- Page 1 Intelligent Hardwire Kit User Manual The information in this manual is subject to change without notice. Rexing All Rights Reserved www.rexingusa.com...
- Page 2 We hope you love your new products as much as we do. If you need assistance, or have any suggestions to improve it, please contact us. care@rexingusa.com (877) 740-8004 Our support team will respond you as soon as possible. Always a surprise in Rexing. Check us out here. • https://www.facebook.com/rexingusa/ • https://www.instagram.com/rexingdashcam/ • https://www.rexingusa.com/support/registration/...
-
Page 3: What's In The Box
Motion Sensor Mini-USB to Mini-USB Cable Smart Hardwire Kit User manual Please DO NOT enable the parking monitor function in the settings of the dash cam once connected. This intelligent hardwire kit will override the dash cam's parking monitor feature. - Page 4 Overview Motion Sensor Indicator Motion Sensor Indicator Power Indicator Mini-USB Port for dash cam connection Power Switch Motion Sensor On/Off Button Mini-USB Port for fuse box connection...
- Page 5 Step One Once the dash cam is attached on the windshield with the included adhesive mount, place the motion sensor on the top of the windshield about a few inches away from the dash cam. Please make sure that the motion sensor is not blocked by any object, especially the rear view mirror.
- Page 6 Step Two Connect the motion sensor with the included USB cable.
- Page 7 Step Three Run the wiring towards the fuse box with the included smart hardwire kit.
- Page 8 Smart Hardwire Kit Connection Power Cable Ground Cable Hot Fuse Cable Switched Fuse Cable If you have different fuse type, please visit our support page at https://www.rexingusa.com/support/for details.
- Page 9 Step One Find the switched fuse and connect the RED cable to it. This fuse has power only when the car is on.
- Page 10 Step Two Find the hot fuse the connect the YELLOW cable to that. This fuse has power at all time.
- Page 11 Step Three Attach the black fuse cable. Make sure to attached the GROUND cable to the bolt near the fuse box.
- Page 12 Once the blue indicator is on, which means that the sensor has detected motions. The intelligent hardwire kit will power up the dash cam automatically and start recording until the motion is cleared.
-
Page 13: Warranty And Support
Warranty & Support Warranty The Rexing Inteligent Hardwire Kit comes with a full 12-month warranty. If you register your product on our official site (https://www.rexingusa.com/support/registration), you can extend the warranty to 18 months. Support If you have any questions regarding your product, please do not hesitate to contact us at care@rexingusa.com, or call us at...
