, contact SIRIUS at SIRIUS Satellite Radio has over 130 passes, parking garages, dense 1-888-539-7474.
Page 199 Using SIRIUS Satellite Radio in order for the radio to receive the information not available in all mar- activation signal. Your Kia vehicle is equipped with a 3 kets. See siriusxm.com/traffic for details. Sirius, XM and all related month complimentary period of SIR-...
Page 200 • Shortly pressing the key (under 0.8 screen. antenna or antenna cable is bro- seconds): Previews each broad- ken or unplugged. Please consult cast for 5 seconds each with your Kia dealership. ❈ Press the Preset key again to SCAN 2. Acquiring Signal...
Page 201 Features of your vehicle Menu USING YOUR USB DEVICE • An encrypted MP3 PLAYER is not recognizable. Select category menu through the • When using an external USB • Depending on the condition of the TUNE knob Press the MENU device, make sure the device is not external USB device, the connect- Select [ Info] through the...
Page 202 Features of your vehicle It is recommended to disconnect (Continued) CAUTION - USB Jack the external USB device when the • Some USB devices such as MP3 Damage audio is turned off or in modes Player/Cellular phone/Digital cam- other than USB. •...
Page 203 Features of your vehicle BASIC METHOD OF USE : • [Media Display] : The screen dis- Random play info can be changed to While song (file) is playing Audio CD / MP3 CD / USB / Album/Artist/ Song name. (RDM) key iPod / My Music ®...
Page 204 Features of your vehicle MP3 CD, USB, iPod ® mode: ALL Scan Searching Songs (File) RDM on screen • Turning TUNE knob : Searches While song (file) is playing SCAN • All Random (pressing and holding the for songs (files) key (over 0.8 seconds)): Plays all files •...
Page 205 Features of your vehicle MENU : Audio CD Information Press the CD MP3 mode MENU Press the key Set [ Info] MENU Repeat, Random, through the TUNE knob or Information features. key to display information of the cur- rent song. ❈...
Page 206 Features of your vehicle MENU : MP3 CD / USB Folder Repeat Copy Press the CD MP3 mode Press the key Set [ F.RPT] Press the key Set [ Copy] MENU MENU MENU to set the Repeat, Folder Random, through the TUNE knob or through the TUNE knob or...
Page 207 Features of your vehicle ® MENU : iPod All Random - iPod Touch 1st~2nd generation ® • The order of search or playback of In iPod mode, press the MENU Press the key Set [ A.RDM] ® MENU songs in the iPod ®...
Page 208 Features of your vehicle • If your iPhone ® is connected to both • When not using iPod ® with car Bluetooth ® Wireless audio, detach the iPod ® cable from Technology and USB, the sound iPod ® . Otherwise, iPod ®...
Page 209 Features of your vehicle MENU : My Music Mode Information Delete All In My Music mode, press the Press the key Set [ Info] Press the key Set [ Del.All] MENU MENU MENU through the TUNE knob or key to set the Repeat, Random, through the TUNE knob or key.
Page 210 Features of your vehicle My Music • Even if memory is available, a • Fully insert the AUX cable into the AUX is used to play external MEDIA maximum of 6,000 songs can be AUX terminal for use. currently connected with the AUX stored.
Page 211 AUDIO owned by Bluetooth SIG, Inc. and [Audio Streaming] of Phone is turned any use of such marks by Kia is What is Bluetooth Wireless under license. Other trademarks ®...
Page 212 Features of your vehicle Starting Bluetooth Wireless Using the Bluetooth Wireless ® ® Technology Audio Technology audio features • Press the key to change MEDIA mode order ➟ ➟ ➟ ➟ Music Audio. • If BT Audio is selected, Bluetooth ®...
Page 213 Features of your vehicle PHONE Making a call using the • Check call history and making call Steering-wheel mount controls ➀ Shortly press (under 0.8 seconds) (if equipped) key on the steering Before using the Bluetooth Wireless ® remote controller . Technology phone features •...
Page 214 Bluetooth SIG, lnc. and any use of ® What is Bluetooth that may lead to an accident, such marks by Kia is under license. severe personal injury, and • Bluetooth refers to a short-dis- ®...
Page 215 Features of your vehicle When connecting a Bluetooth ® • Park the vehicle when connecting the head unit with the mobile Phone phone. • Bluetooth connection ® • Before connecting the head unit become intermittently discon- with the mobile phone, check to nected in some mobile phones.
Page 216 Bluetooth SIG, Inc. and any use of such marks by Kia is under license. Other trademarks and trade names are those of their respective owners. A Bluetooth ®...
Page 217 Features of your vehicle [Non SSP supported device] Pairing Key / PHONE on the Steering Remote (SSP: Secure Simple Pairing) Controller 4. After a few moments, a screen is displayed where the passkey is entered. When No Devices have been Hear, enter the passkey “0000”...
Page 218 Blackberry phones) may offer an option to allow acceptance of all future Bluetooth connection requests default." "Visit http://www.kia.com/#/bluetooth for additional information on pairing your Bluetooth-enabled mobile phone, and to view a phone compatibility list. • If Bluetooth Wireless Technology ®...
Page 219 Features of your vehicle Pairing through [PHONE] • Bluetooth Wireless Technology • Only Bluetooth ® Wireless ® features supported within the vehi- Technology Handsfree Setup cle are as follows. Some features Bluetooth audio related features may not be supported depending are supported.
Page 220 Features of your vehicle • After pairing is complete, a con- Connecting a Device From the paired phone list, select the tacts download request is sent device you want to connect and once to the mobile phone. Some select [Connect]. Press key Select mobile phones may require confir-...
Page 221 Features of your vehicle Changing Priority From the paired phone list, select • Priority icon will be displayed when the phone you want to switch to the the selected phone is set as a pri- highest priority, then select [Change ority phone.
Page 222 Features of your vehicle Disconnecting a Device Deleting a Device • When deleting the currently con- nected device, the device will auto- matically be disconnected to pro- Press key Select Press key Select SETUP SETUP ceed with the deleting process. [Phone] Select [Paired Phone List] [Phone] Select [Paired Phone List] •...
Page 223 Features of your vehicle • If you select the [Call History] but- Answering Calls USING Bluetooth Wireless ® ton but there is no call history data, Technology a prompt is displayed which asks to Answering a Call download call history data. Phone Menu Screen Answering a call with a Bluetooth ®...
Page 224 Features of your vehicle • When an incoming call pop-up is Favorites Call History displayed, most Audio and SETUP Press the Select PHONE mode features are disabled. Only [Favorites] Press the Select [Call the call volume will operate. PHONE History] •...
Page 225 Features of your vehicle Contacts • Up to 1,000 contacts saved in your device authorization upon attempt- Bluetooth Wireless Technology ing to download contacts. If down- ® phone can be downloaded into the loading does not normally occur, Press key Select Bluetooth PHONE car contacts.
Page 226 Press key Select SETUP Bluetooth SIG, Inc. and any use of [Phone] Select [Pair Phone] such marks by Kia is under license. Other trademarks and trade names are those of their respective owners. A Bluetooth enabled cell phone is ®...
Page 227 Features of your vehicle 1) Connect/Disconnect Phone Downloading Contacts Auto Download (Contacts) Connect/ disconnects currently Press key Select Press key Select SETUP SETUP selected phone [Phone] Select [Contacts Download] [Phone] Select [Auto Download] 2) Change Priority : Sets currently selected phone to highest connec- tion priority 3) Delete : Deletes the currently selected phone...
Page 228 Features of your vehicle Audio Streaming Outgoing Volume Turning Bluetooth System Off Press key Select Press key Select Press the key Select SETUP SETUP SETUP [Phone] Select [Outgoing Volume] [Phone] Select [Bluetooth System [Phone] Select [Audio Streaming] Off] Bluetooth Once Wireless ®...
Page 229 Features of your vehicle Voice Recognition (Continued) - When driving on rugged and uneven roads • When using the voice recognition - During severe rain (heavy rains, feature, only commands listed windstorms) within the user's manual are sup- ported. • Phone related voice commands can be used only when a •...
Page 230 Features of your vehicle VOICE RECOGNITION If prompt feedback is in [ON], then Contact List Best Practices the system will say “Please say a 1)Do not store single-name entries command after the beep (BEEP)” Using Voice Recognition (e.g., “Bob”, “Mom”, “Kim”, etc.). •...
Page 231 RECOGNITION Contact Tips: While prompt message is being stat- ed Shortly press the key on the The Kia Voice Recognition System steering remote controller (under 0.8 While Voice Recognition is operating may have difficulty understanding seconds) Press and hold the...
Page 232 Features of your vehicle Illustration on using voice commands More Help Here are some examples of mode commands. • Starting voice command. You can say a radio type like 'FM', 'AM', or 'Satellite'. Shortly pressing the key (under 0.8 seconds): You can also say a media source like 'USB', 'My Music', or 'iPod'.
Page 233: Voice Command List
Features of your vehicle Voice Command List • Common Commands: These commands can be used in most operations. (However a few commands may not be available during certain operations) Command Function Command Function • More Help Provides guidance on commands that can be When listening to the radio, displays the next ➟...
Page 234 Features of your vehicle Command Function Command Function SIRIUS (Satellite) Displays the selected SIRIUS screen. My Music Plays the music saved in My Music. AUX (Auxiliary) Plays the connected external device. SIRIUS Channel Plays the selected SIRIUS channel. Bluetooth ® Audio Plays the music saved in connected Bluetooth ®...
Page 235 Features of your vehicle • FM/AM radio commands: Commands available during • Satellite radio commands: Commands that can be FM, AM radio operation. used while listening to Satellite Radio. Command Function Command Function Preset 1~6 Plays the broadcast station saved in Preset 1~6. Channel 0~223 Plays the selected Satellite Radio channel.
Page 236 Features of your vehicle • Audio CD commands: Commands available during • MP3 CD / USB commands: Commands available dur- Audio CD operation. ing USB and MP3 CD operation. Command Function Command Function Random Randomly plays the tracks within the CD. Random Randomly plays the files within the current folder.
Page 237 Features of your vehicle • iPod Commands: Commands available during iPod • My Music Commands: Commands available during ® ® operation. My Music operation. Command Function Command Function Random Randomly plays the songs within the current Random Randomly plays all saved files. category.
Page 238 Command Operation ® The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Kia is under license. A Command Function ® Bluetooth enabled cell phone is required to use Play Plays the currently paused song.
Page 239: Driving Your Vehicle
Driving your vehicle Before driving......5-3 Special driving conditions ....5-48 .
Page 240 1. Close all windows. State of California to cause can- possible by an authorized Kia dealer. 2. Open side vents. cer and birth defects and repro- 3. Set the air intake control at ductive harm.
Page 241: Before Driving
Driving your vehicle BEFORE DRIVING Before entering vehicle Before starting WARNING - Distracted • Be sure that all windows, outside • Close and lock all doors. driving mirror(s), and outside lights are • Position the seat so that all con- Focus on the road while driving.
Page 242 Driving your vehicle WARNING WARNING - Driving - Fire risk while intoxi- When you intend to park or stop cated the vehicle with the engine on, be careful not to depress the Do not drive while intoxicated. accelerator pedal for a long Drinking and driving is danger- period of time.
Page 243: Key Positions
Driving your vehicle KEY POSITIONS ACC (Accessory) The steering wheel is unlocked and electrical accessories are operative. If difficulty is experienced turning the ignition switch to the ACC position, turn the key while turning the steer- ing wheel right and left to release the tension.
Page 244 Driving your vehicle WARNING - Ignition switch Never turn the ignition switch to LOCK or ACC while the vehicle is moving. This would result in loss of directional control and braking function, which could cause an accident. WARNING - Steering wheel Never reach for any controls through the steering wheel...
Page 245: Engine Start/Stop Button
Driving your vehicle ENGINE START/STOP BUTTON (IF EQUIPPED) ENGINE START/STOP button In an emergency situation while the vehicle is in motion, you are able to position turn the engine off and to the ACC position by pressing the ENGINE START/STOP button for more than 2 seconds or 3 times successively within 3 seconds.
Page 246 Driving your vehicle ACC(Accessory) START/RUN Orange Blue Not illuminated Press the ENGINE START/STOP Press the ENGINE START/STOP To start the engine, depress the button while it is in the OFF position button while it is in the ACC position brake pedal and press the ENGINE without depressing the brake pedal.
Page 247 Driving your vehicle If you leave the ENGINE START/ STOP button in the ACC or ON posi- tion for a long time, the battery will discharge. WARNING - Starting vehicle Never press ENGINE START/STOP button while the vehicle is in motion except in an emergency.
Page 248: Starting The Engine
Driving your vehicle STARTING THE ENGINE 3. Turn the ignition switch to START CAUTION - Starter WARNING - Proper and hold it there until the engine footwear starts (a maximum of 10 seconds), Do not engage the starter for then release the key. more than 10 seconds.
Page 249 Driving your vehicle 5.Do not wait for the engine to warm WARNING - Unintended up while the vehicle remains sta- vehicle movement tionary. Start driving at moderate engine Never leave the smart key in the speeds. (Steep accelerating and vehicle with children or vehicle decelerating should be avoided.) occupants who are unfamiliar with the vehicle operation.
Page 250 Driving your vehicle Do not press the ENGINE START/ STOP button for more than 10 sec- onds except when the stop lamp fuse is blown. OUB053003 • If the battery is weak or the smart key does not work correctly, you can start the engine by pressing the engine start/stop button with the smart key.
Page 251: Manual Transaxle
Driving your vehicle MANUAL TRANSAXLE (IF EQUIPPED) Manual transaxle operation CAUTION - Downshifting The manual transaxle has 6 forward Do not downshift more than 2 gears. gears or downshift the gear This shift pattern is imprinted on the when the engine is running at shift knob.
Page 252 Driving your vehicle • During cold weather, shifting may CAUTION WARNING - Incline be difficult until the transaxle lubri- parking cant is warmed up. This is normal • To avoid premature clutch and not harmful to the transaxle. wear and damage, do not Before leaving the driver’s seat, drive with your foot resting on •...
Page 253 Driving your vehicle Using the clutch Good driving practices • Exercise extreme caution when driving on a slippery surface. Be The clutch should be depressed all • Never take the vehicle out of gear especially careful when braking, the way to the floor before shifting, and coast down a hill.
Page 254: Automatic Transaxle
Driving your vehicle AUTOMATIC TRANSAXLE (IF EQUIPPED) Automatic transaxle operation The automatic transaxle has 6 for- ward speeds and one reverse speed. The individual speeds are selected Shift lever automatically, depending on the Button position of the shift lever. + (UP) ✽...
Page 255 Driving your vehicle For smooth operation, depress the Transaxle ranges CAUTION - Transaxle brake pedal when shifting from N The indicator light in the instrument (Neutral) to a forward or reverse avoid damage your cluster displays the shift lever posi- gear.
Page 256 Driving your vehicle R (Reverse) D (Drive) Use this position to drive the vehicle This is the normal forward driving backward. position. The transaxle will automati- cally shift through 6-gear + (UP) sequence, providing the best fuel CAUTION - Shifting economy and power.
Page 257 Driving your vehicle Up (+) : Push the lever forward once • To maintain the required levels of to shift up one gear. vehicle performance and safety, the system may not execute cer- Down (-) : Pull the lever backwards tain gearshifts when the shift lever once to shift down one is operated.
Page 258 3.Move the shift lever. may be heard. This is a normal con- 4.Have your vehicle inspected by an dition. authorized Kia dealer immediately. WARNING - Shifting from park Always fully depress the brake pedal before and while shifting...
Page 259 Driving your vehicle Ignition key interlock system Good driving practices Driving up a steep grade from a (if equipped) standing start • Never move the shift lever from P The ignition key cannot be removed To drive up a steep grade from a (Park) or N (Neutral) to any other unless the shift lever is in the P standing start, depress the brake...
Page 260: Brake System
Driving your vehicle BRAKE SYSTEM Power brakes Wet brakes may impair the vehicle’s CAUTION - Brake pedal ability to safely slow down; the vehi- Your vehicle has power-assisted cle may also pull to one side when Do not drive with your foot rest- brakes that adjust automatically the brakes are applied.
Page 261: Parking Brake
Driving your vehicle In the event of brake failure Disc brakes wear indicator WARNING - Brake wear If service brakes fail to operate while When your brake pads are worn and the vehicle is in motion, you can new pads are required, you will hear Do not ignore high pitched wear make an emergency stop with the a high-pitched warning sound from...
Page 262 Driving your vehicle CAUTION - Parking brake Driving with the parking brake applied will cause excessive brake pad (or lining) and brake rotor wear. OUB051016 OUB051017 Releasing the parking brake Parking brake To release the parking brake, first Applying the parking brake apply the foot brake and pull up the To engage the parking brake, first parking...
Page 263 Driving your vehicle If at all possible, stop driving the WARNING - Parking vehicle immediately. If that is not pos- brake use sible, use extreme caution while operating the vehicle and only con- All vehicles should always have tinue to drive the vehicle until you the parking brake fully engaged can reach a safe location or repair when parked to avoid inadver-...
Page 264: Anti-Lock Brake System (Abs)
Driving your vehicle ✽ ✽ NOTICE Anti-Lock Brake System (ABS) The ABS continuously senses the speed of the wheels. If the wheels (if equipped) A clicking sound may be heard in are going to lock, the ABS system the engine compartment when the ABS (or ESC) will not prevent acci- repeatedly modulates the hydraulic vehicle begins to move after the...
Page 265: Electronic Stability Control (Esc)
Contact an authorized brakes on individual wheels and at the same time. This happens Kia dealer as soon as possible. intervenes with the engine manage- because of the low battery voltage. It ment system to stabilize the vehicle.
Page 266 Driving your vehicle Electronic stability control (ESC) will When you apply your brakes under ESC operation not prevent accidents. Excessive conditions which may lock the ESC ON condition speed in turns, abrupt maneuvers wheels, you may hear a “tik-tik’’ • When the ignition is turned and hydroplaning on wet surfaces sound from the brakes, or feel a cor- ON, ESC and ESC OFF...
Page 267 Driving your vehicle When operating ESC operation off ■ ESC indicator light When the ESC is in opera- ESC OFF state tion, ESC indicator light • To cancel ESC operation, blinks. press the ESC OFF button • When Electronic (ESC OFF indicator light Stability Control is operat- illuminates).
Page 268 Driving your vehicle ESC OFF usage WARNING WARNING - Electronic - Operating When driving stability control • It’s a good idea to keep the ESC Drive carefully even though Never press the ESC OFF but- turned on for daily driving whenev- your vehicle has Electronic ton while ESC is operating.
Page 269: Vehicle Stability Management (Vsm)
Driving your vehicle Hill-start assist control (HAC) Vehicle stability management WARNING - Maintaining (VSM) Hill start Assist Control is a comfort Brake Pressure on Incline function. The intent is to prevent the This system provides further HAC does not replace the need vehicle from rolling backwards from enhancements to vehicle stability to apply brakes while stopped on...
Page 270 ( ) or ESC warning light instrument cluster remains on, take your vehi- cle to an authorized Kia dealer and have the system checked. • The VSM is designed to function above approximately 9 mph (15 km/h) on curves.
Page 271 When replacing tires authorized Kia dealer for assis- wheels, make sure they are the tance. same size as the original tires • Don't coast down hills with the and wheels installed.
Page 272 Driving your vehicle • Be cautious when parking on a hill. • Do not hold the vehicle on the Firmly engage the parking brake upgrade with accelerator and place the shift lever in P (auto- pedal. This can cause the transaxle matic transaxle) or in first or to overheat.
Page 273: Cruise Control System
Driving your vehicle CRUISE CONTROL SYSTEM (IF EQUIPPED) ✽ ✽ NOTICE ■ Type A The cruise control system allows you to program the vehicle to maintain a During normal cruise control opera- constant speed without depressing tion, when the SET switch is activat- the accelerator pedal.
Page 274 Driving your vehicle ■ Type A 2. Accelerate to the desired speed, On a steep grade, the vehicle may which must be more than 25 mph slow down or speed up slightly while (40 km/h). going downhill. OUB051048 ■ Type B OUB051044 3.
Page 275 Driving your vehicle ■ Type A ■ Type A • Move the lever (1) up (to RES+) and release it immediately. The cruising speed will increase by 1.0 mph (1.6 km/h ) each time the lever is operated in this manner. OUB051047 OUB051048 ■...
Page 276 Driving your vehicle ■ Type A • Move the lever (1) down (to SET-) • Decrease the vehicle speed lower and release it immediately. The than the memory speed by 9 mph cruising speed will decrease by 1.0 (15 km/h). mph (1.6 km/h) each time the lever •...
Page 277 Driving your vehicle ■ Type A If any method other than the To turn cruise control off, do CRUISE ON-OFF switch was used one of the following: to cancel cruising speed and the sys- • Press the CRUISE ON-OFF button tem is still activated, the most recent (the CRUISE indicator light in the set speed will automatically resume...
Page 278 Driving your vehicle ISG (IDLE STOP AND GO) SYSTEM (IF EQUIPPED) ■ Type A Your vehicle may be equipped with The engine will stop and the green the ISG system, which reduces fuel AUTO STOP indicator ( ) on the consumption by automatically shut- instrument cluster will illuminate.
Page 279 Driving your vehicle ■ Type A Auto start To restart the engine from idle stop mode The engine restarts from the idle stop mode when: • Releasing the brake pedal • Moving the shift lever to R (Reverse) position or sports mode OUB051020 OUB051006 with the brake pedal depressed...
Page 280 Driving your vehicle - The fan speed is in the highest Condition of ISG system oper- position when the air conditioning is ation The ISG system will operate - Engine is turned off by Auto Stop under the following condition: for a long time.
Page 281 If the ISG OFF button light is not turned off by pressing the ISG OFF button again or if the ISG system continuously does not work correctly, please contact an authorized Kia dealer as soon as possible. OUB051006/OUB051059 ■ Type B...
Page 282 Driving your vehicle ✽ ✽ NOTICE If the AGM battery is reconnected or replaced, ISG function will not operate immediately. If you want to use the ISG function, the battery sensor needs to be cali- brated for approximately 4 hours with the ignition off and then, turn the engine on and off 2 or 3 times.
Page 283: Active Eco System
Driving your vehicle ACTIVE ECO SYSTEM (IF EQUIPPED) • If Active ECO is turned off, it will Limitation of Active ECO oper- return to the normal mode. ation: If the following conditions occur while Active ECO is operating, the system operation is limited even though there is no change in the ECO indi- cator.
Page 284: Economical Operation
Driving your vehicle ECONOMICAL OPERATION Your vehicle's fuel economy depends • Don't "ride" the brake pedal. This • Keep your vehicle in good condi- mainly on your style of driving, where can increase fuel consumption and tion. For better fuel economy and you drive and when you drive.
Page 285 Driving your vehicle • Remember, your vehicle does not • Use your air conditioning sparingly. WARNING - Engine off require extended warm-up. After The air conditioning system is during the engine has started, allow the operated by engine power so your engine to run for 10 to 20 seconds fuel economy is reduced when you motion...
Page 286: Special Driving Conditions
Driving your vehicle SPECIAL DRIVING CONDITIONS Hazardous driving conditions Do not pump the brake pedal on a Rocking the vehicle vehicle equipped with ABS. When hazardous driving conditions If it is necessary to rock the vehicle • If stalled in snow, mud, or sand, are encountered such as water, to free it from snow, sand, or mud, use second gear.
Page 287: Smooth Cornering
Driving your vehicle CAUTION - Spinning tires Do not spin the wheels, espe- cially at speeds more than 35 mph (56 km/h). Spinning the wheels at high speeds when the vehicle is stationary could cause a tire to overheat which could result in tire damage.
Page 288: Driving In The Rain
Driving your vehicle • Adjust your mirrors to reduce the • If your tires are not in good condi- glare from other driver's head- tion, making a quick stop on wet lights. pavement can cause a skid and possibly lead to an accident. Be •...
Page 289: Driving Off-Road
Driving your vehicle Driving off-road Fuel, engine coolant and engine WARNING - Under/over Drive carefully off-road because your inflated tires High speed travel consumes more vehicle may be damaged by rocks or Always check the tires for prop- fuel than urban motoring. Do not for- roots of trees.
Page 290: Winter Driving
Driving your vehicle WINTER DRIVING Snowy or Icy conditions Snow tires If you mount snow tires on your vehi- To drive your vehicle in deep snow, it cle, make sure they are radial tires of may be necessary to use snow tires the same size and load range as the or to install tire chains on your tires.
Page 291 Driving your vehicle Chain installation CAUTION - Snow chains When installing chains, follow the Make sure the snow chains are manufacturer's instructions the correct size and type for mount them as tightly as you can. your tires. Incorrect snow Drive slowly with chains installed. If chains can cause damage to the you hear the chains contacting the vehicle body and suspension...
Page 292 • Stop driving and retighten the the battery and cables as described chains any time you hear them in section 7. The level of charge in hitting the vehicle. your battery can be checked by an authorized Kia dealer or a service station.
Page 293: Trailer Towing
Don't let ice and snow accu- tions on the container. Window wash- mulate underneath er anti-freeze is available from an authorized Kia dealer and most auto Under some conditions, snow and parts outlets. Do not use engine ice can build up under the fenders coolant or other types of anti-freeze and interfere with the steering.
Page 294: Vehicle Load Limit
Driving your vehicle VEHICLE LOAD LIMIT Tire and loading information label The label located on the driver's door sill gives the original tire size, cold tire pressures recommended for your vehicle, the number of people that can be in your vehicle and vehicle capacity weight.
Page 295 Driving your vehicle Seating capacity: Steps For Determining Correct 5.Determine the combined weight of Load Limit - luggage and cargo being loaded Total : 5 persons on the vehicle. That weight may not (Front seat : 2 persons, 1.Locate the statement "The com- safely exceed the available cargo Rear seat : 3 persons) bined weight of occupants and...
Page 296 Driving your vehicle Example 1 Example 2 Example 3 C190F01JM C190F02JM C190F03JM Item Description Total Item Description Total Item Description Total Vehicle Capacity 849 lbs Vehicle Capacity 849 lbs Vehicle Capacity 849 lbs Weight (385 kg) Weight (385 kg) Weight (385 kg) Subtract Occupant Subtract Occupant...
Page 297: Certification Label
Driving your vehicle To find out the actual loads on your The label will help you decide how front and rear axles, you need to go much cargo and installed equipment to a weigh station and weigh your your vehicle can carry. vehicle.Your dealer can help you with this.
Page 298 Driving your vehicle WARNING WARNING - Over - Loose cargo loading Do not travel with unsecured Do not overload your vehicle. blunt objects in the passenger Overloading your vehicle can compartment of your vehicle cause heat buildup in your vehi- (e.g.
Page 299: Vehicle Weight
Driving your vehicle VEHICLE WEIGHT This section will guide you in the Cargo weight GVWR (Gross vehicle weight rating) proper loading of your vehicle and/or This figure includes all weight added This is the maximum allowable trailer, to keep your loaded vehicle to the Base Curb Weight, including weight of the fully loaded vehicle weight within its design rating capa-...
Page 300: What To Do In An Emergency
What to do in an emergency Road warning ......6-2 Towing ........6-29 .
Page 301: Road Warning
What to do in an emergency ROAD WARNING It should be used whenever emer- gency repairs are being made or when the vehicle is stopped near the edge of a roadway. Depress the flasher switch with the ignition switch in any position. The flasher switch is located in the center console switch panel.
Page 302: In Case Of An Emergency While Driving
Drive off the road as far as your vehicle will not start, contact possible and park on a firm level an authorized Kia dealer or seek ground. If you are on a divided other qualified assistance. highway, do not park in the median...
Page 303: If Engine Dose Not Turn Over Or Turns Over Slowly
4. If the engine still does not start, charged. call an authorized Kia dealer or 4. Check the starter connections to seek other qualified assistance. be sure they are securely tight- ened.
Page 304: Emergency Starting
What to do in an emergency EMERGENCY STARTING Jumper Cables CAUTION - 12 volt WARNING - Battery battery Keep all flames or sparks away Use only a 12-volt jumper sys- from the battery. The battery tem. You can damage a 12-volt produces hydrogen gas which starting motor, ignition system, will explode if exposed to flame...
Page 305 When replacing the AGM battery, 4.Connect the jumper cables in the Do not connect the jumper cable use only the Kia genuine battery for exact sequence shown in the illus- from the negative terminal of the the ISG system.
Page 306: Push-Starting
What to do in an emergency Push-starting Your manual transaxle-equipped vehicle should not be push-started because it might damage the emis- sion control system. Vehicles equipped with automatic transaxle cannot be push-started. Follow the directions in this section for jump-starting. WARNING - Tow starting vehicle...
Page 307: If The Engine Overheats
If overheating happens again, stopped. If there is no visible loss 5. If the water pump drive belt is bro- call an authorized Kia dealer for of engine coolant and no steam, ken or engine coolant leaks, stop assistance.
Page 308: Tire Pressure Monitoring System (Tpms)
What to do in an emergency TIRE PRESSURE MONITORING SYSTEM (TPMS) As an added feature, your vehicle Your vehicle has also been equipped has been equipped with a tire pres- with a TPMS malfunction indicator to sure monitoring system (TPMS) that indicate when the system is not oper- illuminates a low tire pressure telltale ating properly.
Page 309 TPMS malfunctioning ed, one or more of your tires is sig- authorized Kia dealer and have the because the decreased temperature nificantly under-inflated. system checked. leads to a proportional lowering of tire pressure.
Page 310 TPMS malfunction indicator. Have the system checked by an authorized Kia dealer as soon as possible to determine the cause of the problem. The TPMS malfunction indicator may...
Page 311 Pressure will come on. Have the flat use TPMS specific wheels. It is rec- If original mounted tire is replaced tire repaired by an authorized Kia ommended that you always have with the spare tire, the TPMS sensor dealer as soon as possible or...
Page 312 What to do in an emergency ✽ ✽ NOTICE You may not be able to identify a low This device complies with Part tire by simply looking at it. Always 15 of the FCC rules. Tampering with, modifying, or dis- use a good quality tire pressure abling the Tire Pressure Monitoring Operation is subject to the following...
Page 313: If You Have A Flat Tire
What to do in an emergency IF YOU HAVE A FLAT TIRE Jacking instructions Always move the vehicle completely off the road and onto the shoulder The jack is provided for emergency before trying to change a tire. The tire changing only. jack should be used on firm level To prevent the jack from “rattling”...
Page 314: Removing And Storing The Spare Tire
What to do in an emergency Do not allow anyone to remain in the vehicle while it is on the jack. Make sure any children present are in a secure place away from the road and from the vehicle to be raised with the jack.
Page 315 What to do in an emergency To prevent vehicle movement while changing a tire, always set the park- ing brake fully, and always block the wheel diagonally opposite the wheel being changed. We recommend that the wheels of the vehicle be chocked, and that no person remain in a vehicle that is being jacked.
Page 316 What to do in an emergency 9. Loosen the wheel nuts and remove them with your fingers. Slide the wheel off the studs and lay it flat so it cannot roll away. To put the wheel on the hub, pick up the spare tire, line up the holes with the studs and slide the wheel onto them.
Page 317 Then double-check each nut for tightness. After changing the wheels, have an authorized Kia dealer tighten the wheel nuts to their proper torque as soon as possible.
Page 318 “Tires and wheels” in section 8. extreme care in checking for thread and return the jack and tools to their style before installing aftermarket lug proper storage locations. nuts or wheels. If in doubt, consult an authorized Kia dealer. 6 19...
Page 319 What to do in an emergency Important - use of compact spare When using a compact spare tire, WARNING - Spare tire tire (if equipped) observe the following precautions: Do not operate your vehicle on • Under no circumstances should Your vehicle is equipped with a com- this compact spare at speeds you exceed 50 mph (80 km/h);...
Page 320 What to do in an emergency • Do not take this vehicle through an • The compact spare tire should not automatic car wash while the com- be used on any other wheels, nor pact spare tire is installed. should standard tires, snow tires, wheel covers or trim rings be used •...
Page 321 What to do in an emergency Jack label 1. Model Name ■ Example 2. Maximum allowable load ■ Type A 3. When using the jack, set your parking brake. 4. When using the jack, stop the engine. 5. Do not get under a vehicle that is supported by a jack.
Page 322 The Tire Mobility Kit is a temporary fortably seals most punctures in a fix to the tire and the tire should be passenger car tire caused by nails inspected by an authorized Kia deal- or similar objects and reinflates the er as soon as possible. tire.
Page 323: Notes On The Safe Use Of The Tire Mobility Kit
• Use of the Tire Mobility Kit may not be effective for tire damage larger than approximately 0.24 in (6 mm). Please contact the nearest Kia dealership if the tire cannot be made roadworthy with the Tire Mobility Kit.
Page 324: Components Of The Tire Mobility Kit
What to do in an emergency 9. Hose to connect compressor and sealant bottle or compressor and wheel Connectors, cable and connection hose are stored in the compressor housing. WARNING - Expired sealant Do not use the Tire sealant after the sealant has expired (i.e.
Page 325: Using The Tire Mobility Kit
What to do in an emergency Using the Tire Mobility Kit WARNING - Tire pres- 1.Detach the speed restriction label sure (0) from the sealant bottle (1), and Do not attempt to drive your place it in a highly visible place vehicle if the tire pressure is inside the vehicle such as on the below 29 PSI(200kpa).
Page 326: Checking The Tire Inflation Pressure
What to do in an emergency ✽ ✽ NOTICE Distributing the sealant Checking the tire inflation pressure The pressure gauge may show high- 11. Immediately drive approximately er than actual reading when the 4~6miles (7~10km or about 1.After driving approximately 4 compressor is running.
Page 327: Technical Data
When you use the Tire Mobility Amperage rating: max. 15 A including sealant Suitable for use at temperatures: approved by Kia, the tire pres- sure sensors may be damaged -22 ~ +158°F (-30 ~ +70°C) by sealant. The sealant on the Max. working pressure:...
Page 328: Towing
OED066011 Towing service If emergency towing is necessary, we recommend having it done by an authorized Kia dealer or a commer- cial tow-truck service. Proper lifting and towing procedures are neces- OED066014 sary to prevent damage to the vehi-...
Page 329: Removable Towing Hook
What to do in an emergency When towing your vehicle in an 3.Install the towing hook by turning it ■ 4 door emergency without wheel dollies : clockwise into the hole until it is fully secured. 1. Set the ignition switch in the ACC position.
Page 330: Emergency Towing
Emergency towing • The drivers of both vehicles should If towing is necessary, we recom- communicate with each other fre- mend you have it done by an quently. authorized Kia dealer or a com- mercial tow truck service. 6 31...
Page 331 What to do in an emergency Emergency towing precautions If the car is being towed with all four wheels on the ground, it can be • Turn the ignition switch to ACC so towed only from the front. Be sure the steering wheel isn’t locked.
Page 332: Maintenance
Maintenance Engine compartment ......7-3 Tires and wheels......7-42 .
Page 333 Light bulbs ....... . 7-67 • Headlight, position light, turn signal light, 7-68 front fog light bulb replacement .
Page 334: Engine Compartment
Maintenance ENGINE COMPARTMENT 1. Engine coolant reservoir 2. Engine oil filler cap 3. Brake/clutch fluid reservoir 4. Air cleaner 5. Fuse box 6. Positive battery terminal 7. Negative battery terminal 8. Windshield washer fluid reservoir 9. Radiator cap 10. Engine oil dipstick * The actual engine room in the vehicle may differ from the illustration.
Page 335: Maintenance Services
Kia dealer perform this work. nical support from Kia in order to pro- dance with the scheduled mainte- vide you with a high level of service An authorized Kia dealer has factory- nance service charts shown on the satisfaction.
Page 336: Owner Maintenance Precautions
As explained earlier in this section, become entangled in moving several procedures can be done only parts. If you must run the by an authorized Kia dealer with spe- engine while working under the cial tools. hood, make certain that you remove all jewelry (especially ✽...
Page 337: Owner Maintenance
• Check the engine oil level. ized Kia dealer at the frequencies exhaust fumes in the vehicle. indicated to help ensure safe, • Check the coolant level in coolant •...
Page 338 Maintenance At least monthly: At least twice a year At least once a year : (i.e., every Spring and Fall) : • Check the coolant level in the • Clean the body and door drain engine coolant reservoir. holes. • Check the radiator, heater and air conditioning hoses for leaks or •...
Page 339: Scheduled Maintenance Service
Maintenance SCHEDULED MAINTENANCE SERVICE Follow the Normal Maintenance If your vehicle is operated under the Schedule if the vehicle is usually above conditions, should operated where none of the following inspect, replace or refill more fre- conditions apply. If any of the follow- quently than the following Normal Maintenance Schedule.
Page 340: Normal Maintenance Schedule
If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- 3) Brake lines, hoses and connections ommended. Additives are available from your authorized Kia dealer along with 4) Brake pedal and operation information on how to use them. Do not mix other additives.
Page 341 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- 1) Battery condition ommended. Additives are available from your authorized Kia dealer along with 2) Brake fluid / clutch(if equipped) fluid information on how to use them. Do not mix other additives.
Page 342 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- 4) Brake pedal and operation ommended. Additives are available from your authorized Kia dealer along with 5) Chassis/body nuts and bolts information on how to use them. Do not mix other additives.
Page 343 3) Brake lines, hoses and connections If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ommended. Additives are available from your authorized Kia dealer along with 4) Brake pedal and operation information on how to use them. Do not mix other additives.
Page 344 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives. ❈ Inspect : Inspect and if necessary, adjust, correct, clean or replace.
Page 345 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- (Continued) ommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives. ❈ Inspect : Inspect and if necessary, adjust, correct, clean or replace.
Page 346 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- 6) Drum brake and linings (if equipped) ommended. Additives are available from your authorized Kia dealer along with 7) Disc brakes and pads (if equipped) information on how to use them. Do not mix other additives.
Page 347 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- 3) Brake lines, hoses and connections ommended. Additives are available from your authorized Kia dealer along with 4) Brake pedal and operation information on how to use them. Do not mix other additives.
Page 348 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- (Continued) ommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives. ❈ Inspect : Inspect and if necessary, adjust, correct, clean or replace.
Page 349 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- 3) Brake lines, hoses and connections ommended. Additives are available from your authorized Kia dealer along with 4) Brake pedal and operation information on how to use them. Do not mix other additives.
Page 350 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- 12) Parking brakes ommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives. (Continued) ❈...
Page 351 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) No check, No service required ❑ Automatic transaxle fluid (if equipped)
Page 352: Maintenance Under Severe Usage Conditions
Maintenance MAINTENANCE UNDER SEVERE USAGE CONDITIONS The following items must be serviced more frequently on cars normally used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary MAINTENANCE DRIVING MAINTENANCE ITEM...
Page 353 Maintenance MAINTENANCE DRIVING MAINTENANCE ITEM MAINTENANCE INTERVALS OPERATION CONDITION MANUAL TRANSAXLE OIL* EVERY 75,000 miles C, D, E, F, G, H, I, J AUTOMATIC TRANSAXLE FLUID* EVERY 60,000 miles A, C, E, F, G, H, I CLIMATE CONTROL AIR FILTER MORE FREQUENTLY C, E (FOR EVAPORATOR AND BLOWER UNIT)
Page 354: Explanation Of Scheduled Maintenance Items
Inspect all drive belts for evidence of as the exhaust manifold. age. Have an authorized Kia dealer cuts, cracks, excessive wear or oil Inspect the hose routing to assure replace any damaged or leaking saturation and replace if necessary.
Page 355 Maintenance ✽ ✽ NOTICE Air cleaner filter Coolant A Genuine Kia air cleaner filter is The coolant should be changed at Automatic transaxle fluid color is recommended when the filter is the intervals specified in the mainte- basically red. replaced.
Page 356: Parking Brake Lever
Maintenance Brake hoses and lines Rear brake drums and linings Steering gear box, linkage & (if equipped) boots/lower arm ball joint Visually check for proper installation, chafing, cracks, deterioration and Check the rear brake drums and lin- With the vehicle stopped and engine any leakage.
Page 357: Engine Oil
Maintenance ENGINE OIL WARNING - Radiator hose Be very careful not to touch the radiator hose when checking or adding the engine oil as it may be hot enough to burn you. 5. Pull the dipstick out again and check the level. The level should be between F and L.
Page 358: Engine Coolant
The reservoir is Have engine oil and filter changed by filled at the factory. an authorized Kia dealer according Check the antifreeze protection and to the Maintenance Schedule at the coolant level at least once a year, at beginning of this section.
Page 359 Bring the level to F (MAX), but do not Mixture Percentage (volume) overfill. If frequent coolant addition is Ambient required, see an authorized Kia deal- Temperature er for a cooling system inspection. Antifreeze Water 5°F (-15°C) Recommended engine coolant -13°F (-25°C)
Page 360 Maintenance Changing the coolant CAUTION - Removing Have the coolant changed by an radiator cap authorized Kia dealer according to Never attempt the Maintenance Schedule at the remove the radiator beginning of this section. cap while the engine Put a thick cloth or fabric around the is operating or hot.
Page 361: Brake/Clutch Fluid
BRAKE/CLUTCH (IF EQUIPPED) FLUID In the event the brake/clutch* system CAUTION - Proper fluid requires frequent additions of fluid, the vehicle should be inspected by Only use brake/clutch fluid in an authorized Kia dealer. brake/clutch system. Small amounts of improper fluids When changing...
Page 362: Automatic Transaxle Fluid
Kia dealer. washer fluid. The windshield In severe conditions, the fluid should washer fluid is poisonous to be changed at an authorized Kia humans and animals. dealer in accordance to the sched- uled maintenance at the beginning of this chapter.
Page 363: Parking Brake
If the stroke is more or less than specified, have the parking brake adjusted by an authorized Kia dealer. Stroke : 6~8 “clicks’’ at a force of 44 lbs (20 kg, 196 N).
Page 364 • Use a Kia genuine part. Use of OUB071012 nongenuine part could dam- 2. Wipe the inside of the air cleaner.
Page 365: Climate Control Air Filter
Maintenance CLIMATE CONTROL AIR FILTER (IF EQUIPPED) Filter inspection The climate control air filter should replaced according Maintenance Schedule. If the vehicle is operated in severely air-polluted cities or on dusty rough roads for a long period, it should be inspected more frequently and replaced earlier.
Page 366 Maintenance OMG079027 4. Replace the climate control air fil- ter. 5. Reassemble in the reverse order of disassembly. When replacing the climate control air filter, install it properly. Otherwise, the system may produce noise and the effectiveness of the filter may be reduced.
Page 367: Wiper Blades
Maintenance WIPER BLADES Contamination of either the wind- Blade replacement shield or the wiper blades with for- When the wipers no longer clean eign matter can reduce the effective- adequately, the blades may be worn ness of the windshield wipers. or cracked, and require replacement.
Page 368 Maintenance 1JBA7037 1LDA5023 OED076040 Front windshield wiper blade Rear window wiper blade 1. Raise the wiper arm and pull out the wiper blade assembly. CAUTION - Wiper arms Do not allow the wiper arm to fall against the windshield, since it may chip or crack the windshield.
Page 369 3. Make sure the blade assembly is installed firmly by trying to pull it slightly. To prevent damage to the wiper arms or other components, have an authorized Kia dealer replace the wiper blade.
Page 370: Battery
Maintenance BATTERY WARNING WARNING - Risk of - Sulfuric explosion acid in bat- teries Keep Lit cigarettes and other flames Keep batteries out of the sparks away from the reach children battery. because batteries con- tain highly corrosive battery contains SULFURIC ACID hydrogen -- a highly...
Page 371 Please return the battery to Batteries also contain other an authorized Kia dealer to chemicals known to the State of be recycled. California to cause cancer. Wash hands after handling.
Page 372 Maintenance Battery recharging When recharging battery, Reset items observe the following precautions: Your vehicle has a maintenance-free, Items should be reset after the bat- • The battery must be removed from calcium-based battery. tery has been discharged or the bat- the vehicle and placed in an area tery has been disconnected.
Page 373: Tires And Wheels
Maintenance TIRES AND WHEELS Tire care WARNING - Tire under- For proper maintenance, safety, and inflation maximum fuel economy, you must Inflate your tires consistent with always maintain recommended tire the instructions provided in this inflation pressures and stay within manual.
Page 374: Checking Tire Inflation Pressure
(1.6 km) since startup.) spare tire. refilling, have it checked by an • Check the pressure of your spare authorized Kia dealer. tire each time you check the pres- • Overinflation produces a harsh How to check sure of other tires.
Page 375: Tire Rotation
• Remember to check the pressure Replace the tire if you find either of the valve stems. They help prevent of your spare tire. Kia recommends these conditions. Replace the tire if leaks by keeping out dirt and mois- that you check the spare every fabric or cord is visible.
Page 376: Wheel Alignment And Tire Balance
Maintenance Rotate radial tires that have an Wheel alignment and tire bal- Without a spare tire asymmetric tread pattern only from ance front to rear and not from right to left. The wheels on your vehicle were Do not use the compact spare tire for aligned and balanced carefully at the tire rotation.
Page 377: Tire Replacement
Maintenance The ABS works by comparing the Compact spare tire replacement Tread wear indicator speed of the wheels. Tire size can A compact spare tire has a shorter affect wheel speed. When replacing tread life than a regular size tire. tires, all 4 tires must use the same Replace it when you can see the size originally supplied with the vehi-...
Page 378: Wheel Replacement
CAUTION - Wheel wheel alignment. for safety standard certification. The Wheels that do not meet Kia's When you have new tires installed, TIN can be used to identify the tire in specifications may fit poorly make sure they are balanced. This case of a recall.
Page 379 Maintenance 2. Tire size designation 89 - Load Index, a numerical code Tire speed ratings associated with the maximum A tire’s sidewall is marked with a tire The chart below lists many of the dif- load the tire can carry. size designation.
Page 380 Maintenance 3. Checking tire life (TIN : Tire 5. Maximum permissible inflation WARNING - Tire age Identification Number) pressure Replace tires within the recom- Any tires that are over 6 years old, This number is the greatest amount mended time frame. Failure to based on the manufacturing date, of air pressure that should be put in replace tires as recommended...
Page 381 Maintenance 7. Uniform tire quality grading Tires degrade over time, even when Traction - AA, A, B & C they are not being used. Regardless Quality grades can be found, where The traction grades, from highest to of the remaining tread, we recom- applicable, on the tire sidewall lowest, are AA, A, B, and C.
Page 382: Tire Terminology And Definitions
Maintenance Temperature -A, B & C Tire terminology and definitions Cold Tire Pressure: The amount of air pressure in a tire, measured in Air Pressure: The amount of air The temperature grades are A (the pounds per square inch (psi) or kilo- inside the tire pressing outward on highest), B and C representing the pascals (kPa) before a tire has built...
Page 383 Maintenance Intended Outboard Sidewall: The Occupant Distribution: Designated Speed Rating: An alphanumeric side of an asymmetrical tire, that seating positions. code assigned to a tire indicating the must always face outward when maximum speed at which a tire can Outward Facing Sidewall: The side mounted on a vehicle.
Page 384: All Season Tires
Vehicle Maximum Load on the All season tires Snow tires Tire: Load on an individual tire due to Kia specifies all season tires on If you equip your car with snow tires, curb and accessory weight plus some models to provide good per-...
Page 385: Tire Chains
Maintenance Tire chains Radial-ply tires Longer wearing tires can be more susceptible to irregular tread wear. It Tire chains, if necessary, should be Radial-ply tires provide improved is very important to follow the tire installed on the front wheels. tread life, road hazard resistance and rotation interval shown in this section smoother high speed ride.
Page 386 - If the tire is impacted, we rec- ommend that you inspect the tire condition or contact an authorized Kia dealer. - To prevent damage to the tire, inspect the tire condition and pressure every 3,000km. 7 55...
Page 387: Fuses
Avoid Do not use a screwdriver or any using the system involved and imme- other metal object to remove diately consult an authorized Kia fuses because it may cause a OTA070039 dealer. short circuit and damage the A vehicle’s electrical system is pro-...
Page 388: Instrument Panel Fuse Replacement
If it fits loosely, consult an authorized ommend that you consult with Kia dealer. an authorized Kia dealer. 7 57...
Page 389 4.Push in a new fuse of the same rat- lights. ing, and make sure it fits tightly in 3. Open the driver’s side panel cover the clips. and pull up the memory fuse. If it fits loosely, consult an author- ized Kia dealer.
Page 390: Fuse/Relay Panel Description
It is accurate at the time of printing. When you inspect OUB071023N the fuse panel in your vehicle, refer Multi fuse to the fuse panel label. If the multi fuse is blown, consult an authorized Kia dealer. 7 59...
Page 391 Maintenance OUB071025 Instrument panel fuse panel ✽ ✽ NOTICE The actual fuse/relay panel label may differ from equipped items. OUB074064N...
Page 392 Maintenance OUB071026 Engine compartment fuse panel ✽ ✽ NOTICE The actual fuse/relay panel label may differ from equipped items. OUB074063N 7 61...
Page 393 Maintenance Instrument panel fuse panel Fuse Name Fuse rating Circuit Protected POWER OUTLET Power Outlet C/LIGHTER Cigarette Lighter Front Map Lamp, Power Outside Mirror Switch, BCM, Low DC-DC Convertor, Smart Key Control Module, Audio, A/V & Navigation Head Unit, Digital Clock A/BAG IND Instrument Cluster SBR PAB Indicator, SRS Control Module...
Page 394 Maintenance Fuse Name Fuse rating Circuit Protected Vehicle Speed Sensor, Stop Lamp Switch, Inverter IG1 2 A/C Control Module HAZARD Hazard Switch, BCM PDM 1 Smart Key Control Module SUNROOF Sunroof Motor Immobilizer Module, Start/Stop Button Switch, PDM 2 Smart Key Control Module Smart Key Control Module, Immobilizer Module, ECM/PCM, Transaxle Range Switch IGN COIL...
Page 395: Rear Combination Lamp
Maintenance Fuse Name Fuse rating Circuit Protected With ISG : Low DC-DC Convertor AUDIO W/O ISG : Audio, A/V & Navigation Head Unit Head Lamp LH, License Lamp TAIL LAMP LH Rear Combination Lamp (IN/OUT) LH Head Lamp RH, License Lamp, ILL. (+), TAIL LAMP RH Rear Combination Lamp (IN/OUT) RH With Burglar Alarm : Burglar Alarm Relay...
Page 396 Maintenance Engine compartment fuse panel Fuse Name Fuse rating Circuit Protected MDPS EPS Control Module MULTI FUSE 125A Alternator I/P Junction Box (Power Connector Fuse : ROOM LP 10A / AUDIO 20A, Fuse : FOG LP FRT 15A / MODULE 1 10A / STOP LP 15A, Tail Lamp Relay) INVERTER Inverter I/P Junction Box (Fuse : HAZARD 15A / PDM 1 25A / PDM 2 10A / SUNROOF 15A /...
Page 397 Maintenance Engine compartment main fuse panel Fuse Name Fuse rating Circuit Protected PCB Fuse & Relay Box (Start Relay), W/O Smart Key - Ignition Switch, With Smart Key - PDM Relay Box (ESCL (IG2) Relay) ECU1 PCB Fuse & Relay Box (Engine Control Relay, ECU2 10A) ECU3 Not Used BLOWER...
Page 398: Light Bulbs
If you don’t have necessary tools, the WARNING - Lights wattage. correct bulbs and the expertise, con- sult an authorized Kia dealer. In Prior to working on the light, many cases, it is difficult to replace firmly apply the parking brake, CAUTION...
Page 399: Headlight, Position Light, Turn Signal Light
Maintenance • 4 door ■ 4 door (1) Headlight (High/Low) (2) Position light (3) Front turn signal light (4) Front fog light* • 5 door (1) Headlight (High) OUB071065K (2) Headlight (Low) ■ 5 door (3) Front turn signal light OHD076046 Headlight bulb (4) Position light...
Page 400 Maintenance Always handle them carefully, and 1.Turn off the engine and open the avoid scratches and abrasions. If the hood. bulbs are lit, avoid contact with liq- 2.Remove the front bumper upper uids. Never touch the glass with bare cover. hands.
Page 401 10. Install the headlight bulb cover by turning it clockwise. If the headlight aiming adjustment is necessary after headlight assembly is reinstalled, consult an authorized Kia dealer. OUB071030N OUB071029 Headlight (High) Headlight (Low) • 5 door • 5 door 5.Remove the headlight bulb cover Follow the steps 1 to 4 from the pre- by turning it counterclockwise.
Page 402 If the light bulb does not operate, OUB071031N have the vehicle checked by an Turn signal light/Position light or Side authorized Kia dealer. marker Follow the steps 1 to 4 from the pre- vious page. 5.Remove the socket from the...
Page 403: Side Repeater Light Bulb Replacement
2.Disconnect the bulb electrical con- ing and turn the socket clockwise. the vehicle checked by an authorized nector. Kia dealer. 6 Connect the power connector to 3.Separate the socket and the lens the socket. parts by turning the socket coun-...
Page 404: Rear Combination Light Bulb Replacement
(LED type, if equipped) 8.Reinstall the light assembly to the If the light (LED) does not operate, body of the vehicle. have the vehicle checked by an authorized Kia dealer. OUB071067K ■ 5 door OUB071036 Rear combination light bulb...
Page 405 Maintenance 7.Install the socket in the assembly by aligning the tabs on the socket with the slots in the assembly. Push the socket into the assembly and turn the socket clockwise. 8.Install the service cover by putting it into the service hole. OUB071069K OUB071070K Outside light...
Page 406 Maintenance 8.Install the socket in the assembly by aligning the tabs on the socket with the slots in the assembly. Push the socket into the assembly and turn the socket clockwise. 9.Reinstall the light assembly to the body of the vehicle. OUB071037 OUB071038 •...
Page 407 Maintenance 5.Remove the bulb from the socket by pressing it in and rotating it until the tabs on the bulb align with the slots in the socket. Pull the bulb out of the socket. OUB071071K OUB071072K Inside light 6.Insert a new bulb by inserting it into the socket and rotating it until it Back-up light/tail light locks into place.
Page 408 Maintenance 7.Install the socket in the assembly by aligning the tabs on the socket with the slots in the assembly. Push the socket into the assembly and turn the socket clockwise. 8.Install the service cover by putting it into the service hole. OUB071039 OUB071058 •...
Page 409: High Mounted Stop Light Replacement
Maintenance 3.Remove the socket from the assembly by turning the socket counter clockwise until the tabs on the socket align with the slots on the assembly. 4.Remove the bulb by pulling it straight out. 5.Insert a new bulb in the socket. OUB071042 6.Reinstall the socket in the assem- bly in the reverse order of removal.
Page 410: License Plate Light Bulb Replacement
Maintenance OUB071061N OUB071043 5.Loosen the retaining nuts. License plate light bulb replacement 6.Remove the washer hose socket from the lamp assembly by turning 1.Remove the lens by pressing the the socket counter clockwise until tabs. the tabs on the socket align with 2.Remove the socket from the lens.
Page 411: Interior Light Bulb Replacement
Maintenance ■ ■ Interior light bulb replacement Map lamp Glove box lamp 1.Using a flat-blade screwdriver, gently pry the lens from the interior light housing. 2.Remove the bulb by pulling it straight out. WARNING - Interior lights Prior to working on the Interior Lights, ensure that the “OFF”...
Page 412: Appearance Care
Maintenance APPEARANCE CARE Exterior care Finish maintenance After washing the vehicle, test the brakes while driving slowly to see if Washing Exterior general caution they have been affected by water. If To help protect your vehicle’s finish It is very important to follow the label braking performance is impaired, dry from rust and deterioration, wash it directions when using any chemical...
Page 413 Maintenance Waxing CAUTION - Drying Wax the vehicle when water will no vehicle longer bead on the paint. • Wiping dust or dirt off the Always wash and dry the vehicle body with a dry cloth will before waxing. Use a good quality scratch the finish.
Page 414 Maintenance Finish damage repair Underbody maintenance Aluminum or chrome wheel main- tenance Deep scratches or stone chips in the Corrosive materials used for ice and painted surface must be repaired snow removal and dust control may The aluminum or chrome wheels are promptly.
Page 415 Maintenance Corrosion protection High-corrosion areas Moisture breeds corrosion If you live in an area where your vehi- Moisture creates the conditions in Protecting your vehicle from corro- cle is regularly exposed to corrosive which corrosion is most likely to sion materials, corrosion protection is occur.
Page 416 Maintenance To help prevent corrosion • When cleaning underneath the Keep your garage dry vehicle, give particular attention to You can help prevent corrosion from Don't park your vehicle in a damp, the components under the fenders getting started by observing the fol- poorly ventilated garage.
Page 417: Interior Care
Maintenance Don't neglect the interior Interior care CAUTION - Leather Moisture can collect under the floor Interior general precautions When cleaning leather products mats and carpeting and cause corro- Prevent chemicals such as perfume, (steering wheel, seats etc.), use sion. Check under the mats periodi- cosmetic oil, sun cream, hand clean- neutral detergents or low alco- cally to be sure the carpeting is dry.
Page 418 Maintenance Cleaning the upholstery and inte- Cleaning the lap/shoulder belt rior trim webbing Clean the belt webbing with any mild Vinyl soap solution recommended for Remove dust and loose dirt from cleaning upholstery or carpet. Follow vinyl with a whisk broom or vacuum the instructions provided with the cleaner.
Page 419: Emission Control System
(The ORVR system is designed to an authorized Kia dealer in accor- allow the vapors from the fuel tank to dance with the maintenance sched- be loaded into a canister while refu- ule in this manual.
Page 420 Maintenance Canister 3. Exhaust emission control Engine exhaust gas precautions (carbon monoxide) system Fuel vapors generated inside the fuel tank are absorbed and stored in the • Carbon monoxide can be present Exhaust Emission Control onboard canister. When the engine is with other exhaust...
Page 421 It may present a fire risk under trol system. All inspections and the emission control system. certain conditions. adjustments must be made by an authorized Kia dealer. Your vehicle is equipped with a cat- • Avoid driving with a extremely low WARNING - Catalytic alytic converter emission control fuel level.
Page 422: California Perchlorate Notice
Maintenance CALIFORNIA PERCHLORATE NOTICE Perchlorate Material-special han- dling apply, www.dtsc.ca.gov/hazardouswaste/p erchlorate. Notice California Vehicle Dismantlers: Perchlorate containing materials, such as air bag inflators, seatbelt pretensioners and keyless remote entry batteries, must be disposed of according to Title 22 California Code of Regulations Section 67384.10 (a).
Page 423: Specifications, Consumer Information And Reporting Safety Defects
Specifications, Consumer information and Reporting safety defects Engine ........8-2 Dimensions .
Page 424: Engine
Specifications, Consumer information, Reporting safety defects ENGINE Item Gasoline 1.6 97.09 Displacement [cu.in(cc)] (1,591) 3.03 x 3.36 Bore x Stroke [in(mm)] (77 x 85.44) Firing order 1-3-4-2 No. of cylinders 4, In-line DIMENSIONS Item in (mm) 4 door 171.8 (4365) Overall length 5 door 159.2 (4045)
Page 425: Bulb Wattage
Specifications, Consumer information, Reporting safety defects BULB WATTAGE ■ ■ 5 door Light Bulb Wattage Bulb type H11B Head lamp High Position lamp 5W or LED P21/5W or LED Front Turn signal lamp PY21W Front fog lamp* 9006 Side marker light Inside 5W or LED W5W or LED...
Page 426 Specifications, Consumer information, Reporting safety defects ■ ■ 4 door Light Bulb Wattage Bulb type Head lamp High Position lamp 5W or LED W5W or LED Front Turn signal lamp PY28/8W Front fog lamp* Side marker light Inside 8W or LED P27/8W or LED Tail lamp Outside...
Page 427: Tires And Wheels
Specifications, Consumer information, Reporting safety defects TIRES AND WHEELS Cold tire inflation pressure / psi (kPa) Wheel lug nut torque / Item Tire size Wheel size Normal load Maximum load lb.ft(kg.m, N.m) Front Rear Front Rear P185/65R15* 5.5J X 15 Full size tire (230) (230)
Page 428: Recommended Lubricants And Capacities
Manual transaxle fluid approved by Kia Motors Corp. (1.8 ~ 1.9 l) MICHANG ATF SP-IV, SK ATF SP-IV Automatic transaxle NOCA ATF SP-IV, Kia genuine ATF SP-IV or 1.6 Engine 7.71 US qt. (7.3 l) fluid other brands meeting the above specification approved by Kia Motor Co.,...
Page 429: Recommended Sae Viscosity Number
Specifications, Consumer information, Reporting safety defects Recommended SAE viscosity Engine oil viscosity (thickness) has When choosing an oil, consider the an effect on fuel economy and cold range of temperature your vehicle number weather operation (engine start and will be operated in before the next oil Always be sure to clean the area engine oil flowability).
Page 430: Vehicle Identification Number (Vin)
Specifications, Consumer information, Reporting safety defects VEHICLE IDENTIFICATION NUMBER (VIN) VEHICLE CERTIFICATION LABEL VIN Label (if equipped) OUB081005N OVQ076002N OUB081001 VIN label vehicle certification label The vehicle identification number attatched on the driver’s side center (VIN) is the number used in register- The VIN is also on a plate attached pillar gives the vehicle identification ing your vehicle and in all legal mat-...
Page 431: Tire Specification And Pressure Label
Specifications, Consumer information, Reporting safety defects TIRE SPECIFICATION AND ENGINE NUMBER REFRIGERANT LABEL PRESSURE LABEL OUB081004N OUB071062N OUB071018 The engine number is stamped on The refrigerant label is located on the engine block as shown in the the underside of the hood. The tires supplied on your new vehi- drawing.
Page 432: Consumer Assistance
Roadside Assistance is provided on all new current Please note that you must provide your Vehicle model year Kia Vehicles from the date the vehicle is deliv- Identification Number (VIN) to verify coverage at the time ered to the first retail buyer or otherwise put into use (in- of your call.
Page 433 Roadside Assistance benefits are not available for any should therefore consider the possibility of having to deal Kia vehicle that has ever been or should be issued a “sal- with them: vage” title or similar “branded” title under any state’s 1.The fuel specified for your vehicle may be unavailable.
Page 434: Electrical Equipment
Authorized Kia electronic systems may be adversely affected. To avoid Dealer, in order to ensure that you do not void your war- damage to your vehicle, consult an Authorized Kia Dealer ranty. concerning the proper equipment and installation.
Page 435: Reporting Safety Defects
However, NHTSA cannot become involved in indi- defects please contact your Kia's toll-free Consumer vidual problems between you, your dealer, or Kia Motors Assistance hot line as below: America, Inc.
Page 436: Online Factory Authorized Manuals
Specifications, Consumer information, Reporting safety defects ONLINE FACTORY AUTHORIZED MANUALS (U.S. ONLY) following publications available www.KiaTechinfo.com at no charge. Service manual: This manual covers maintenance and recommended pro- cedures for repair to engine and chassis components. It is written for the Journeyman mechanic, but is simple enough for most mechanically inclined owners to under- stand.
Page 437 Index...
Page 438 Index Base curb weight ···························································5-61 Active Eco System·························································5-45 Battery············································································7-39 Air bag warning label ····················································3-54 Battery saver function····················································4-76 Air bag warning light·····················································3-34 Before driving ··································································5-3 Air bags··········································································3-31 Bottle holders, see cup holders····································4-103 Air bag warning label··················································3-54 Brake system··································································5-22 Air bag warning light ··················································3-34 Anti-lock brake system (ABS) ····································5-26 Curtain air bag ·····························································3-46 Electronic stability program (ESC) ·····························5-27...
Page 439 Index Cargo capacity ·······························································5-57 Cargo weight··································································5-61 Center console storage···················································4-98 Dashboard illumination, see instrument panel illumination··································································4-46 Central door lock switch················································4-18 Dashboard, see instrument cluster ·································4-45 Certification label ···················································5-59, 8-8 Defogging (Windshield) ················································4-96 Chains Defogging logic (Windshield) ·······································4-97 Tire chains ···································································5-53 Defroster (Rear window) ···············································4-86 Changing tires································································6-15 Defrosting (Windshield) ················································4-96 Checking tire inflation pressure·····································7-43...
Page 440 Index Economical operation ····················································5-46 Flat tire (with spare tire) ················································6-14 Electric power steering ··················································4-39 Jack and tools ······························································6-14 Electronic stability program (ESC) ·······························5-27 Changing tires······························································6-15 Emergency starting ··························································6-5 Compact spare tire·······················································6-20 Jump starting ·································································6-5 Removing and storing the spare tire····························6-15 Push starting ··································································6-7 Flat tire (with tire mobility kit) ·····································6-23 Emergency while driving·················································6-3...
Page 441 Index Gauge Idle stop and go system ·················································5-40 Engine coolant temperature gauge ······························4-47 Immobilizer system ·······················································4-11 Fuel gauge ···································································4-47 Indicator symbols on the instrument cluster ···················1-7 GAW (Gross axle weight) ·············································5-61 Indicators and warnings·················································4-58 GAWR (Gross axle weight rating) ································5-61 Inside rearview mirror ···················································4-42 Glove box·······································································4-98 Instrument cluster ··························································4-45...
Page 442 Index Clothes hanger ···························································4-107 Cup holder ·································································4-103 Digital clock and calendar·········································4-106 Label Floor mat anchor(s) ···················································4-107 Air bag warning label··················································3-54 Power outlet·······························································4-105 Refrigerant label ····························································8-9 Shopping bag holder ···················································4105 Tire sidewall labeling ··················································7-47 Sliding armrest ··························································4-103 Tire specification and pressure label ·····························8-9 Sunvisor ·····································································4-104 Vehicle certification label ··············································8-8 Interior light ···································································4-84...
Page 443 Index Maintenance schedule······················································7-8 Maintenance under severe usage conditions ·················7-21 Normal maintenance schedule·······································7-9 Parking brake························································5-24, 7-32 Maintenance services·······················································7-4 Power brakes··································································5-22 Manual climate control system······································4-87 Power outlet ·································································4-105 Air conditioning ··························································4-92 Power window lock button ············································4-28 Climate control air filter ··············································4-95 Pre-tensioner seat belt····················································3-18 Heating and air conditioning ·······································4-88 Push starting·····································································6-7 Manual transaxle····························································5-13...
Page 444: Spare Tire
Index Smooth cornering···························································5-49 Snow tires ······································································5-52 Spare tire Scheduled maintenance service ·······································7-8 Compact spare tire·······················································6-20 Maintenance under severe usage conditions ···············7-21 Compact spare tire replacement ··································7-46 Normal maintenance schedule·······································7-9 Removing and storing the spare tire····························6-15 Seat belt warning ···························································3-14 Special driving conditions ·············································5-48 Seat belts········································································3-13 Driving at night ···························································5-49 3 Point rear center belt ················································3-15...
Page 445 Index Luggage net ·································································4-99 Tire traction ·································································7-47 Luggage tray······························································4-100 Wheel alignment and tire balance ·······························7-44 Sunroof···········································································4-35 Wheel replacement ······················································7-47 Sunvisor ·······································································4-104 Towing ···········································································6-29 Towing capacity ·····························································5-57 Transaxle Automatic transaxle·····················································5-16 Manual transaxle ·························································5-13 Tachometer·····································································4-46 Trip computer ································································4-49 Tailgate···········································································4-23 Trunk··············································································4-21 Emergency safety release ············································4-24 Telescoping steering ······················································4-40 Tether anchor system ·····················································3-28 Theft-alarm system ························································4-13...
Page 446 Index Tire and loading information label······························5-56 Winter driving ································································5-52 Towing capacity···························································5-57 Snow tires ····································································5-52 Vehicle capacity weight···············································5-56 Tire chains ···································································5-53 Vehicle stability management········································5-31 Wiper blades ··································································7-36 Volume/weight ·································································8-5 Wipers and washers ·······················································4-80 Base curb weight ·························································5-61 Cargo weight ·······························································5-61 GAW (Gross axle weight) ···········································5-61 GAWR (Gross axle weight rating) ······························5-61 GVW (Gross vehicle weight) ······································5-61 GVWR (Gross vehicle weight rating)·························5-61...

Kia 2015 Rio Owner's Manual

Introduction 1

Safety Features of Your Vehicle

Features of Your Vehicle

Driving Your Vehicle

Before Driving

Key Positions

Engine Start/Stop Button

Starting the Engine

Manual Transaxle

Automatic Transaxle

Brake System

Cruise Control System

ISG (Idle Stop and Go) System

Active Eco System

Economical Operation

Special Driving Conditions

Winter Driving

Trailer Towing

Vehicle Load Limit

Vehicle Weight

What to Do in an Emergency

Road Warning

In Case of an Emergency While Driving

If the Engine Does Not Start

Emergency Starting

If the Engine Overheats

Tire Pressure Monitoring System (TPMS)

If You Have a Flat Tire

Towing

Maintenance

Specifications, Consumer Information and Reporting Safety Defects

Quick Links

Chapters

Related Manuals for Kia 2015 Rio

Summary of Contents for Kia 2015 Rio
