AirClean systems PowderSafe AC730C Operator's Manual page 22

CAUTION: Disconnect the linecord from the power entry module
prior to proceeding.
Fluorescent Light Bulb Replacement -AC740:
1. Remove the linecord from the power entry module as shown in figure 5.
2. Using a philips head screwdriver, remove the two mounting screws that hold
the light tray in place, located on the right side of the enclosure. See figure 11.
3. Once the screws are removed, slide the light tray until you see the black
connector. See figure 12.
4. Grasp both sides of the electrical connector and turn the collar counter-
clockwise to release. See figure 13.
Figure 11.
Figure 12.
Figure 13.
22
