Setting Up the System

The condenser and condenser product arm need to be rinsed with warm water to remove any
residues from the manufacture process, run water through the condenser body from the
base. Ensure you can blow through the condenser product arm, with the tap in the open and
closed positions, the holes can sometimes be blocked by particles from manufacturing, if
blocked use a very small needle and poke through the ball in the tap.
Setting up
1. Undo the nut and silicon seal from the base of the condenser and fit the boiler lid to
the condenser, refit the silicon seal (always under the lid) and tighten the nut.
2. Ensure the boiler is placed on a stable and secure workspace near a water connection
and drainage point and secure the lid to the top of the boiler with the clips.
3. Fit the condenser product arm to the condenser, it only needs to be finger tight, do not
use a spanner. Ensure the tap and vent hole are facing up and there is a slight slope
away from the condenser as per below.
Vent Hole
