Gateway M685 Quick Start

FRONT
Headphone jack
Microphone jack
Speaker
Battery charge indicator
LEFT
Kensington™ lock slot
USB ports
S-Video out jack
1
INSTALL THE BATTERY.
With the label side down, slide the battery into the
battery compartment until it clicks. Then lock it in place.
3
CONNECT TO THE INTERNET. (optional)
Connect the phone cord (included) to the
modem jack ( ) if using dialup Internet access.
Or connect your Ethernet ( ) or USB ( ) cable
(not included) if using high-speed access.
Memory card reader
LCD panel release latch
Speaker
Power indicator
IEEE 1394 port
PC Card slot
Ventilation fan
Caution: Do not block
BACK
Modem jack
Ethernet jack
RIGHT
2
CONNECT TO AC POWER.
Leave the AC adapter plugged in for at least three
hours the first time, so the battery will fully charge.
4
START THE NOTEBOOK.
Press the power button, then follow the on-screen instructions to
complete Windows setup.
Power connector
Monitor port
DVD drive
USB ports
