Visit the Signature Choral Risers web page at www.wengercorp.com
for detailed instructions and videos.
C
ONTENTS
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Important User Information . . . . . . . . . . . . . . . . . . . . . . . . . . .3
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Manufacturer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Hardware Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Step Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Chassis Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Stringer Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Back Rail Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Note: Please read and understand these Assembly and Owner's Instructions before assembling
the parts.
Note: Remove all items from the shipping cartons and arrange them in a convenient location.
Refer to the illustrations on the following pages. If you need additional information,
contact the Wenger Corporation using the information below.
©Wenger Corporation 2014
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: 800-4WENGER (493-6437) • Worldwide: 1-507-455-4100 • www.wengercorp.com
Assembly/Owner's Manual
Signature
Before Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Chassis Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Back Rail Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Step Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Final Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Safety Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Moving and Storing Risers . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Connecting Multiple Riser Units . . . . . . . . . . . . . . . . . . . . . . .15
Straight Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Printed in USA 05/14
Choral Riser
®
3-Step Model
Part #098E498-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Signature and is the answer not in the manual?

Questions and answers

Summary of Contents for Wenger Signature

  • Page 1: Table Of Contents

    Refer to the illustrations on the following pages. If you need additional information, contact the Wenger Corporation using the information below. ©Wenger Corporation 2014 Printed in USA 05/14 Part #098E498-01 Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448 Questions? Call..USA: 800-4WENGER (493-6437) • Worldwide: 1-507-455-4100 • www.wengercorp.com...
  • Page 2: Safety Precautions

    WARNING means that failure to follow the instruction may result in serious injury or death. • CAUTION means that failure to follow the instruction may result in serious injury or damage to property. Read all of the safety instructions before assembling or using the Signature Choral Riser. CAUTION CAUTION Make sure that anyone...
  • Page 3: Warranty

    Wenger Corporation. Wenger Corporation does not assume any responsibility for any errors that may appear in this manual. In no event will Wenger Corporation be liable for technical or editorial omissions made herein, nor for direct, indirect, special, incidental, or consequential damages resulting from the use or defect of this manual.
  • Page 4: Parts List

    ARTS ARDWARE Fasteners are shown actual size. (2) Carriage Bolt, (2) Carriage Bolt, (4) Socket Screw, 3/8-16 x 1 3/8-16 x 1-3/4 3/8-16 x 2-3/4 (8) Nut, Lock, (6) Nut, Jam Lock, 3/8-16 3/8-16 (4) Carriage Sleeve (For Use On Back Rail Only) (2) Velcro Strip 7/32"...
  • Page 5: Step Assembly

    ARTS CONTINUED SSEMBLY Item Qty Description Item Qty Description 1st Step Screw, SM, 1/4-20 x 1, Self Drill 2nd Step Capscrew, GD2, ZP, 5/16-18 x 5/8 3rd Step Wing Nut, 3/8-16 Unit Connector Bracket HASSIS SSEMBLY Item Qty Description Item Qty Description 3-Step Carriage Carriage Bolt, 5/16-18 x 5/8...
  • Page 6: Stringer Assembly

    ASTENERS AND ARTS CONTINUED TRINGER SSEMBLY Item Qty Description Item Qty Description Stringer Assembly Plug, 1-1/4 SSEMBLY Item Qty Description Item Qty Description Back Rail Upright Tube Back Rail End Cap Back Rail Horizontal Tube Plug, 1-1/4 OD...
  • Page 7: Before Assembly

    EFORE SSEMBLY Each riser is shipped in two cartons, one shorter carton containing the chassis and the hardware pack and one longer carton containing the Back Rail and Steps. Assembling a riser will likely involve kneeling. Use carpeting, a rug, or the cardboard carton to soften a hard floor and prevent scratching riser surfaces.
  • Page 8: Assembly

    SSEMBLY HASSIS SSEMBLY 1. Remove the Chassis Assembly, Stringer Assemblies, Truss Supports and Hardware Pack from the carton. Place the Chassis Assembly (wheels down) on the floor. 2. Cut and remove the plastic shipping bands. 3. Position the Truss Support inside the Chassis Frame with the square hole at the top and angled towards the outside.
  • Page 9 SSEMBLY CONTINUED HASSIS SSEMBLY CONTINUED 8. Place both Stringer Assemblies on the threaded studs of the Chassis Assembly. 9. Place a Carriage Sleeve over each of the four threaded studs. Carriage 10. Secure the Stringer Assemblies and Sleeves using Sleeve a 3/8-16 Lock Nut on each of the four threaded studs.
  • Page 10: Back Rail Assembly

    SSEMBLY CONTINUED SSEMBLY 1. Remove the Upright Tubes, Horizontal Tubes and Steps from the carton. 2. Remove the End Caps from the bottom end of both Upright Tubes and set them aside. Note: Do not discard the End Caps, they will be re-attached later. Upright Tubes Caps...
  • Page 11 SSEMBLY CONTINUED SSEMBLY CONTINUED Jam Lock 8. Locate the three Horizontal Tubes. Remove and discard the protective rubber caps from each of the threaded studs. 9. Insert the threaded studs of the Horizontal Tubes Horizontal Tube through the predrilled holes in the front side of the Upright Tubes.
  • Page 12: Step Assembly

    SSEMBLY CONTINUED SSEMBLY 1. Remove the four Wing Nuts from each of the three Steps and set them aside. Note: Do not discard the Wing Nuts, they will used to attach the Steps to the Riser. 2. Start with the longest Step at the top and place the Steps on the Stringer Assemblies in descending order with the widest end at the rear as shown.
  • Page 13: Final Assembly

    SSEMBLY CONTINUED INAL SSEMBLY 1. Lift up on the Lower Step to fold the riser to the Storage Position. 2. Replace the End Caps at the bottom of the Upright Tubes. Apply Velcro to 3. Note where the edge of the Lower Step Contact Points contacts the surface of the Upright Tubes.
  • Page 14: Moving And Storing Risers

    OVING AND TORING ISERS The Riser must be put into the Storage Position to be moved and stored. To place the Riser in the Storage Position: 1. Lift up on the First Step and fold it up to the Back Rail. 2.
  • Page 15: Connecting Multiple Riser Units

    ONNECTING ULTIPLE ISER NITS Risers can be connected to additional units using the Unit Connector Brackets installed on the Steps. To connect risers together: 1. Roll an additional riser to be aligned as close as possible with the riser already placed in the Performance Position.
  • Page 16: Straight Configuration

    TRAIGHT ONFIGURATION The previous assembly instructions were for Arc Configurations. To arrange risers in a Straight Configuration, every other riser in the configuration must have the positioning of the Steps and the Back Rail Horizontal Tubes reversed. 1. With the riser in the Performance Position, remove the four Wing Nuts from the underside of each Step.
