- Page 1 Wired/Wireless Dual-Function Microphone 有线/无线双功能麦克风 BY-PM500W User Manual 用户手册...
-
Page 2: General Introduction
General Introduction Thanks for choosing BOYA! BOYA BY-PM500W is a dual-function microphone, offering wired or wireless operation for gamers, streamers, podcasters in a variety of applications. The microphone features selectable cardioid and omnidirectional pickup patterns, allowing you to customize your audio, and supporting 24bit/48 kHz resolution. -
Page 3: Product Structure
Product Structure 1. Metal mesh windscreen 2. Headphone volume/ gain/mute control 3. Polar pattern indicators 4. Polar pattern switch 5. Locking knobs 6. Desk stand 7. Battery level indicator 8. Power/pair button 9. USB-C port 10. 3.5mm headphone jack 11. 3/8'' threaded hole... - Page 4 1. Status indicator 2. USB-C connector 3. 3.5mm headphone jack 4. Volume control(+/-) / Pair button 5. Mono/stereo switch Accessories USB-C to USB-C cable USB-C female to USB-A male adapter USB-A to USB-C cable...
- Page 5 Functions Angle Adjustment Loosen the knobs of both sides anticlockwise. Adjust the microphone at your desired angle, then tighten the knobs.
- Page 6 Headphone Volume/Gain/Mute Control Operation Mode Indicator Headphone Default setting: headphone volume control volume control Short press the knob to mute the microphone. Long press the knob to switch between gain Gain control control and headphone volume control. Turn the knob to adjust mic gain/ headphone volume.
- Page 7 Factory Reset For optimum sound, please press and hold the headphone volume/gain/mute control knob and the polar pattern switch simultaneously to restore factory setting. The indicator will blink red three times. Press and hold simultaneously...
- Page 8 Operation Guide Wired Operation 1. Connect the microphone to your smartphone/computer. USB-C devices Using the supplied USB-C to USB-C cable...
- Page 9 Mac/Windows Computer Using the supplied USB-A to USB-C cable...
- Page 10 2. Connect headphones for audio monitoring. 3. Adjust the headphone volume/gain/mute control knob according to your needs. 4. You are ready to record.
- Page 11 Wireless Operation 1. Turn on the transmitter Press and hold the power button Note: When using wired function, short press the power button to enable wireless function simultaneously. Double-click the power button to enter pairing mode. Press again to disable wireless function.
- Page 12 2. Connect the Receiver to an external device Connect to a USB-C device Connect to a USB-A device...
- Page 13 3. TX & RX Pairing Before leaving factory, the transmitter and the receiver is pre-paired. Therefore, the connection will be established once they are powered on. If they are disconnected, please follow below steps: ① Double-click the TX’s pair button to enter pairing mode.
- Page 14 ② Press the RX’s pair(+ and -) button to enter pairing mode. Press + and - buttons simultaneously...
- Page 15 4. The transmitter and the receiver will be successfully paired within 10 seconds. Mode Indicators (of both TX and RX) Unpaired Slowly flashing blue light Pairing Quickly flashing blue light Paired Successfully Solid blue light 5. Connect headphones for audio monitoring.
- Page 16 6. You are ready to record. Note: Due to 2.4GHz wireless frequency, signal can be easily attenuated. Please try to avoid obstacles, such as walls and buildings, and avoid close proximity to devices with 2.4GHz signal, such as high-power wifi antennas, smartphones with wifi...
-
Page 17: Specifications
Specifications Wired Operation Mic Capsule 14mm Condenser Capsule Polar Pattern Cardioid /Omnidirectional Frequency Response 20Hz-20kHz Sensitivity -36dB（0dB=1V/Pa，1kHz 1Pa） Signal-to-Noise Ratio 80dB 110dB Maximum SPL Sampling Rate 48kHz Bit Rate 24bit Mic Gain 0~54dB Working Voltage 5V/100mA Audio Output Connector 3.5mm Headphone Jack USB-C Port Operating Temperature 0°C to 50°C... - Page 18 Wireless Operation Mic Capsule 14mm Condenser Capsule Polar Pattern Cardioid /Omnidirectional Frequency Response 35Hz-18kHz Sensitivity -36dB（0dB=1V/Pa，1kHz 1Pa） Signal-to-Noise Ratio 80dB Maximum SPL 110dB Transmission Type 2.4GHz Modulation GFSK Antenna Dipole Antenna Operating Range 10m (Indoors with obstacles) RF Output Power <10mW ＜0.05% Distortion Battery Life 8 Hours...
-
Page 19: Polar Pattern
Polar Pattern Cardioid Polar Pattern 0° 270° 90° 2000 20000 180° Omnidirectional 0° 270° 90° 180° 2000 20000... - Page 20 FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
- Page 21 The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. www.boya-mic.com SHENZHEN JIAYZ PHOTO INDUSTRIAL., LTD. The BOYA logo is a trademark which is registered and owned by Shenzhen Jiayz Photo Industrial., Ltd. 深圳市长丰影像器材有限公司 地址:广东省深圳市龙华区观澜街道大富社区硅谷动力智能终端产业园A16栋...
