FRONT
Volume control
Microphone jack
LEFT
Ventilation fan
USB ports
Caution: Do not block
Modem jack
1
INSTALL THE BATTERY.
With the label side down, slide the battery into the
battery compartment until it clicks. Then lock it in place.
3
CONNECT TO THE INTERNET. (optional)
Connect the phone cord (included) to the
modem jack (
) if using dialup Internet access.
Or connect your Ethernet (
) or USB (
) cable
(not included) if using high-speed access.
LCD panel release latch
Media card reader
Headphone jack
PC Card slot
Monitor port
BACK
Power indicator
Kensington™ lock slot
RIGHT
Optical drive
2
CONNECT TO AC POWER.
Leave the AC adapter plugged in for at least three
hours the first time, so the battery will fully charge.
4
START THE NOTEBOOK.
Press the power button, then follow the on-screen instructions to
complete Windows setup.
Ethernet jack
Power connector
