2-Step
Fixed Height Stairway
Contents
Important User Information � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2
General � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2
Manufacturer � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2
Intended Use � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2
Warranty � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2
Safety Precuations � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
Required Tools� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
Fasteners� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
Note: Please read and understand these instructions before assembling the parts.
Note: Remove all items from the shipping cartons and arrange them in a convenient location.
Note: If you need additional information, contact Wenger Corporation using the information below.
©Wenger Corporation 2019
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: (800) 4WENGER (493-6437) • Worldwide: +1-507-455-4100 • wengercorp.com
Fixed Height Stairway
2-Step, 3-Step and 4-Step
3-Step
Fixed Height Stairway
Parts List 2-Step Model � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
Parts List 3-Step, 4-Step Models � � � � � � � � � � � � � � � � � � � � � � � � � 4
Assembly � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5
Installation � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 8
Printed in USA 2019-10
Assembly Instructions
4-Step
Fixed Height Stairway
Part #281A129-05
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wenger Fixed Height Stairway 2-Step
Summary of Contents for Wenger Fixed Height Stairway 2-Step
-
Page 1: Table Of Contents
Fasteners� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3 Note: Please read and understand these instructions before assembling the parts. Note: Remove all items from the shipping cartons and arrange them in a convenient location. Note: If you need additional information, contact Wenger Corporation using the information below. ©Wenger Corporation 2019 Printed in USA 2019-10 Part #281A129-05 Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448... -
Page 2: Important User Information
Important User Information General Copyright © 2019 by Wenger Corporation All rights reserved. No part of the contents of this manual may be reproduced, copied, or transmitted in any form or by any means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and retrieval systems without the written permission of the publisher, unless it is for the purchaser's personal use. Printed and bound in the United States of America. The information in this manual is subject to change without notice and does not represent a commitment on the part of Wenger Corporation. Wenger Corporation does not assume any responsibility for any errors that may appear in these instructions. In no event will Wenger Corporation be liable for technical or editorial omissions made herein, nor for direct, indirect, special, incidental, or consequential damages resulting from the use or defect of these instructions. The manufacturer reserves the right to change this product at any time. The information in this document is not intended to cover all possible conditions and situations that might occur. The end user must exercise caution and common sense when assembling or installing Wenger Corporation products. If any questions or problems arise, call the Wenger Corporation at (800) 4WENGER (493-6437) or +1-507-455-4100 worldwide. Manufacturer The Fixed Height Stairway is manufactured by: Wenger Corporation 555 Park Drive Owatonna, MN 55060 (800) 4WENGER (493-6437) • +1 (507) 455-4100 wengercorp.com Intended Use · This product is intended for indoor use in normal ambient temperature and humidity conditions — it must not be exposed to prolonged outside weather conditions. This product is intended to be assembled only as described in these instructions. · Warranty This product is guaranteed free of defects in materials and workmanship for five full years from date of shipment. A full warranty statement is available upon request. -
Page 3: Safety Precuations
Safety Precautions Throughout this document you may find cautions and warnings which are defined as follows: • WARNING: Failure to follow the instruction could result in serious injury or damage to property. X001552 • CAUTION: Failure to follow the instruction could result in minor injury or damage to property. Read all of these safety instructions before using the equipment. CAUTION CAUTION Make sure that anyone working Failure to comply with the with the fixed height stairway Warnings and Cautions in this has read and understands these document can result in damage instructions. to property or serious injury. -
Page 4: Parts List 2-Step Model
Parts List 2-Step Model Item Qty Description Self-Tapping Screw, 3/8-16 x 1" Capscrew, 3/8-16 x 2" Base Machine Screw, 1/4-20 x 2.36" (2-Step Model) Lock Nut, 3/8-16 (3-Step, 4-Step Models) Carriage Bolt, 3/8-16 x 2" (3-Step, 4-Step Models) Wing Nut, 3/8-16 Step Assembly Hand Rail Assembly, Left-Hand Hand Rail Assembly, Right-Hand Cross Brace (2-Step Model) Cross Base (3-Step, 4-Step Models) Connection Bracket Fiber Washer, 3/8" ID Parts List 3-Step and 4-Step Models Item 3-Step 4-Step Description Self-Tapping Screw, 3/8-16 x 1"... -
Page 5: Assembly
Assembly 1. Attach the step assemblies (7) to the left-hand (8) and right-hand (9) hand rail assemblies using two 3/8-16 x 1" self-tapping screws (1) and two 3/8" ID fiber washers (13) on each side. The wheel on both of the hand rail assemblies must face toward the inside as shown. The fiber washers will help reduce rubbing between the step assemblies and hand rail assemblies. Screw the self-tapping screws through the pilot holes in the hand rail assembly and into the channels on the underside of the step assembly. 3/8" ID Fiber Washer (13) Step 3/8-16 x 1" Assembly Self-Tapping Screw Channel Right-Hand Hand Rail Assembly Step Assembly Left-Hand Hand Rail Assembly Wheels face inside Front View 3-step model is shown as an example. - Page 6 Assembly (continued) 2. Attach the cross brace (10) or cross base (11) depending on model to the hand rail assemblies. 2-Step Model Attach the cross brace (10) to the left-hand (8) and right-hand (9) hand rail assemblies using one 1/4-20 x 2.36" machine screw in each side as shown. Align each end of the cross brace with the bottom pilot hole in each hand rail assembly and secure using a machine screw on each end. Cross Brace (10) Bottom pilot hole 1/4-20 x 2.36" Top step is shown Machine Screw removed for clarity. 3-Step and 4-Step Models Attach the cross base (11) to the left-hand (8) and right-hand (9) hand rail assemblies using two 3/8-16 x 2" carriage bolts (5) and two 3/8-16 lock nuts (4) in each side as shown. Align each end of the cross base with the two pilot holes in each hand rail assembly and secure using the carriage bolts and lock nuts.
- Page 7 Assembly (continued) 3. Attach one connection bracket (12) to both the left-hand rail assembly (8) and the right-hand rail assembly (9) using one 3/8-16 x 2" capscrew (2) and one 3/8-16 wing nut (6) in each as shown. Orient the connection bracket according to the type of stage being used as referenced below. Depending on the stairway model and stage deck elevation, align the pilot hole in each connection bracket with either the top or bottom pilot hole in each hand rail assembly according to the chart below and secure using the capscrew and wing nut. Connection Stairway Stage Deck Bracket Model Elevation Location 16" (406 mm) Bottom Hole 2-Step 24" (610 mm) Top Hole 24" (610 mm) Bottom Hole 3/8-16 x 2" 3-Step 32" (813 mm) Top Hole Capscrew 32" (813 mm) Bottom Hole 4-Step 40" (1016 mm) Top Hole pilot hole Connection Bracket (12)
-
Page 8: Installation
Installation 1. Slightly tilt the fixed height stairway forward and slide it under the stage so the connection brackets will engage with the edge of the stage deck as shown on the previous page. 2. Tilt the fixed height stairway back to the ground to grip the stage deck. CAUTION Be sure all adjustment knobs and fasteners are tight before using the stairway. Engage edge of stage deck Connection Bracket Toward Stage...
