Gateway 450RGH Specifications

Gateway 450RGH Specifications

Gateway 450rgh: specifications
Hide thumbs Also See for 450RGH:

Advertisement

Quick Links

Download this manual See also: Service Manual, User Manual
Specifications are subject to change without notice or obligation.
Processor and Core Logic
Processor options
Processor packaging
Level 2 cache
Core logic
Processor side bus speed
BIOS

SPECIFICATIONS

Gateway 450RGH Notebook
®
®
One Intel
Pentium
■
To determine your notebook's processor speed:
In Windows XP, click Start, My Computer, then click
■
View System Information. The processor speed is
listed.
-OR-
In Windows 2000, click Start, Programs,
■
Accessories, System Tools, then click System
Information. The processor speed is listed.
Intel socketable FCPGA2
1 MB with Advanced Transfer Cache Architecture
®
Intel
855PM chipset
400 MHz front side bus
Phoenix BIOS
■
512 KB Flash ROM
■
SMBIOS 2.3 support
■
Advanced Configuration and Power Interface 1.0b and
■
2.0 (ACPI 1.0b and 2.0) support
Wired for Management 2.0 (WfM 2.0)
■
www.gateway.com
M CPU
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 450RGH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gateway 450RGH

Summary of Contents for Gateway 450RGH

  • Page 1: Specifications

    Processor and Core Logic Processor options Processor packaging Level 2 cache Core logic Processor side bus speed BIOS SPECIFICATIONS Gateway 450RGH Notebook ® ® One Intel Pentium M CPU ■ To determine your notebook’s processor speed: In Windows XP, click Start, My Computer, then click ■...
  • Page 2 Gateway 450RGH Notebook System memory Memory type Memory expansion options Video Graphics controller Video memory LCD display panel LCD supported video modes LCD maximum refresh rate Controls External video External CRT resolutions External CRT maximum refresh rate TV out (composite video) jack...
  • Page 3 DVD decoder through Toslink optical S/PDIF jack on port replicator. Volume control keys on keyboard ■ Software control provided through Windows ■ Stereo speakers built into front of notebook ■ 1.5 W maximum output ■ Stereo headphone output ■ Stereo line input ■ Monophonic microphone input ■ www.gateway.com...
  • Page 4 Gateway 450RGH Notebook Communications Modem features 10/100/1000 Mbps Ethernet interface features Wireless Ethernet interface features (Factory installed option) Input/Output (I/O) Keyboard Pointing device Integrated V.92/56K data/fax modem ■ Uses the RJ-11 jack on the back of the notebook ■ Supports Wake on ring from S3 power mode ■...
  • Page 5 Docking port ■ DC input ■ Accepts two Type II or one Type III device ■ Ricoh R5C554 controller ■ NOTE: This notebook does not support Zoom Video. Port replicator Hot dock ■ Warm dock ■ Cold dock ■ www.gateway.com...
  • Page 6 Gateway 450RGH Notebook Input/Output (I/O ports) Storage Hard drive controller Hard drive Super I/O controller Two USB 2.0 (4-pin) ■ High-speed serial ■ Parallel ■ Modem (RJ-11) ■ Ethernet (RJ-45) ■ External monitor (VGA) ■ S-Video TV out ■ S/PDIF digital audio out ■...
  • Page 7 ■ ™ IBM Microdrive ■ ® Memory Stick ■ ™ MultiMediaCard ■ ™ Secure Digital ■ ™ SmartMedia ■ Secondary Battery Removable six-cell prismatic Lithium Ion battery pack ■ 3.4 Ah ■ 11.1 V nominal ■ 37.74 Wh ■ www.gateway.com...
  • Page 8 Gateway 450RGH Notebook Power Intelligent charger AC adapter Battery type Battery capacity Power management Controls Power switch Supports dynamic charge current to achieve the best charge performance 19 VDC, 4.74A, 90 W output ■ Automatically adjusts for 100 to 240 VAC, 50 to 60 Hz ■...
  • Page 9 Wired for Management 2.0 (WfM 2.0) enabled ■ PC2001 specification ■ Advanced Configuration and Power Interface 1.0b and ■ 2.0 (ACPI 1.0b and 2.0) support SMBIOS 2.3 ■ Windows Hardware Quality Labs (WHQL) certified ■ Supported www.gateway.com Client manager 6.0...
  • Page 10 Gateway 450RGH Notebook Physical specifications Dimensions System weight AC adapter weight Environment Operating temperature Storage temperature Operating humidity Storage humidity Operating altitude, maximum Storage altitude, maximum 15.0-inch display ~13.15 × 10.63 × 1.3 in. (W × D × H) ~334 × 270 × 33 mm (W × D × H) 15.0-inch display (includes DVD drive and 6-cell...
