- Page 1 INSTALLATION & CONFIGURATION MANUAL DIO88 UNIVERSAL TRIPLE MODE, 16 CHANNEL AUDIO I/O CARD FOR QUAD SPEED ADD-ON APPLICATIONS...
- Page 2 (for manuals on hardware products) or on the EVS website on the following page: http://www.evs.com/contacts. User Manuals on EVS Website The latest version of Media Infrastructure manuals are available at: https://mi-sftp.evs.com/ The user manuals for other EVS products can be found at the EVS download center, on the following webpage: https://www.evs.com/en/download-area.
- Page 3 ● NEVER operate this product in an explosive atmosphere. Warranty: EVS warrants their products according to the warranty policy as described in the general terms. That means that EVS Broadcast Equipment SA can only warrant the products as long as the serial numbers are not removed.
-
Page 4: Table Of Contents
When Powering-up Default settings Changing settings and parameters Front Panel Control Example of changing parameters using front panel control EVS Cortex Menu Structure Example The DIO88 Card Introduction Applications Program Procedure ... -
Page 5: Introduction To Synapse
INCREASE SYSTEM FLEXIBILITY OF ONE OR MORE SYNAPSE FRAMES Although not required to use EVS Cortex with a Synapse frame, you are strongly advised to use a remote personal computer or laptop PC with EVS Cortex installed as this increases the ease of use and understanding... -
Page 6: Unpacking And Placement
DIO88 2 Unpacking and Placement Unpacking The EVS Synapse card must be unpacked in an anti-static environment. Care must be taken NOT to touch components on the card – always handle the card carefully by the edges. The card must be stored and shipped in anti-static packaging. -
Page 7: A Quick Start
Dolby digital plus output, using external incoming meta data program streams. Changing The front panel controls or EVS Cortex can be used to change settings. settings and An overview of the settings can be found in chapter 5, 6 and 7 of this parameters manual. -
Page 8: Example Of Changing Parameters Using Front Panel Control
INSTALLATION AND CONFIGURATION MANUAL DIO88 Example of With the display as shown below changing parameters using front panel RRC18 [Select Card] control >S01=SFS10 Pressing the ► selects the SFS10 in frame slot 01. The display changes to indicate that the SFS10 has been selected. In this example the Settings menu item is indicated. -
Page 9: Evs Cortex
EVS Broadcast Equipment SA EVS Cortex EVS Cortex can be used to change the settings of Synapse modules from a PC, either locally or remotely. The software enables communication based on TCP/IP between the Setup PC and Synapse frames/modules. Each Synapse frame is addressed through its rack controller’s unique IP address, giving access to each module, its menus and adjustment items. -
Page 10: The Dio88 Card
This card can be updated with new firmware when new firmware Procedure versions are released by EVS. You can download the .spf file from our website when new releases are announced. To upgrade the DIO88 you can follow the instructions as described in the ‘reprogramming cards... -
Page 11: Block Schematics
EVS Broadcast Equipment SA Block schematics DIO88 MODE 1 – 4IN/4OUT GAIN & PHASE AES/EBU IN 1/2 2 CHANNEL MONO DELAY SWITCH GAIN & PHASE GAIN & PHASE AES/EBU IN 3/4 2 CHANNEL MONO DELAY SWITCH GAIN & PHASE GAIN & PHASE... - Page 12 INSTALLATION AND CONFIGURATION MANUAL DIO88 DIO88 MODE 3 – 8 OUT GAIN & PHASE AES/EBU IN 1/2 2 CHANNEL MONO AES/EBU OUT 1/2 DELAY SWITCH GAIN & PHASE GAIN & PHASE AES/EBU IN 3/4 2 CHANNEL MONO AES/EBU OUT 3/4 DELAY SWITCH GAIN &...
-
Page 13: Settings Menu
DIO88 and enables the item to be changed or adjusted. Settings can be changed using the front panel of the Synapse frame (SFR18, SFR08 or SFR04) or EVS Cortex. Please refer to chapter 3 for information on the Synapse front panel control and EVS Cortex. -
Page 14: Gain-Ch_1
INSTALLATION AND CONFIGURATION MANUAL DIO88 PROCESS CONTROL Gain-CH_1 ~ These items allow you to gain the audio for each individual channel in a Gain-CH_16 range from –60dB to 12 dB in steps of 0.25 dB. –999dB mutes this channel. Default is 0dB. Phase-CH_1 ~ These items allow you to gain the audio for each individual channel with Phase-CH_16... -
Page 15: Status Menu
EVS Broadcast Equipment SA 6 Status Menu Introduction The status menu indicates the current status of each item listed below. Addon-lock This card must be locked to the ADD-ON bus. When this lock is OK, this item indicates OK. When there’s no lock available, this item will indicate... -
Page 16: Events Menu
INSTALLATION AND CONFIGURATION MANUAL DIO88 7 Events Menu Introduction An event is a special message that is generated on the card asynchronously. This means that it is not the response to a request to the card, but a spontaneous message. What is the Goal of The goal of events is to inform the environment about a changing an event? -
Page 17: The Tag
EVS Broadcast Equipment SA used in controlling software like Synapse Set-up to show the event. The Tag The tag is also defined in the card. The tag has a fixed meaning. When controlling or monitoring software should make decisions based on events, it is easier to use the tag instead of interpreting a string. -
Page 18: Led Indication
INSTALLATION AND CONFIGURATION MANUAL DIO88 8 LED Indication ERROR The error LED indicates an error if the internal logic of the DIO88 card is not configured correctly or has a hardware failure. INPUT 1 ~ These LEDs indicated the presence of a valid AES/EBU signal on the INPUT 8 inputs 1 till 5. -
Page 19: Block Schematics
EVS Broadcast Equipment SA 9 Block Schematics DIO88 MODE 1 – 4IN/4OUT GAIN & PHASE AES/EBU IN 1/2 2 CHANNEL MONO DELAY SWITCH GAIN & PHASE GAIN & PHASE AES/EBU IN 3/4 2 CHANNEL MONO DELAY SWITCH GAIN & PHASE GAIN &... - Page 20 INSTALLATION AND CONFIGURATION MANUAL DIO88 DIO88 MODE 3 – 8 OUT GAIN & PHASE AES/EBU IN 1/2 2 CHANNEL MONO AES/EBU OUT 1/2 DELAY SWITCH GAIN & PHASE GAIN & PHASE AES/EBU IN 3/4 2 CHANNEL MONO AES/EBU OUT 3/4 DELAY SWITCH GAIN &...
-
Page 21: Connector Panel
EVS Broadcast Equipment SA 10 Connector Panel The DIO88 can be used with the BPL11 back plane only: BPL11 AES/EBU IN/OUT 1/2 AES/EBU IN/OUT 3/4 AES/EBU IN/OUT 5/6 AES/EBU IN/OUT 7/8 NOT CONNECTED AES/EBU IN/OUT 9/10 AES/EBU IN/OUT 11/12 AES/EBU IN/OUT 13/14... -
Page 22: Quad Speed Add-On Bus
INSTALLATION AND CONFIGURATION MANUAL DIO88 Appendix 1 Quad speed ADD-ON bus Scope The internal audio ADD-ON bus needs an upgrade. We want more channels (32 per video stream seems possible in the near future). And we want the bus to be bidirectional, so 32 channels in and 32 channels out at the same time. The new interface needs to be compatible with all existing hardware (frames) and in the implementation of the master card it needs to be backward compatible with the original ADD-ON bus. -
Page 23: Example
EVS Broadcast Equipment SA Example The big difference between the new and old bus structure is the fact that it caries 4 times as much audio channels. It is also bi directional by design. So half of the original physical... -
Page 24: Multiplexing
INSTALLATION AND CONFIGURATION MANUAL DIO88 Multiplexing The injection of processed audio into the master card works differently then you were used to with the original audio ADD-ON bus. The brown large arrow will always carry 32 channels from ADD-ON to ADD-ON, or from ADD-ON to Master Card.
