Page 2
Pengenalan Terima kasih telah membeli BOYA! BY-DM20 merupakan paket mikrofon multi fungsi dengan 2 jalur mikrofon masuk dan 1 output audio. BY-DM20 merupakan solusi perekaman suara untuk iOS, Android Type- C dan laptop. BY-DM20 cocok digunakan dalam interview, produksi televisi, produksi film, rekaman musik, periklanan, dll.
Page 3
Fitur - All-in-one recording solution - Compact and easy to use - Dual-channel audio inputs - Ideal for interview or other demands for capturing two subjects - Stereo and Mono mode selectable - Volume control for each channel separately - 3.5mm Headphone output - Compatible with iOS, Android(Type-C), Laptop Spesifikasi Frequency response:...
Page 4
Bagian-bagian Indicate light ① 1) “Blue light on” for recording 2) “Green light on” for replay 3) “Both lights on” for real-time playing by compatible App...
Mic/Line-in jack (Left channel) ② Type-C port ③ Mic/Line-in jack (Right channel) ④ Volume control (Right channel) ⑤ Recording/Play switch ⑥ 1) switch to “REC” for recording 2) switch to “PLAY” for replay Earphone jack ⑦ Stereo/Mono switch ⑧ 1) switch to “S” for stereo 2) switch to “M”...
Page 6
Pemakaian 1. Install the clip and windscreen 2. Connect lavalier mics and cables to main body...
Page 7
3. Mount the microphone to your clothing • Attach the microphone to the front of your clothing with the clothing clip, about 20-25cm (8-10 inches) from your face. 1) Attach the microphone upside down to reduce excessive breath noises and tonal inconsistencies due to head movements.
4. Connect BY-DM20 to your device - Choose and connect the right cable with your device - Open a compatible app and start recording 5. Settings - Adjust left/right channel volume from side wheel - Select between Mono(M) or Stereo(S) mode from...
Page 9
SHENZHEN JIAYZ PHOTO INDUSTRIAL., LTD. The BOYA logo is a trademark which is registered and owned by Shenzhen Jiayz Photo Industrial., Ltd. COPY RIGHT 2010-2020 TEL: 400 6131096 Email: sales@boya-mic.com www.boya-mic.com / www.jiayz.com...
