- Page 1 USER GUIDE 6 0 C M F R E E S T A N D I N G D I S H W A S H E R T D X 7 S S - 6 TECHNIKA.COM.AU...
-
Page 3: Table Of Contents
CONTENTS TABLE 1. Safety Information__________________________ 4 2. Product Overview__________________________ 7 3. Installation Instructions______________________ 8 About Power Connection_______________________ 8 Water Supplier and Drain_______________________ 9 Connection of Drain Hoses_____________________ 10 Position the Appliance_________________________ 11 Freestanding Installation_______________________ 11 4. Using the Dishwasher_______________________ 12 Control Panel________________________________ 13 Function of the Rinse Aid and Detergent____________15 Filling the Rinse Aid Dispenser___________________ 16... -
Page 4: Safety Information
SAFETY INFORMATION Warnings When using your dishwasher , follow the precautions listed below: • Installation and repair can only be carried out by a qualified technician • This appliance is intended to be used in household and similar applications such as: - staff kitchen areas in shops, offices and other working environments;... - Page 5 SAFETY INFORMATION Earthing Instructions • This appliance must be earthed. In the event of a malfunction or breakdown, earthing will reduce the risk of an electric shock by providing a path of least resistance of electric current. This appliance is equipped with an earthing conductor plug. •...
- Page 6 SAFETY INFORMATION Disposal • For disposing of package and the appliance please go to a recycling center. Therefore cut off the power supply cable and make the door closing device unusable. • Cardboard packaging is manufactured from recycled paper and should be disposed in the waste paper collection for recycling.
-
Page 7: Product Overview
PRODUCT OVERVIEW IMPORTANT: To get the best performance from your dishwasher, read all operating instructions before using it for the first time. Top spray arm Inner pipe Lower spray arm Filter assembly Dispenser upper spray arm Cup rack Cutlery rack Upper basket Lower basket NOTE:... -
Page 8: Installation Instructions
INSTALLATION INSTRUCTIONS Electrical Shock Hazard Disconnect electrical power before installing dishwasher. Failure to do so could result in death or electrical shock. Attention The installation of the pipes and electrical equipments should be done by professionals. About Power Connection For personal safety: Do not use an extension cord or an adapter plug with this appliance. -
Page 9: Water Supplier And Drain
INSTALLATION INSTRUCTIONS Water Supply and Drain Cold water connection Connect the cold water supply hose to a threaded 3/4 inch connector and make sure that it is fastened tightly in place. If the water pipes are new or have not been used for an extended period of time, let the water run to make sure that the water is clear. -
Page 10: Connection Of Drain Hoses
INSTALLATION INSTRUCTIONS Connection of Drain Hoses Insert the drain hose into a drain pipe with a minimum diameter of 4 cm, or let it run into the sink, making sure to avoid bending or crimping it. The height of drain pipe must be less than 1000mm. The free end of the hose must not be immersed in water to avoid the back flow of it. -
Page 11: Position The Appliance
INSTALLATION INSTRUCTIONS Position The Appliance Position the appliance in the desired location. The back should rest against the wall behind it, and the sides, along the adjacent cabinets or walls. The dishwasher is equipped with water supply and drain hoses that can be positioned either to the right or the left sides to facilitate proper installation. -
Page 12: Using The Dishwasher
USING THE DISHWASHER Please read the corresponding content in the instruction manual for detailed operating method. Install the dishwasher Inside Outside Loading the baskets Removing the larger residue on the cutlery Filling the dispenser Selecting a program and running the dishwasher PG 12... -
Page 13: Control Panel
USING THE DISHWASHER Control Panel Operation (Button) Press this button to turn on your dishwasher, the screen lights up. Power Press this button to select the appropriate washing program, corresponding Program indicator will be lit. Press the button to add or decrease the delay time, maximum 24 hours delay Delay -/+ can be defined. - Page 14 USING THE DISHWASHER Display To show the reminding time, delay time, error code etc. To Screen show the washing temperature. Auto For lightly, normally or heavily soiled crockery with or without dried-on food. Intensive For heaviest soiled crockery, and normally soiled pots, pans, dishes etc.With dried-on food.
-
Page 15: Function Of The Rinse Aid And Detergent
USING THE DISHWASHER Function Of The Rinse Aid And Detergent The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can leave spots and streaks. It also improves drying by allowing water to roll off the dishes. -
Page 16: Filling The Rinse Aid Dispenser
USING THE DISHWASHER Filling The Rinse Aid Dispenser Rinse-Aid indicator Remove the rinse aid dispenser Pour the rinse aid into the dispenser, cap by rotating it counterclockwise. NOTE: Clean up any spilled rinse aid with an absorbent cloth to avoid excessive foaming during the next wash. -
Page 17: Filling The Detergent Dispenser
USING THE DISHWASHER Filling The Detergent Dispenser Push latch to open deterge nt Press the release catch on the dispenser Add detergent into the larger cavity to open the cover. (A) for the main wash cycle. For more heavily soiled wash loads, also add some detergent into the smaller cavity (B) for the pre-wash cycle . -
Page 18: Basket Use Tips
USING THE DISHWASHER Basket Use Tips Adjusting the upper basket Type 1: The height of the upper basket can be easily adjusted to accommodate taller dishes in either the upper or lower basket. Folding back the cup shelves To make room for taller items in the upper basket, raise the cup rack upwards. -
Page 19: Preparing And Loading Dishes
USING THE DISHWASHER • Consider buying utensils which are identified as dishwasher-proof. • For particular items, select a program with the lowest possible temperature. • To prevent damage, do not take glass and cutlery out of the dishwasher immediately after the program has ended. - Page 20 USING THE DISHWASHER • Load hollow items such as cups, glasses, pans etc. With the opening facing downwards so that water cannot collect in the container or a deep base. • Dishes and items of cutlery must not lie inside one another, or cover each other. •...
- Page 21 USING THE DISHWASHER Loading the upper basket The upper basket is designed to hold more delicate and lighter dishware such as glasses, coffee and tea cups and saucers, as well as plates, small bowls and shallow pans (as long as they are not too dirty). Position the dishes and cookware so that they will not get moved by the spray of water.
-
Page 22: Loading The Baskets According To As/Nzs 2007.1
USING THE DISHWASHER Loading The Baskets According To AS/NZS 2007.1 1. Upper basket: Number Item Cups Saucers Glasses 2. Lower basket: Item Number Dinner plates Soup plates Dessert dishes PG 22... - Page 23 USING THE DISHWASHER 3. Cutlery basket: Item Number Forks Soup spoons Dessert spoons 4 4 4 Teaspoons Knives Information for comparability tests in accordance with (*AS/NZS 2007.1 ) Capacity: 14 place settings Position of the upper basket: lower position Program: ECO Rinse aid setting: 6 Detergent(Pre/main): 5g/27.5g Door is open at the end of the drying cycle for the drying performance test (Door position: Open 50 mm)
-
Page 24: Programming The Dishwasher
PROGRAMMING THE DISHWASHER Wash Cycle Table The table below shows which programs are best for the levels of food residue on them and how much detergent is needed. It also show various information about the programs. )Means: need to fill rinse into the Rinse-Aid Dispenser. Description Energy Water... -
Page 25: Starting A Cycle Wash
PROGRAMMING THE DISHWASHER Program Description Detergent Running Energy Water Rinse of Cycle Pre/Main Time(min) (Kwh) Wash(40℃ ) Rinse(50℃) 0.60 11.5 Rapid Rinse(55℃) Prewash 0.02 Soak Note: AS/NZS 2007.1: This program is the test cycle. The information for comparability test in accordance with AS/NZS 2007.1. -
Page 26: Forgot To Add A Dish
PROGRAMMING THE DISHWASHER Forget To Add A Dish A forgotten dish can be added any time before the detergent dispenser opens. If this is the case, follow the instructions below: 1. Press the Start/Pause button to pause the washing. 2. After the spray arms stop working, you can open the door completely. 3. -
Page 27: Maintenance & Cleaning
MAINTENANCE AND CLEANING External Care The door and the door seal Clean the door seals regularly with a soft damp cloth to remove food deposits. When the dishwasher is being loaded, food and drink residues may drip onto the sides of the dishwasher door. These surfaces are outside the wash cabinet and are not accessed by water from the spray arms. - Page 28 MAINTENANCE AND CLEANING WARNING Do not over tighten the filters. Put the filters back in sequence securely, otherwise coarse debris could get into the system and cause a blockage. Never use the dishwasher without filters in place. Improper replacement of the filter may reduce the performance level of the appliance and damage dishes and utensils.
- Page 29 MAINTENANCE AND CLEANING Spray arms Wash the arms in soapy and warm water and use a soft brush to clean the jets. Replace them after rinsing them thoroughly. It is necessary to clean the spray arms regularly for hard water chemicals will clog the spray arm jets and bearings.
-
Page 30: Caring For The Dishwasher
MAINTENANCE AND CLEANING Caring For The Dishwasher Frost precaution Please take frost protection measures on the dishwasher in winter. Every time after washing cycles, please operate as follows: 1. Cut off the electrical power to the dishwasher at the supply source. 2. -
Page 31: Troubleshooting Tips
TROUBLESHOOTING TIPS PG 31... - Page 32 TROUBLESHOOTING TIPS PG 32...
- Page 33 TROUBLESHOOTING TIPS PG 33...
- Page 34 TROUBLESHOOTING TIPS PG 34...
-
Page 35: Error Codes
ERROR CODES If there is a malfunction, the dishwasher will display an error code. The following table shows possible error codes and their causes. Codes Meanings Possible Causes Faucets is not opened, or water intake is restricted, or Longer inlet time. water pressure is too low. -
Page 36: Technical Information
TECHNICAL INFORMATION Height (H) 845mm Width (W) 598mm Depth (D1) 600mm (with the door closed) Depth (D2) 1175mm (with the door opened 90°) PG 36... -
Page 37: Product Fiche
PRODUCT FICHE Manufacturer TECHNIKA Type / Description TDX7SS-6 Standard place settings Water consumption class Standard cleaning cycle Energy consumption of the standard cleaning cycle 0.71 kWh Water consumption of the standard cleaning cycle 12.5 litre Program duration of the standard cleaning cycle... - Page 38 Subject to the exclusions below, we warrant that the product will not have any electrical or mechanical breakdowns within: a) In the case of Technika Professional products used for personal, domestic or household purposes, a period of 2 years from the date the product is purchased as a brand-new product from a retailer located in Australia / New Zealand.
- Page 39 MANUFACTURER GUARANTEE The product requires repairs due to damage resulting from accident, misuse, incorrect installation, insect or vermin infestation, improper liquid spillage, cleaning or maintenance, unauthorised modification, use on an incorrect voltage, power surges and dips, voltage supply problems, tampering or unauthorised repairs by any persons, use of defective or incompatible accessories or exposure to abnormally corrosive conditions, events independent of human control which occurred after the goods left the control of Glen Dimplex;...
- Page 40 MANUFACTURER GUARANTEE Warranty claims If you make a valid claim under this warranty and none of the exclusions set out in section 2 apply, we will, at our election, either repair the product or replace the product with a product of identical specification (or where the product is superseded or no longer in stock, with a product of as close a specification as possible).
- Page 41 NOTES PG 41...
- Page 42 MANUFACTURER GUARANTEE READ THE INSTRUCTION BOOKLET BEFORE INSTALLING AND USING THE APPLIANCE. The manufacturer will not be responsible for any damage to property or to persons caused by incorrect installation or improper use of the appliance. The manufacturer is not responsible for any inaccuracies, due to printing or transcription errors, contained in this manual.
