PRELIMINARY TECHNICAL DATA
SUB1
P R O F E S S I O N A L
POWERED BASS MODULE
(Grille removed)
Product Overview
A powered, portable bass module, the Sub1 subwoofer combines with virtually any portable PA and delivers
low-end performance down to 40 Hz. Its unique 7" × 13" high-excursion RaceTrack driver allows for an ultra-
slim enclosure, delivering performance that rivals a traditional 12" woofer without the cumbersome size,
freeing up room in your vehicle and on the stage. Compared to the Sub2 subwoofer, Sub1 is the more compact
subwoofer option for the Bose L1 Pro32 system, combining seamlessly via single-cable SubMatch connectivity.
You can stack multiple Sub1 subwoofers for even more low end — or to unleash Cardioid Mode for directional
bass. With a Sub1, you get a subwoofer that goes virtually anywhere and effortlessly fills out your sound.
Key Features
Add powerful bass to your portable PA system with low-end range down to 40 Hz
Go from vehicle to venue easily with a slim design featuring a unique 7" × 13" high-excursion RaceTrack
driver; performance that rivals a conventional 12" woofer with a smaller footprint
Stack multiple Sub1 subwoofers for even more bass or unleash Cardioid Mode for focused, directional
performance that steers the bass out front and decreases feedback
Combine seamlessly with Bose L1 Pro32 portable line array via proprietary SubMatch connectivity, which
delivers both power and audio over a single cable
Pair with other powered loudspeakers via line input and output with selectable crossover modes, plus
integrated threaded pole mount for use with Bose S1 Pro PA and more
PRO.BOSE.COM/L1
1
OF 6
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bose SUB1
Summary of Contents for Bose SUB1
- Page 1 12" woofer without the cumbersome size, freeing up room in your vehicle and on the stage. Compared to the Sub2 subwoofer, Sub1 is the more compact subwoofer option for the Bose L1 Pro32 system, combining seamlessly via single-cable SubMatch connectivity.
-
Page 2: Technical Specifications
+24 dBu Channel 1 & 2 Output: Audio Type XLR connector, line-level, full-frequency bandwidth SubMatch Input: Audio Type Bose proprietary multi-pin cable SubMatch Thruput: Audio Type Bose proprietary multi-pin cable LED Indicators Standby, Phase/Pattern selection, Input EQ selection, Output EQ selection,... - Page 3 Shipping Weight 18.0 kg (39.6 lbs) Warranty Period 2 years Included Accessories IEC power cord, slip cover Optional Accessories Sub1 Roller Bag, Adjustable Speaker Pole, SubMatch Cable Product Part Numbers 840918-1100 SUB1 POWERED BASS MODULE,120V,US 840918-2100 SUB1 POWERED BASS MODULE,230V,EU 840918-3100...
-
Page 4: Connections And Controls
Sub bass module with a SubMatch cable. LINE IN 1 LINE IN 2 LINE IN EQ Up to two Sub1 or Sub2 powered bass modules can be powered by a single L1 Pro32 via SubMatch connection. Power Input Cover: Prevents... -
Page 5: Product Dimensions
Product Dimensions Left View Front View Right View Rear View Bottom View Top View Performance Frequency Response (On-Axis) 1000 10000 20000 Frequency (Hz) PRO.BOSE.COM/L1 OF 6... -
Page 6: Safety And Regulatory Compliance
The enclosure of the sub shall be constructed of high-impact polypropylene and birch plywood. The sub shall provide a pole-mount M20 threaded insert for use with the Bose Sub1/Sub2 Adjustable Speaker Pole. The sub shall provide four interlocking feet on each side for stacking with one other Sub1.
