- Page 1 CR-IR346CL Operation Manual FUJI COMPUTED RADIOGRAPHY CR Console Annotation Option Function OPERATION MANUAL First Edition December 2002 MADE IN JAPAN FUJI PHOTO FILM CO., LTD. TOKYO 106-8620 010-204-00 Fuji Photo Film Co., Ltd. 2002. 12...
-
Page 2: Table Of Contents
CR Console Operation Manual CONTENTS INTRODUCTION _____________________________________________ 3 Operation Procedures ________________________________________ 4 1. Annotation Input ......................6 2. Annotation Editing ..................... 10 3. Annotation Deletion ....................12 4. Cautions ........................14 010-204-00 Fuji Photo Film Co., Ltd. 2002. 12... -
Page 3: Introduction
CR Console Operation Manual INTRODUCTION This operation manual describes how to operate the annotation option function on the CR Console. For details of other functions/operations, see the “CR Console Operation Manual” (No.: 010-034-xx) and “CR Console Operation Manual - Supplement: User Utility Operations”... -
Page 4: Operation Procedures
CR Console Operation Manual Operation Procedures The annotation option function enables input /editing/deletion of annotations on the read images. Display the image editing window for each image or study according to the procedure as has been used previously, and select the “Processing” folder tab. (The operation procedure will be explained herein using the image editing window for each image. - Page 5 CR Console Operation Manual The annotation input box will appear. You can also select on the marker input box to display the annotation input box. Selecting on the annotation input box will complete marker input processing, and selecting on the same box will cancel processing performed on the marker input box.
-
Page 6: Annotation Input
CR Console Operation Manual Annotation Input This function allows to input an annotation on a read image. (Artifacts may appear around the input annotation due to spatial frequency processing when the annotation-added image is displayed or output on film by other devices.) Select . - Page 7 CR Console Operation Manual Select a character font and size. Input characters in the input field, then select Characters thus input will be determined. A maximum of 32 annotations can be input for each image by inputting characters and then pasting them repeatedly.
- Page 8 CR Console Operation Manual To change the character color/background color of an annotation, select the target annotation and then select any of the icons shown below. : White characters/black background : White characters/transparent background : Black characters/white background : Black characters/transparent background After selecting any of the icons above, select .
- Page 9 CR Console Operation Manual : Cancels the operation. : Displays the marker input box. If is selected on the marker input box, the annotation input completes. If is selected, the operation performed on the annotation input box will also be canceled.
-
Page 10: Annotation Editing
CR Console Operation Manual Annotation Editing This function allows to edit an input annotation. Select Select an annotation you want to edit. Whether the annotation is selected or unselected for editing can be changed alternately every time it is selected. - Page 11 CR Console Operation Manual The content of a selected annotation will be displayed. Make corrections as necessary. To correct the content of the input field, select after corrections have been made accordingly. Select then 010-204-00 Fuji Photo Film Co., Ltd.
-
Page 12: Annotation Deletion
CR Console Operation Manual Annotation Deletion This function allows to delete any input annotation. Select Select (Delete All Annotations) or have an annotation in selected state, then select (Delete). 010-204-00 Fuji Photo Film Co., Ltd. 2002. 12... - Page 13 CR Console Operation Manual After performing steps above, select NOTE • The Delete icon on the annotation input box does not delete markers input on the marker input box. Use the marker input box to delete those markers. Similarly, the Delete icon on the marker input box does not delete annotations input on the annotation input box.
-
Page 14: Cautions
CR Console Operation Manual Cautions • If exposure menus are changed or images substituted for images where annotations have been input, annotations thus input will be erased. • When annotations are input on images composed using optional image composition processing, annotations thus input will be erased if those images are subjected to recomposition processing. - Page 15 CR Console Operation Manual 010-204-00 Fuji Photo Film Co., Ltd. 2002. 12...
- Page 16 CR Console Operation Manual European Authorized Representative : FUJIFILM MEDICAL SYSTEMS U.S.A., INC. FUJI PHOTO FILM (Europe) GmbH 419 WEST AVENUE, STAMFORD CT 06902, U.S.A. Heesenstrasse 31, D-40549 Düsseldorf Germany 010-204-00 Fuji Photo Film Co., Ltd. 2002. 12...
