Grifco E138G Quick Start Manual

+
For use with eDrive 2.0 with radio-on-board.
GRIFCO FRONT PANEL

OPERATION

The E138G TOP bu�on can be used to TOGGLE the ac�on of the door between close / stop / open if an obstruc�on detec�on device is installed,
or stop / open only if no obstruc�on detec�on device is installed.
The E138G LOWER bu�on can be used to CLOSE the door. If no obstruc�on detec�on device is installed, the LOWER key must remain pressed to complete the door close sequence.
grifco.com.au
grifco.co.nz
1. UP - Moves the door upwards
2. DOWN - Moves the door downwards
3. STOP - Stops the door
4. SET - SET bu�on
POWER ON - Shows when the unit is
5.
mains powered
6. STATUS - Shows the status of the unit
7. LIMIT ERROR – When lit indicates
limits are not set
WIRELESS WALL CONTROL – MODEL E138G
To prevent possible SERIOUS INJURY or DEATH from a moving door:
Use Wireless Entry Device within sight of the door and out of reach of children
•
• ALWAYS keep remote controls out of reach of children. NEVER permit children to operate, or play with remote
controls.
• Ac�vate door ONLY when it can be seen clearly, is properly installed, and there are no obstruc�ons to the door travel.
•
ALWAYS keep the door in sight un�l completely closed. NEVER permit anyone to cross the path of a moving door
•
NEVER allow small children near ba�eries. If ba�ery is swallowed, immediately no�fy your doctor.
PROGRAMMING
TOP
Bu�on
LOWER
Bu�on
E138G
Wireless Wall
Control

WARNING

To program the E138G Wireless Entry Device ensure the radio lock
is removed then perform the following steps:
1. Press and hold the SET bu�on on the GRIFCO front panel,
then
While holding the SET bu�on, press the STOP bu�on 5 �mes
2.
(the green status light will light then con�nue flashing,
indica�ng learn mode)
3. Let go of the SET bu�on
4. Press the E138G TOP bu�on
5. Then press the E138G LOWER bu�on
6. The orange LIMIT ERROR light will flash each �me to
acknowledge the bu�on has been pressed.
7. Press STOP bu�on on the GRIFCO front panel (the green light
will con�nue to flash).
8. Press the E138G LOWER bu�on again
9. The green light will go out indica�ng exit learn mode.
10. Install the RADIO LOCK key on the eDrive2 board to prevent
any further wireless entry devices being learned.
