ARCHITETTURA SONORA ICARUS SUB Quick Start Manual

ICARUS_
SUB

Unpacking:

to remove Icarus_sub from the shipping box carefully follow these steps
1.
Icarus_sub is shipped in a box
secured with packing foam
upside down for safety reasons.
Acoustic connectivity & settings:
board. For everything concerning the regulation of the DSP, please refer to the website www.architetturasonora.com or to your speciali-
zed dealer.
2.
Open the box and without
removing the foam on top of
the speaker gently tilt the box
so that it rests directly on the
protecting foam.
IMPORTANT.
NEVER lift the speaker by its
base, but only by its body, once
you turned the box into position
as shown above!
the Icarus_sub necessarily requires an ampli er equipped with DSP on
SOUND OUTPUT
Speaker type
8" Woofer
Nominal impedence
4
Crossover
DSP needed
Frequency range
40 - 150Hz (-6dB)
Sensitivity (1W-1m)
87 dB/W/m
250W (Class D)
3.
Remove the box and the
upper part of the foam to
release the sound module.

SPECIFICATIONS

Material
concrete, marbles, travertine,
alternative stones.
Metal material
stainless steel, oxidized brass,
and painted steel
Dimensions
34,6h x 27 cm
(13.62h x 10.62 inches)
Weight
16,5 kg (36,4 pounds)
4.
Holding gently the module on
its body, pull it out of the box
ready for set-up and installa-
tion.
