Ready for 4
•
Depress footswitch
128.
129.
•
Manually place fastener
into upper tool
•
1
st
of 3 insertion
points
• Station
is in place & ready
•
Touch on OK
130.
Station 2 Insertion
17-00001-C
th
of 4 insertions
•
Turn TIS to STATION 2
tooling and fastener
Upper tool in motion
TIS is now UNLOCKED, allowing you
to turn it to Station
. When in the
correct position, the machine will
automatically lock the TIS.
Manually Place Fastener
Setup Stroke: Saves all the setup
values such as Fastener pick up point,
vacuum detection, length and tooling test.
Page | 102
