INSTALLATION AND OPERATION MANUAL Synapse MGU100 - MGG100 4K (MGU100) / 3Gbps (MGG100), HD, SD SDI Eightfold Multiview Building Block (ACP2 model) Version 1.00 | December 2021...
Page 3
You will find the full list of addresses and phone numbers on the following webpage: https://evs.com/contact/offices. User Manuals on EVS Website The latest version of the user manual, if any, and other user manuals on EVS products can be found at the EVS download center, on the following webpage: https://download-area.evs.com. Synapse MGU100 - MGG100 | Disclaimer |...
NEVER bypass any fuse. NEVER replace any fuse with a value or type other than those specified. NEVER attempt to repair this product. If a problem occurs, contact your local EVS distributor. NEVER expose this product to extremely high or low temperatures.
5.1.2. Video, Clock and Notes Settings 5.2. Control Tab 5.3. Background Tab 5.4. Detection Tab 5.5. Network Tab 5.6. Input Status Tab 5.7. Window Status Tab 5.8. Output Status Tab 5.9. GPI Tab 5.10. Object Browser Tab Synapse MGU100 - MGG100 | Contents |...
Page 6
6. Use Cases and Advanced User Guide 7. Events Menu 8. LED Indication 9. Block Schematic 10. Connector Panels Appendices Appendix 1: Supported Protocols Appendix 2: Timezones GNU Public License ICONOGRAPHY Warning Note IV | December 2021 | Issue 1.00.B...
In the Installation and Operation Manual the icon has been added on the left margin to highlight information on updated features. No changes in version 1.00 of the MGU100 - MGG100 require an update to the current manual. Synapse MGU100 - MGG100 | What's New? |...
Synapse is a modular system designed for the broadcast industry. High density, intuitive operation and high-quality processing are key features of this system. Synapse offers a full range of converters and processing modules. Please visit the EVS website at www.evs.com to obtain the latest information on our new products and updates.
2. Unpacking and Placement Unpacking The EVS Synapse card must be unpacked in an anti-static environment. Care must be taken NOT to touch components on the card – always handle the card carefully by the edges. The card must be stored and shipped in anti-static packaging.
Move forward through the menu structure. Go back through the menu structure. Move up within a menu, or increase the value of a parameter. Move down through a menu or decrease the value of a parameter. Synapse MGU100 - MGG100 | 3. Quick Start |...
Page 12
When editing parameters, pressing ► twice will reset the value to its default setting. How to Change Parameters Using the Front Panel Control With the display as shown below: Pressing selects the SFS10 in frame slot 01. The display changes to indicate that the SFS10 has been selected. In this example the Settings menu item is indicated.
For operation of Cortex, please refer to the Cortex help files. Further information about Front Panel Control and Cortex can be obtained from the ERC, ERS, RRC and RRS operational manuals and the Cortex help files. Synapse MGU100 - MGG100 | 3. Quick Start |...
3.3. Daisy Chain Mode Daisy chain mode refers to the way several multiviewer cards can be connected to one another, in order to be able to configure a greater number of input streams. Daisy Chain mode is applicable to the MGU, MGG and MNU modules only. How to Connect Cards in Daisy Chain Mode The multiviewer cards have to be connected using the cables provided specifically for this purpose.
Page 15
DIO88 for external AES inputs or DEE28 for Dolby E decoding The output status enables you to check that the bus is connected correctly. For more information, please refer to "Output Status Tab" on page 33. Synapse MGU100 - MGG100 | 3. Quick Start |...
Page 16
Output Configuration The following illustration shows a possible configuration where 16 MGU100 or MGU200 cards are daisychained with the SynView loop connectors to create a 128-input 8-output multiviewer on 8 multiviewer heads. 8 | December 2021 | Issue 1.00.B...
4. The MGU100 / MGG100 Card Introduction SynView is EVS’s next generation Synapse modular multiviewer. The feature set has been increased tremendously, with double the amount of inputs and up to 8 times the amount of outputs (heads) UHD/4K/60Hz output resolution on display outputs and a 6-fold increase in processing power.
Page 18
Features • 8 inputs to two individual panel outputs or 8 SDI (1080p) outputs (MGU200 only) • 8 inputs to two individual panel outputs or 2 SDI (1080p) outputs • Each input can be displayed on each head with individual scale and position •...
Page 19
This card has an unconventional way of updating with new or other firmware. For an explanation of how this is done, please refer to the Synapse Module Reprogramming Guide, which can be downloaded from the EVS website. Synapse MGU100 - MGG100 | 4. The MGU100 / MGG100 Card |...
5. Graphical User Interface 5.1. Window Layout Tab 5.1.1. Overview The layout settings enable you to configure the window display on the multiviewer head. Each card can have up to 8 inputs. When multiple cards are daisy-chained, it is possible to have very large numbers of inputs.
Page 21
For more information, please refer to Video, Clock and Notes Settings below. 5. Multiviewer Output Head Display This area provides a graphical representation of the selected head in accordance with the configured settings. Synapse MGU100 - MGG100 | 5. Graphical User Interface |...
5.1.2. Video, Clock and Notes Settings Video Settings Window selector Identifies the Window whose video settings are currently being displayed, along with its input Source. You can also Enable or deselect the window display in the multiviewer head. Window Size These settings enable you to position the windows on the multiviewer head and set their dimensions as a percentage, in pixels or lines.
Page 23
Green, Red, Gray or Amber. Default for all inputs is Gray. Audio Meters The Enable: button allows you to display or hide audio meters, to have a visual indication of the volume. Synapse MGU100 - MGG100 | 5. Graphical User Interface |...
Page 24
Position: With these settings, you can select a position for the audio meter bars. It is possible to set them Over or to the Side of the picture. You can also turn them Off. By default it is set to Off. Style: With this setting, you can select the style of the audiometer bars for each individual input.
Page 25
System, in which case the clock will show the card’s internal clock (uptime). The multiview card also has two LTC inputs, physically available on the Dsub connector on the backplane. You can choose between the LTC1 and LTC2 inputs. Synapse MGU100 - MGG100 | 5. Graphical User Interface |...
Page 26
It is possible to synchronize the internal clock to an NTP server. This way, with Time Source set to NTP (default), the clock will indicate the correct NTP time corresonding to the NTP Server and Timezone settings. VITC/ATC Input. When the Timecode is is taken from SDI, the user needs to assign which input this refers to.
Page 27
Background Color You can specify the RGB values to customize the note background color or select one from the color picker. The Opacity can also be used to adjust the note's degree of transparency. Synapse MGU100 - MGG100 | 5. Graphical User Interface |...
5.2. Control Tab The Control tab provides an overview of the main settings that are required to configure the system. 1. Output Format You can select here the resolution and frame rate of the 4 SDI output connectors corresponding to each head.
Page 29
Screen nr. 2: The address used for mapping UMD data to Head B. 7. Time Sync Settings NTP Server: This is the address used to connect to the NTP server on the network. Timezone: Sets the timezone. Please refer to "Appendix 2: Timezones" on page 51. Synapse MGU100 - MGG100 | 5. Graphical User Interface |...
Page 30
Offset: Here you can set a time difference, e.g. to display the local time if the output content is being broadcast from another time zone. Status 1 / 2. This enables you to see the connection statuses of the LTC1 and LTC2inputs on the Dsub connector of the backplane.
The Background tab enables you to configure the Multiviewer background display settings individually for both screens. 1. Background Mode Enables you to select the default EVS background graphic or specify another picture that has been saved on the card. 2. Background Status Can be transparent or a solid color.
5.4. Detection Tab 1. General Detection Settings Alarm Timeout: If Auto Acknowledge is set to On, this sets the length of time (in seconds) that an error announcement will be displayed in the multiviewer, starting from the moment when the error is detected.
Page 33
Trigger Interval: This setting specifies the number of consecutive frames for which there is no sound and an alarm should be generated. Alarm Status: When the alarm status is On, any alarms that are generated will be displayed in both the multiviewer window and the GUI. Synapse MGU100 - MGG100 | 5. Graphical User Interface |...
Page 34
Silence Detection identifies when the sound level is very low. Enable: This button activates silence detection. Trigger Interval: This setting specifies the number of consecutive frames for which the sound level is too low and an alarm should be generated. Alarm Status: When the alarm status is On, any alarms that are generated will be displayed in both the multiviewer window and the GUI.
As the IP configuration is set to DHCP in the illustration, the status items display the settings that have been assigned automatically. IP Address: The IP network address currently being used to connect to the card. Synapse MGU100 - MGG100 | 5. Graphical User Interface |...
Page 36
Link Status: A green icon indicates that the IP connection has been detected and the field contains the network speed. Primary DNS: In the illustration, this field shows the address of the primary Domain Name Server currently being used, overriding the manual settings entry. 28 | December 2021 | Issue 1.00.B...
WSS Stnd: This status item displays the detected standard WSS value of the inputs when they are SD. This is displayed as 1_vid through 8_vid, 1_flm through 8_flm or NA (when no standard WSS is detected). Synapse MGU100 - MGG100 | 5. Graphical User Interface |...
Page 38
WSS Ext: This item displays the detected extended WSS value of the inputs when they are SD. This is displayed as 4:3_0 through 4:3_7, 16:9_0 through 16:9_7 or NA (when no extended WSS is detected). S2016 (AFD): This item displays the detected SMPTE 2016 (AFD) values of the corresponding input. This is displayed as AFD0 - AFD15 or NA (no S2016 detected).
Can be a string with a maximum length of 16 characters. Tally 1 through Tally 4: These items display the status of the relevant tally on the input window. It can be Gray (off), Green, Red or Amber. Synapse MGU100 - MGG100 | 5. Graphical User Interface |...
Page 40
2. Status History Monitoring events can be filtered according to their severity and whether they are new or have been acknowledged. The list can be exported. 32 | December 2021 | Issue 1.00.B...
Daisy Chain between two adjacent cards in a multicard setup. The value itself is not very important, but typically it is expected that the values should remain more or less constant. Head Lock. This item shows whether the output is locked to the ref. Synapse MGU100 - MGG100 | 5. Graphical User Interface |...
Page 42
2. Backpanel Detection. Indicates whether the backpanel has been detected. Possible statuses are Connected or Disconnected (default). Panel ID. Indicates the ID of the connected backpanel. 3. Status History Monitoring events can be filtered according to their severity and whether they are new or have been acknowledged.
Tally_R2 Tally_L1+R2 2. GPI Contacts State For each GPI contact, it is possible to see the status: • open (gray = unused) • closed (green = in use). GPIs work in a latching mode. Synapse MGU100 - MGG100 | 5. Graphical User Interface |...
5.10. Object Browser Tab Objects The Objects view presents all of the settings and statuses found in the card. The items are divided into folders according to the different functionalities and can be easily browsed in the tree structure. For example, if you want to edit any of the settings and status items related to the multiviewer presets, they are all contained within the relevant folder and sub-folders.
The SynView multiview system has also capabilities for displaying background graphics. Factory default, there will be an EVS background. For the user it is possible to put another picture on the board, which will be used as background. This picture will be scaled to the resolution set on the output.
Page 46
How to Activate On-Screen Closed Captions Closed caption decoding is first enabled by selecting Closed Captions: Figure 1. Closed Caption On/Off Then select one of the Closed Caption Channel options (CC1, CC2, TXT1, TXT2) in the dropdown shown below: Figure 2. Closed Captioning Channel Selection 38 | December 2021 | Issue 1.00.B...
Page 47
A closed captions detection status item is now available per physical input: Figure 3. CC Decoding Status CC data is processed and rendered as a transparent overlay on top of the video. Figure 4. Rendered Result Synapse MGU100 - MGG100 | 6. Use Cases and Advanced User Guide |...
7. Events Menu Introduction An event is a special message that is generated on the card asynchronously. This means that it is not the response to a request to the card, but a spontaneous message. What is the Goal of an Event? The goal of events is to inform the environment about a changing condition on the card.
Page 49
Card Address Together with the message string or the tag, the slot number or address of the card is relevant to be able to assign the event to a certain card. Synapse MGU100 - MGG100 | 7. Events Menu |...
8. LED Indication Indicator Description Error LED The error LED indicates an error if the internal logic of the card is not configured correctly or has a hardware failure. Input1 LED LED indicate the presence of a valid SDI video signal on input 1. Reference LED Indicates the presence of a valid reference signal on the selected reference input connector (ref-1 or ref-2).
Appendices Appendix 1: Supported Protocols ASCII Electrical RS232 (max 30 meters) 9.6 kbaud 8-bit 2 stop bits No parity, X-on/X-off Commands Loading the display: ZDaanabcdefgh<cr> command identification “display set” UMD address in HEX form as selected at the UMD display number (1..n) abcdefgh characters for the display <cr>...
Page 55
The protocol described is for one way communication only. It details physical layer, link layer and message structure. Electrical RS 422/ RS 485 8 bit data 1 stop even parity 38k4 baud Synapse MGU100 - MGG100 | Appendix 1: Supported Protocols |...
Page 56
Dynamic UMD Protocol HEADER / CONTROL BYTE / DISPLAY DATA Header (1 byte): Display address (0-126) + 80 hex control byte and display data will be sent Control (1 byte): bit 0 tally 1 1=on, 0=off bit 1 tally 2 1=on, 0=off bit 2 tally 3 1=on, 0=off...
Page 57
Clear for ASCII based strings in packet, set for Unicode UTF-16LE If set, data after SCREEN is screen control data (SCONTROL) – otherwise it is display message Bit 1 data (DMSG) Bits 2-7 Reserved (clear to 0) Synapse MGU100 - MGG100 | Appendix 1: Supported Protocols |...
Page 58
SCREEN (16 bit): Primary index for use where each screen entity would have display indices (defined below) starting from 0. Index 0xFFFF is reserved as a “Broadcast” to all screens. If not used, set to 0. Display Message (<DMSG>) Definition This message definition is sent per display, and there can be several in a packet (up to max packet length).
Under this license, you are eligible to receive a copy of the source code of this software, including any changes. EVS Broadcast Equipment SA shall provide the source code on request either through physical distribution or electronic communication. For physical distribution you may be charged a fee that covers distribution costs.
