Summary of Contents for Arcserve Appliance X Series
- Page 1 Hardware Setup Guide Arcserve Appliance X Series Storage Node Installation Guide...
-
Page 2: Table Of Contents
Access Arcserve Unified Data Protection (UDP) ........ -
Page 3: Product Ratings
Install near appropriate AC outlets, and Ethernet hubs or individual jacks. Be sure to install an AC Power Disconnect for the entire rack assembly. The Power Disconnect must be clearly marked. Ground the rack assembly properly to avoid electrical shock. Arcserve Appliance X Series Storage Node Hardware Installation Guide... -
Page 4: Unpacking The 5U Storage System Enclosure
DDICs ship in a separate container and must be installed into the enclosure drawers during product installation. For rackmount installations, due to the weight DDICs are installed after the enclosure is mounted in the rack. Arcserve Storage System Hardware Installation Guide... -
Page 5: Installing The Rails And The 5U Storage System Enclosure In The Rack
(see above) as shown. Secure the brackets to the rails (left hand rail shown above). Step 6: Reinsert the rear panel modules and proceed to Section 5 on page 6. Arcserve Appliance X Series Storage Node Hardware Installation Guide... -
Page 6: Installing The Ddics Into The 5U Storage System Enclosure
In a rack containing more than one U84 enclosure, do not open more than one drawer per rack at a time. Arcserve Appliance X Series Storage Node Hardware Installation Guide... -
Page 7: Rear Panel Components
Ethernet port used by management interfaces Reset button USB serial port (CLI) SAS ports 3 and 2 3.5 mm serial port (CLI) SAS ports 1 and 0 Continued on the next page Arcserve Appliance X Series Storage Node Hardware Installation Guide... -
Page 8: Rear Panel Controller Modules - A And B Led Detail
Blinking amber — Hardware-controlled power-up or a cache flush or restore error. Green — The controller is operating normally. Blinking green — System is booting. Off — The controller module is not OK, or is powered off. Arcserve Appliance X Series Storage Node Hardware Installation Guide... -
Page 9: Rear Panel Fan Cooling Modules 0 Through 4 Detail
9. Rear Panel Power Supply Units 0 and 1 Detail Module release latch Power OK LED (Green) Handle AC power inlet PSU Fault LED (Amber / blinking amber) Power I/O switch AC Fail LED (Amber / blinking amber) Arcserve Appliance X Series Storage Node Hardware Installation Guide... - Page 10 Storage Unit, Controller A, SAS port 1. On the server install the fourth cable into Slot 8, Port 1 (right port of HBA), then connect the other end to the Storage Unit, Controller B, SAS port 1. Arcserve Appliance X Series Storage Node Hardware Installation Guide...
-
Page 11: Front Panel Operation
This may be initiated from the controller module or an external HBA. The indication is typically associated with a DDIC and LEDs at each disk position within the drawer, which help to identify the DDIC affected. Continued on the next page Arcserve Appliance X Series Storage Node Hardware Installation Guide... - Page 12 Contact your service provider to resolve the problem. Activity Bar Graph Displays the amount of data I/O from zero segments lit (no I/O) to all six segments lit (maximum I/O). Arcserve Appliance X Series Storage Node Hardware Installation Guide...
-
Page 13: Run Arcserve Appliance Wizard
VMware ESX servers or Microsoft Hyper-V servers. You can back up data to either a local machine or a recovery point server. A recovery point server is a central server where backups from multiple sources are stored and can be globally deduplicated. For more information about Arcserve UDP, see the Knowledge Center at: arcserve.com/udp-knowledge-center. -
Page 14: Contact Support
Arcserve provides this document “as is” without warranty of any kind, including, without limitation, any implied warranties of merchantability, fitness for a particular purpose, or non-infringement. In no event will Arcserve be liable for any loss or damage, direct or indirect, from the use of this document, including, without limitation, lost profits, business interruption, goodwill or lost data, even if Arcserve is expressly advised in advance of the possibility of such damage.
