Shark CORDLESS SV780 Quick Start Manual

SV780

FEATURES

Air-Intake Nozzle
A G
Dust Cup
B H
Dust Cup Filter
C I
Dust Cup Release Button
D J
Charging Indicator Light
E K
On/Off Switch
F
Technical Specifications: 15.6-Volt DC
K
J
I
G
H
IMPORTANT SAFETY INSTRUCTIONS – FOR HOUSEHOLD USE ONLY
WARNING
To reduce the risk of injury, fire, electric shock, and property damage
resulting from improper use of the appliance, carefully observe the
following instructions. This unit contains electrical connections and
moving parts that potentially present risk to the user.

POWER SUPPLY, CHARGING ADAPTER, AND HAND VACUUM

CONTAIN ELECTRICAL CONNECTIONS:
1. There are NO serviceable parts.
2. DO NOT use to vacuum any liquids.
3. DO NOT immerse in water or other liquids.
4. Inspect charging adapter cord and plug for any damage before use. DO NOT use hand vacuum with a damaged charging
adapter cord or plug. Turn off all controls before plugging in or unplugging the hand vacuum from the adapter.
5. DO NOT use or charge unit outdoors or on wet surfaces. Use only on dry surfaces.
6. If hand vacuum is not working as it should, or has been dropped, damaged, left outdoors, or dropped into
water, return it to SharkNinja Operating LLC for examination, repair, or adjustment.
7. DO NOT pull or carry the charging adapter by the cord or use the cord as a handle.
8. DO NOT unplug the charging adapter by pulling on the cord. Grasp the plug, not the cord.
9. DO NOT handle charging adapter or hand vacuum with wet hands.
10. DO NOT use charging adapter with an extension cord.
11. Use only the charging adapter model XA780N supplied with this appliance.
12. Keep charging adapter cord away from heated surfaces.
13. This hand vacuum includes rechargeable nickel metal hydride batteries. Batteries must be recycled or
disposed of properly. DO NOT incinerate batteries or expose to high temperatures as they may explode.
14. Leaks from battery cells can occur under extreme conditions. If the liquid gets on skin, wash immediately
with soap and water. If the liquid gets into eyes, flush them immediately with clean water for a minimum
of 10 minutes and seek medical attention.

GENERAL USE

15. Use only as described in this manual.
16. Keep your work area well lit.
17. Keep the vacuum cleaner moving over the carpet surface at all times to avoid damaging the carpet fibers.
18. DO NOT place hand vacuum on unstable surfaces such as chairs or tables.
19. DO NOT put any objects into openings. DO NOT use with any opening blocked; keep free of dust, lint, hair, and
anything that may reduce airflow.
20. DO NOT allow the appliance to be used by children. Close attention is necessary when used near children. This is not a toy.
21. DO NOT use without dust cup and filter in place.
22. ALWAYS turn off the hand vacuum before connecting or disconnecting the air-intake nozzle.
Motor Housing
Charging Base
Charging Adapter
Motorized Brush
Crevice Tool
A
B
C
1. Before charging for the first
D
time, make sure the power
switch is off.
E
2. Connect charging adapter
to port on the bottom of the
charging base. Turn the charge
F
adapter plug clockwise one-
quarter of the way around to
secure it place.
READ CAREFULLY BEFORE USE – SAVE THESE INSTRUCTIONS

CHARGING YOUR HAND VACUUM

1
ON
OFF
3
3. Plug charging adapter into a
wall outlet and place the hand
vacuum on the charging base.
The Charging Indicator light
will illuminate.
4. Remove the hand vacuum
from the charging adapter
when the Charging Indicator
light turns off. See "Maximizing
the Life of Your Battery."

DUST CUP, FILTER, AND ACCESSORIES

Before turning on the hand vacuum:
23. Make sure filter is thoroughly dry after routine cleaning.
24. Make sure dust cup and filter are in place.
25. Make sure accessories are free of blockages.
26. Use only Shark® brand filters and accessories. Using other brands will void warranty.

GENERAL CLEANING

27. DO NOT vacuum up large objects.
28. DO NOT vacuum up hard or sharp objects such as glass, nails, screws, or coins that could damage the hand vacuum.
29. DO NOT vacuum up drywall dust, fireplace ash, or embers. DO NOT use as an attachment to power tools for dust collection.
30. DO NOT vacuum up smoking or burning objects such as hot coals, cigarette butts, or matches.
31. DO NOT vacuum up flammable or combustible materials (e.g., lighter fluid, gasoline, or kerosene) or use hand
vacuum in areas where they may be present.
32. DO NOT vacuum up toxic solutions (e.g., chlorine bleach, ammonia, or drain cleaner).
33. DO NOT use in an enclosed space where vapors are present from paint, paint thinner, moth-proofing
substances, flammable dust, or other explosive or toxic materials.
34. Use extra care when cleaning on stairs.

NI-MH BATTERY

35. WARNING: The cordless hand vacuum is powered by Ni-MH batteries, which must be recycled or disposed of
properly in accordance with state, federal, and local laws.
36. If uncertain as to how to remove the battery pack, we suggest that you take your hand vacuum to a reputable small
appliance service technician to have this service performed.
37. WARNING: DO NOT attempt to replace the batteries used in this hand vacuum with any other type of battery.
38. WARNING: NEVER use ordinary batteries for replacement as these may leak and damage your hand vacuum. Use only the
battery pack provided by SharkNinja.

MAXIMIZING THE LIFE OF YOUR BATTERY

39. DO NOT store the unit with the charging adapter attached and plugged in.
40. DO NOT store in areas of high temperature or humidity.
41. Use only the charging adapter supplied with the hand vacuum. If other chargers are used, the batteries can fail, causing
damage to the battery, hand vacuum, or personal property.
42. After 3 months of non-use, the hand vacuum should be fully discharged and then recharged to maximize battery power.
43. If the hand vacuum has never been stored for an extended period of time without use, it will take several complete
charge and discharge cycles to realize the full operational time of your hand vacuum.
44. Ni-MH batteries have a long, useful life but will eventually need to be replaced. To purchase replacement batteries, visit
sharkaccessories.com

HAND VACUUM ASSEMBLY AND USE

2 1
4 3
1. Push the Dust-Cup Release button and remove the dust cup
to verify that the filter is inside. Reinstall the dust cup.
2. Insert the desired accessory into the air-intake nozzle.
3. Press the power switch to turn on the hand vacuum.
NOTE: During first use, discharge fully to properly condition the
battery. It takes approximately 2.5 hours to charge battery completely.
NOTE: For maintenance, see reverse side.
2
