- Page 1 CR Console Operation Manual FUJI COMPUTED RADIOGRAPHY CR Console Portable Exposure Function OPERATION MANUAL 3rd Edition October 2006 2006. 10 897N0721B...
- Page 2 This Product contains software ("Software") and related written materials ("Documentation"). The term "Software" shall include any updates, upgrades, modified versions, additions and copies of the Software licensed to you by FUJIFILM Corporation ("FUJI"). 1. License. Subject to the terms and conditions of this Agreement, you are granted a limited, non-exclusive, non-transferable and non-sublicensable license to use the Software and the Documentation only on a single computer until such rights are terminated according to Section 8 below.
- Page 3 1. No part or all of this manual may be reproduced in any form without prior permission. 2. The information contained in this manual may be subject to change without prior notice. 3. FUJIFILM Corporation shall not be liable for malfunctions and damages resulting from installation, relocation, remodeling, maintenance, and repair performed by other than dealers specified by FUJIFILM Corporation.
-
Page 4: Table Of Contents
CR Console Operation Manual CONTENTS INTRODUCTION PRECAUTIONS FOR USE OPERATIONS 1. Overview ......................6 Names and functions of the POCKET id Console's exterior features ..7 • Battery charging ................8 • Making a connection with the CR Console ........9 • Scanning a barcode ................9 •... -
Page 5: Introduction
CR Console Operation Manual INTRODUCTION This manual explains how to operate the portable exposure function at the CR Console. For other functions/operations, refer to the “ CR Console OPERATION MANUAL ” and “ CR Console OPERATION MANUAL, THE USER UTILITY OPERATIONS. ” PRECAUTIONS FOR USE When using the POCKET id Console, basic safety precautions should always be followed, including the following, in order to forestall any possible trouble. -
Page 6: Operations
CR Console Operation Manual OPERATIONS Overview The portable exposure function represents a function designed to enable the registration of IPs outside the X-ray room. By importing study information into this POCKET id Console from the CR Console, it becomes possible to register IPs on this hand-held unit. IP-registered information can be reflected on the CR Console. -
Page 7: Names And Functions Of The Pocket Id Console's Exterior Features
CR Console Operation Manual Names and functions of the POCKET id Console's exterior features Scan LED Scan window LED display Left scan trigger button Right scan trigger button Keypad * (As an example, a standard 6-key arrangement is shown.) *1 The keypad may apparently differ slightly from the real one. -
Page 8: Battery Charging
CR Console Operation Manual Operation Up scroll key Takes you to the next higher study on a Study list window or to the next higher exposure menu item on a study screen. Down scroll key Takes you to the next lower study on the Study list window or to the next lower exposure menu item on a study window. -
Page 9: Making A Connection With The Cr Console
CR Console Operation Manual • Making a connection with the CR Console When you place the POCKET id Console in the cradle and make a connection with the CR Console, the following dialog box is displayed on the POCKET id Console. After the connection has been established, the dialog box disappears and the POCKET id Console screen appears. -
Page 10: Installing The Battery
CR Console Operation Manual • Installing the battery Use the following procedure to install the battery. 1) Turn the setscrew counterclockwise until the battery cover comes off. 2) Remove the battery cover from the POCKET id Console housing. Setscrew Battery cover 3) As shown in the illustration below, correctly orient the battery tab and place the lithium-ion battery into the battery compartment. -
Page 11: Startup And Shutdown Of The Pocket Id Console
CR Console Operation Manual Startup and shutdown of the POCKET id Console Startup: Turn on the power. The application software will automatically start. When the maintenance setting of the log-in function has been enabled, the log-in screen appears on power-up. After filling in the “... -
Page 12: About Power Control
CR Console Operation Manual About power control In order to prolong operation time, a power-saving feature is incorporated. If the POCKET id Console has gone into power-saving mode and the screen is out, press the power button. The time before the POCKET id Console enters power-saving mode has been set beforehand. -
Page 13: Routine Operation
CR Console Operation Manual Routine Operation Step1. Transmitting a study In this step, you transmit a portable exposure study from the CR Console to the POCKET id Console. Place the POCKET id Console into the dedicated cradle. If the Study list window is being displayed on the POCKET id Console, communication with the CR Console will start. - Page 14 CR Console Operation Manual Transmit a study from the CR Console to the POCKET id Console. Depending on the study reservation method taken on the CR Console, perform an appropriate operation described in one of the following pages. 1) Making study reservation on the CR Console ..page 16 2) Worklist (1) With stock (Stored entry present) .....page 17 (2) Without stock (No stored entry) ....page 18...
- Page 15 CR Console Operation Manual NOTE • You cannot transmit a study which has already been transmitted (checked out) to another POCKET id Console. To cancel the transmitted (checked-out) status, you must perform cancellation of the transmitted status of a study. To do so, select a study on which you want to cancel the transmitted status on the Local WL list, and then click the button.
- Page 16 CR Console Operation Manual 1) Making study reservation on the CR Console This is a method to select a study (studies) which has been reserved on the CR Console and then transfer it (them) to the POCKET id Console. Make a study reservation using the conventional operation. Select a study (studies) on the “...
- Page 17 CR Console Operation Manual 2) Worklist In this method, studies that have been received from the RIS (Radiology Information System) are transmitted to the POCKET id Console. (When using a worklist, which procedure, for the (1) With stock or (2) Without stock case, can be used depends on the maintenance setting.) If the POCKET id Console is not sitting in the cradle at the time of transmission, a transmission failure message appears.
- Page 18 CR Console Operation Manual To transmit the stocked studies to the POCKET id Console, choose . The state of waiting for studies to receive is turned off ( is indicated), and the stocked studies are automatically transmitted to the POCKET id Console. (2) Without stock Select a study (studies) in the “...
-
Page 19: Step2. Study List Operation
CR Console Operation Manual Step2. Study list operation A portable exposure study that has been received by the POCKET id Console is displayed on the Study list window. List tabs List tabs : Display various lists. “ Unfinished ” ..Lists information on studies, each of which has some of its exposure menus not completed with IP registration yet. -
Page 20: Patient Id Verification
CR Console Operation Manual Patient ID verification Study information can be verified using a patient ID number. On the Study list window, read the barcode of the patient ID number with the barcode reader. If the patient ID number cannot be read with the barcode reader for some reason, the soft numeric-key pad can be used to enter the patient ID number. -
Page 21: Displaying Detailed Information Of A Study
CR Console Operation Manual CR Console Operation Manual Displaying detailed information of a study You can view detailed information of a study. Select a study, and then select “ Pt Detail .” The study detailed information dialog box appears. Choosing “... -
Page 22: Deleting Study Information
CR Console Operation Manual Deleting study information You can delete study information. A deleted study can also be deleted on the CR Console when it is received by the CR Console. (Page 32 ) Select a study to delete, and choose “ Dlt Study .” A confirmation dialog appears. -
Page 23: Sort Order Setting
CR Console Operation Manual Sort order setting You can set the sort order of lists. The set sort order is applied to all lists. Selecting “ Sort ” displays the sort dialog box. Select sort-key priorities and the sort order for each sort keys, and then choose “ OK .” Cancel : Cancels the operation. -
Page 24: Step3. Starting A Study
CR Console Operation Manual Step3. Starting a study In this step, you can display the study window and start a study as follows. Select a study and then choose “ Start study .” The Study window appears. Exposure menu list Technologist display field : Lists exposure menus. -
Page 25: Ip Registration
CR Console Operation Manual The layout of display items shown in the upper part of the window, as well as the order in which the function buttons including “ Change Tech ” are displayed, can be set from the User Utility. - Page 26 CR Console Operation Manual NOTE • If the ID number that has just been entered is already registered with an exposure menu of a study being held by the POCKET id Console, the following confirmation dialog appears. Select either of the options. Yes : Cancels the IP registration of the same IP number to the existing exposure menu, and registers the IP number to the currently selected exposure menu.
-
Page 27: Image Rotation/Flip Setting
CR Console Operation Manual Image rotation/flip setting You can set an image rotation/flip mode. After selecting an exposure menu, select “ RotateFlip .” The image rotation/flip setting dialog appears. Select one of the icons, and choose “ OK .” : Normal image : Flips horizontally. -
Page 28: Changing Technologist
CR Console Operation Manual Changing technologist You can change the technologist. The technologist change is reflected to all exposure menus of the currently displayed study, each of which has no IP registered to it. After selecting an exposure menu that has no IP registered to it yet, choose “ Change Tech .” The technologist selection dialog appears. -
Page 29: Adding An Exposure Menu
CR Console Operation Manual Adding an exposure menu You can add the same exposure menu as the exposure menu selected. The added exposure menu will be also added to the study on the CR Console at the time of reception by the CR Console. -
Page 30: Step4. Completing A Study
CR Console Operation Manual Step4. Completing a study To end the current study, perform the procedure below. Choose “ Study Cmplt .” If IP registration has been done for all exposure menus of the study: This window closes, and you are taken back to the Study list window. The study is displayed on the “... -
Page 31: Step5. Receiving A Study
CR Console Operation Manual Step5. Receiving a study In this step, the CR Console receives studies that have been completed on the POCKET id Console after IP registration. Place the POCKET id Console on its dedicated cradle. Whenever receiving studies, be sure to perform receive operation on the source CR Console from which the studies have been transmitted. - Page 32 CR Console Operation Manual While studies are being received, a message is displayed on both the CR Console and the POCKET id Console. When the study reception completes after a while, the Study list window on the POCKET id Console is updated. The studies that have been received are deleted from the POCKET id Console.
-
Page 33: User Utility
CR Console Operation Manual User Utility Customizing the POCKET id Console window The POCKET id Console window can be customized (in terms of the layout of items that are displayed) using the following procedure. (1) Starting the User Utility → Selecting “ P.Console. ” Start the User Utility, and then select “... - Page 34 CR Console Operation Manual (3) Performing customization The “ Customization of the P.Console window - User Utility ” appears. Select a tab to display its folder, and perform customization operation. Then, select “ Transmission ” to transmit the settings to the POCKET id Console. (See page 43 .) Be aware, the settings are not reflected unless this transmission is done.
- Page 35 CR Console Operation Manual <Study list window - Display items> Sets the layout of items to be displayed on the Study list window. <Study list window> Display items Select a number of studies to display on the Study list. Eight studies (One-column layout) : Displays eight studies, using one row for each study.
- Page 36 CR Console Operation Manual With an item you want to display being selected on the left list, set “ Width ,” “ Height ,” and “ Position ,” and select “Determined.” Repeat this operation the number of times as that equals the number of items to display. : Enter the width in which to display an item within a range of 1 to 12.
- Page 37 CR Console Operation Manual <Study list window - function buttons> Sets the display order of the function buttons on the Study list window. <Study list window> Function buttons Select a registered function button, and then choose (to the left in the window) / (to the right in the window).
- Page 38 CR Console Operation Manual <Study window - Display items> Sets the layout of items to be displayed on the Study list window. <Study list window> Display items Select an item you want to display from the list on the left, set the “ Width ,” “ Height ,” and “...
- Page 39 CR Console Operation Manual Width : Enter the width of the display item within the range from 1 to 12. : Enter the height of the display item within the range from 1 to 5. Height Position : Enter the start point of the display item by selecting a screen layout position number from among numbers 0 to 59.
- Page 40 CR Console Operation Manual <Study window - Function buttons> Sets the display order of function buttons on the Study list window. <Study window> Function buttons Select a registered function button, and then choose (to the left in the window) / (to the right in the window).
- Page 41 CR Console Operation Manual <Study window - Detailed information> Customizes the items to display in the detailed information box. <Study window> Detailed information Show / hide : Switches whether to show or hide each item. Select and checkmark the checkbox of each item you want to show. Unchecked items are set to be hidden.
- Page 42 CR Console Operation Manual <Detailed study information dialog - Detailed information> Customize items to be displayed on the Detailed study information dialog. <Detailed study information dialog> Show / hide : Switches whether to show or hide each item. Select and checkmark the checkbox of each item you want to show. Unchecked items are set to be hidden.
- Page 43 CR Console Operation Manual (4) Transmitting the settings Save the settings and transmit them to the POCKET id Console. Place the POCKET id Console on the dedicated cradle. Then, with the Study list window being displayed, choose “ Transmission .” The confirmation dialog box appears.
-
Page 44: Transmitting Technologist Information
CR Console Operation Manual Transmitting technologist information Transmit technologist information to the POCKET id Console using the following procedure. (1) Startup of the User Utility → Selecting “ P.Console ” Start up the User Utility, and select “ P.Console .” (2) Selecting a menu option The “... - Page 45 CR Console Operation Manual (4) End of transmission When the transmission completes, the confirmation dialog box appears. Choose “ OK .” 2006. 10 897N0721B...
-
Page 46: Setup Of A Portable-Study Ending Procedure
CR Console Operation Manual Setup of a portable-study ending procedure This setting determines how to end a study that has been performed with the POCKET id Console when all images have been received in the background. You can specify this setting in the User Utility's property setting window. Set the “ Setting for automatically finishing a study (Portable Console) ”... -
Page 47: Troubleshooting
CR Console Operation Manual Troubleshooting Problem Cause Action The POCKET id Consol Its lithium-ion battery is not Charge the lithium-ion battery in the would not turn on. charged. POCKET id Console, or replace the battery. The lithium-ion battery is not Load the battery correctly. -
Page 48: Major Specifications
CR Console Operation Manual Major Specifications Operating temperature range 14 to 122°F / -10 to 50°C Storage temperature range 13 to 158°F / -25 to 70°C Humidity range 5 to 90% (non-condensing) Electrostatic discharge (ESD) ±15 kVDC (air); ±8 kVDC (contact) Drop onto concrete 4ft / 1.2m Sealing... - Page 49 CR Console Operation Manual 2006. 10 897N0721B...
- Page 50 FUJIFILM MEDICAL SYSTEMS U.S.A., INC. 419 WEST AVENUE, STAMFORD CT 06902, U.S.A.
