Summary of Contents for Idis DA-MC1101

  • Page 1 All manuals and user guides at all-guides.com 10/100/1000 Base-T to Gigabit Fiber Media Converter Operation Manual DA-MC1101 Powered by...
  • Page 2: Before Using The Product

    DA-MC1101 is designed to fulfill requirements for forming a Gigabit network, and can extend a connection up to 10KM using fiber optic cables. The LED indicators located on the front panel of DA-MC1101 shows the operating status of the product.
  • Page 3: Product Features

    ● Mode switching using DIP switches Accessories The product consists of the following components. Power FDX Status Speed FO TX Diag Link / Act Main Unit (DA-MC1101) 5V DC adapter Operation Manual Overview Front LED indicators Power FDX Status RJ45 port...
  • Page 4: Installation

    Connect the Video In port of DirectIP™ NVR and RJ45 port of DA-MC1101 #1 using a UTP cable. Insert an SFP module into SFP slot of DA-MC1101 #1 and connect the fiber optic cable to the module. The connection distance can be extended to 500m to 10km using fiber optic cables.
  • Page 5 All manuals and user guides at all-guides.com Insert an SFP module into SFP slot of DA-MC1101 #2 and connect the fiber optic cable to the module. Connect the RJ45 port of DA-MC1101 #2 to a DirectIP ™ Switching Hub or a network camera using a UTP cable.
  • Page 6 All manuals and user guides at all-guides.com • The connection distance can be extended to 500m to 10km using fiber optic cables. • The connection distance is determined by the SFP module and the fiber optic cable. • For more details on supported SFP modules, refer to "7. Supported SFP Modules". Insert an SFP module into SFP slot of DirectIP™Gigabit PoE Switch and connect the fiber optic cable to the module.
  • Page 7: Dip Switch Settings

    All manuals and user guides at all-guides.com Checking Other Information DIP Switch Settings In factory settings, Pin 1 and Pin 5 are switched On and the rest are switched Off. Pin No. Operation TX Auto-Negotiation Disable Enable Manual TX Data Rate 10M/100M 100M Manual TX Data Rate 1000M 10M or 100M...
  • Page 8: Checking Led Indicators

    All manuals and user guides at all-guides.com Checking LED Indicators Color Operation Power Green Turns on when power is connected. Turns on when the connection between remote device and TX cable is established. Green TX Link/Act Blinks when transferring data. Blinks when fiber optic cable connection is disconnected in Orange LLF Mode.
  • Page 9: Specifications

    All manuals and user guides at all-guides.com Specifications Model DA-MC1101 Network Protocols IEEE 802.3, 802.3u, 802.3ab, 802.3z Port type 1 x RJ-45 LAN connector, 1 x SFP slot Power, FDX, Status, Speed, FO Link/ACT, TX LED type Link/ACT Power adapter...
  • Page 10 All manuals and user guides at all-guides.com...
  • Page 11 All manuals and user guides at all-guides.com...
  • Page 12 All manuals and user guides at all-guides.com IDIS Co., Ltd. For more information, please visit at Ver. 1.00 www.idisglobal.com...
