QUICK-START GUIDE - XV1013 VACUUM CHAMBER MACHINE
Please Read All Instructions Before Operating Machine
YOU MUST ADD OIL TO MACHINE BEFORE FIRST USE!
STEP 1
Remove the bottom center
screw on the back of the
machine with the allen
wrench provided.
CHANGE OIL EVERY 120 HOURS OF OPERATION:
To change the oil, remove the screw on the underside of the machine over a container.
Drain the oil. Replace the screw and refill with fresh oil. DO NOT OVERFILL!
STEP 2
Machine housing pivots
up and away from you
until machine face rests
back of machine
on table.
STEP 3
DO NOT OVERFILL!
Remove the red screw
on to of pump. Fill with
oil provided above
minimum oil line.
Advertisement
Table of Contents
Related Manuals for XtraVac XV1013
Summary of Contents for XtraVac XV1013
- Page 1 QUICK-START GUIDE - XV1013 VACUUM CHAMBER MACHINE Please Read All Instructions Before Operating Machine YOU MUST ADD OIL TO MACHINE BEFORE FIRST USE! STEP 1 STEP 2 STEP 3 DO NOT OVERFILL! Remove the bottom center Remove the red screw...
- Page 2 Use arrows to adjust the time. the sealed package from the vacuum chamber. (default 1.5) XV1013 VACUUM MACHINE TROUBLESHOOTING ISSUE SUGGESTED FIX No power to Check power cable at the back of machine. Make sure it is plugged in securely to both the machine machine and to the wall outlet.
