  • Page 1 Operator Manual Water purifier Operator’s manual version: 2021.06...

  • Page 2: Table Of Contents

    ONTENT Safety information ............................3 Warning labels ............................. 3 Safety instructions ..........................3 Introduction to the system .......................... 4 Introduction ............................4 Technical specifications ....................4 Overview of the system (front view) ....................5 Overview of the system (back view) ....................6 General description ..........................
  • Page 3 «O maxi+» MEMBRANE KIT (ref. 959070) ................. 28 OP101+/OP202+/OP302+/«O maxi+» RESIN KIT (ref. 950243) ..........28 Maintenance procedures ........................29 Flow measurement procedure ....................29 Understanding conductivity values ................... 30 Change of SEDIMENT FILTER 5 µm .................... 32 Change of ACTIVE CARBON BLOCK FILTER ................33 Change of SEDIMENT FILTER 1 µm ....................

  • Page 4: Safety Information

    AFETY INFORMATION Read the safety information before installing the water purifier 2.1 W ARNING LABELS Before reading the manual, please get familiarized with the following icons used in this manual. Electric Shock Warnings Specific Information non safety related 2.2 S AFETY INSTRUCTIONS To ensure the product SAFETY and RELIABILITY, all repairing must be realized with spare parts available with our after-sales service.

  • Page 5: Introduction To The System

    NTRODUCTION TO THE SYSTEM 3.1 I NTRODUCTION The water purifier system «O maxi+» produces water of Class 2 as defined in ISO 3696 standard, which is intended to be used by clinical analyzers. The principle of purification uses two technologies: the REVERSE OSMOSIS, which is currently the most effective membrane separation process, the demineralization by ion exchange resin.

  • Page 6: Overview Of The System (Front View)

    3.3 O VERVIEW OF THE SYSTEM FRONT VIEW Storage tank Active 5µm carbon sediment 1µm filter filter sediment filter Controller Operator’s manual version: 2021.06...

  • Page 7: Overview Of The System (Back View)

    3.4 O VERVIEW OF THE SYSTEM BACK VIEW Post treatment filter Resin Bottle Reverse osmosis membrane 3.5 G ENERAL DESCRIPTION The "O maxi+" water purifier includes a set of prefiltration cartridges for filtering the inlet water: 5 µm sediment filter + carbon block filter + 1 µm sediment filter. After this stage, the water is injected via a booster pump into a reverse osmosis membrane.

  • Page 8: Controller Description

    3.6 C ONTROLLER DESCRIPTION Main display The conductivity of the produced water is displayed continuously on the main screen. Menu access (press 2 seconds) Conductivity of produced water Unit System status Flush(wash) button Detailed information button Operator’s manual version: 2021.06...

  • Page 9: Menu Display

    Menu display The setting menu is displayed after pressing the SET button 2 seconds with a tool. Menu’s title Selection (press 2 seconds) Different choices Moving in the menu Detailed information display From the main menu, when pressing shortly on the ‘+’ button, the values from various sensors are displayed momentarily.

  • Page 10: Functioning Display

    Functioning display The conductivity of the produced water can be different from 1.0. The remaining time to finish the purge process is displayed (seconds). The water purifier is rinsing the membrane after start- up, periodically (by default each 6 hours), or when pressing shortly on the ‘FLUSH’...

  • Page 11: Setting Menu

    Setting menu The settings menu is accessible by pressing with a tool on the SET button for 2 seconds. SETTINGS The available sub-menus are: CALIBRATION TELEMETRY • Calibration of the conductivity electrodes CONTRAST • Telemetry management SERVICE • Screen contrast adjustment •...

  • Page 12: General Comments On The Calibration Of The Conductivity Electrodes

    General comments on the calibration of the conductivity electrodes The calibration process is not forced by the system. It is possible to adjust the displayed value on the controller’s screen if it is different from the value measured with an external calibrated conductivity meter. For the calibration of the electrodes, it is necessary to use a precise external conductivity meter which must be calibrated (in option, conductivity meter reference 950026).
  • Page 13 3.6.7.3 Use of the adjustment screen The calibration of the integrated conductivity electrodes is processed with the inner water. In parallel, the conductivity of this water has to be measured with an external conductivity meter which needs to be previously calibrated. xxxxxx POINT x CONDUCTIVITY •...
  • Page 14 3.6.7.4 Calibration curve with one point As the electrodes are not accessible by the user, they are able to measure only the conductivity of the water crossing the system. • Point of calibration: grey vertical line. • The calibration curve goes from 0 to the point of calibration. •...
  • Page 15 3.6.7.5 Calibration curve with 2 points As the electrodes are not accessible by the user, they are able to measure only the conductivity of the water crossing the system. • Points of calibration: where are the 2 grey vertical lines. •...

  • Page 16: Calibration Of The Production Conductivity Electrode

    Calibration of the production conductivity electrode The calibration of the production conductivity electrode is made by taking water directly from the output of the purified water. The points of calibration must have conductivity values strictly under 10 µS/cm. 3.6.8.1 To define a 1st point of calibration This is the initial case, before any saving of calibration point.

  • Page 17: Calibration Of The Membrane Conductivity Electrode

    Calibration of the membrane conductivity electrode 3.6.9.1 How to take water after the membrane 1. Remove the transparent covers. 2. Take out the resin bottle (Figure1). 3. Close the valve on top of the pressurized water tank. 4. Close the hand valve No. 1. 5.
  • Page 18 3.6.9.2 To define a 1st point of calibration This is the default configuration, before any saving of calibration point. CALIBRATION CONDUCTIVITY CAL PROD CONDUCTIVITY SET MEMBRANE POINT 1 MEMBRANE CONDUCTIVITY SELECT:PRESS SET 2 SEC SELECT:PRESS SET 2 SEC 3.6.9.3 To delete the 1st point of calibration It is possible to come back to the default conductivity values by deleting the 1 calibration point.
  • Page 19 3.6.9.4 To define a 2nd point of calibration This is the default configuration, before any saving of calibration point. CALIBRATION PROD CONDUCTIVITY MEMBRANE CONDUCTIVITY SELECT:PRESS SET 2 SEC 3.6.9.5 To delete the 2nd point of calibration It is possible to come back to only one point of calibration by deleting the 2 point of calibration.

  • Page 20: Telemetry Management

    Telemetry management The telemetry feature allows to monitor and to record the measurements of conductivity, pressure, temperature, and status of the water purifier on a PC connected by a USB cable. On the activation screen, to active/unactivate the telemetry function, press with a tool for 2 seconds on the ‘SET’...

  • Page 21: Installing The Water Purifier

    NSTALLING THE WATER PURIFIER 4.1 I NSTALLATIONS ONDITIONS  Water inlet (2 to 6 bars) equipped with a turn hand valve and a male exit tap of 1/2" delivered with the packing list (male connector 3/8" quick fit/1/2" NPTF or water inlet valve 1/2" male/female). ...

  • Page 22: Connections Of Resin Bottle

    4.3 C ONNECTIONS OF ESIN BOTTLE STEP 1: Remove completely the 3/8” hand valve connecting the two tubings. This hand valve can be used for the inlet water connection of the O Maxi+ (see chapter 4.2) Hand valve 3/8" STEP 2: 1- Connect the tubing with a orange ring...

  • Page 23: Connection Of The Pressurized Tank

    4.4 C ONNECTION OF THE RESSURIZED TANK Outlet Pressurized Tank (to be connected to the water purifier) Avoid exposing the pressure tank near a heat source or near a window for proper operation. Operator’s manual version: 2021.06...

  • Page 24: Installation Of The Membrane

    4.5 I NSTALLATION OF THE MEMBRANE 1. Disconnect the water inlet pipe from the membrane holder (Figure 1). 2. Remove the membrane holder out of its two plastic stirrups (Figure 2). 3. Unscrew (by turning to the right) the cap of the membrane holder using the two special keys provided with the accessories (Figure 3).

  • Page 25: Water Purifier Start-Up

    WATER PURIFIER START 1. Connect all the tubings to the water purifier. 2. Check all hydraulic connections. 3. Close the storage tank valve. 4. Open the water purifier exit hand valve. 5. Open the tap water supply valve. 6. Connect the power supply cable and switch ON the water purifier. 7.

  • Page 26: User Maintenance

    SER MAINTENANCE 6.1 M AINTENANCE CALENDAR In order to maintain an optimal functioning of the water purifier, it is necessary to check regularly the water purifier and to perform the first level maintenance. These actions must be executed by the user. The following table lists the actions and their frequency. Calendar Frequency Operation...

  • Page 27: System Errors

    System errors When there is a malfunction, the water purifier stops, the ‘EC’LED blinks in red color and the controller displays the potential causes of error with a code. PUMP NO POWER FLUSH VALVE NO POWER PURGE VALVE NO POWER ….

  • Page 28: Consumables

    6.3 C ONSUMABLES OP202+/OP302+/«O maxi+» FILTER KIT (ref. 950019) The kit contains the following consumables: The 5 µm sediments cartridge (20") Pre-treatment The active carbon block cartridge (20") The 1 µm sediments cartridge (20") Post-treatment The 1 µm post treatment cartridge (10") The 3 pre-treatment filters must be replaced when a plugging, significant drop of the purified water production flow and/or sediments 5 µm filter seems dirty.

  • Page 29: O Maxi+" Membrane Kit (Ref. 959070)

    «O maxi+» MEMBRANE KIT (ref. 959070) The kit contains the following consumables: 1 Membrane 300 GPD + 1 flow restrictor 300 CC Reverse osmosis Flow Restrictor membrane 300 GPD The direction of the arrow inscribed on the restrictor is very important. The arrow must be down The reverse osmosis membrane and the flow restrictor must be replaced when the flow of purified water outlet is significantly low despite of a recent replacement of pre-treatment filters or/and an important increase in the frequency of the ions exchangers resins bottle replacement.

  • Page 30: Maintenance Procedures

    6.4 M AINTENANCE PROCEDURES Flow measurement procedure 6.4.1.1 General points The flow measurement is interesting to check the filters and reverse osmosis membrane plugging state. The osmosis membrane flow is function of the supply water temperature. We generally allow a flow drop of 3 % per Celsius degree in a range from 10 to 25 °C. This flow measurement must be compared to the water purifier theoretical nominal value with a fixed temperature, which is 25 °C: Note: this theoretical flow rate represents the production at a "tank outlet"...

  • Page 31: Understanding Conductivity Values

    Understanding conductivity values 6.4.2.1 General information The global quantity of dissolved solids in water can be measured by the CONDUCTIVITY (expressed in microSiemens per centimeter (µS / cm). 6.4.2.2 Production conductivity « output of water purifier » The conductivity of the produced water is below 1µS/cm The conductivity indicator...
  • Page 32 6.4.2.3 Conductivity of « after membrane» It is possible to check the conductivity after the membrane on the « DETAILS » screen. Conductivity of water after the membrane (µS/cm) Is the conductivity « after membrane » above 25 µS/cm ? , THEN change: o the membrane (see paragraph 4.5) o the flow restrictor (see paragraph 6.4.8)

  • Page 33: Change Of Sediment Filter 5 Μm

    Change of SEDIMENT FILTER 5 µm 1. Close the tap water hand valve. 2. Close the storage tank hand valve. 3. Open the water purifier exit hand valve to reduce the water pressure inside the water purifier; on the controller screen is displayed «NO FEED». Keep the water purifier exit hand valve open. 4.

  • Page 34: Change Of Active Carbon Block Filter

    Change of ACTIVE CARBON BLOCK FILTER 1. Close the tap water hand valve. 2. Close the storage tank hand valve. 3. Open the water purifier exit hand valve to reduce the water pressure inside the water purifier; on the controller screen is displayed «NO FEED». Keep the water purifier exit hand valve open. 4.

  • Page 35: Change Of Sediment Filter 1 Μm

    Change of SEDIMENT FILTER 1 µm 1. Close the tap water hand valve. 2. Close the storage tank hand valve. 3. Open the water purifier exit hand valve to reduce the water pressure inside the water purifier; on the controller screen is displayed «NO FEED». Keep the water purifier exit hand valve open. 4.

  • Page 36: Change Of The Post Treatment Cartridge: Sediment 1 Μm

    Change of the POST TREATMENT CARTRIDGE: SEDIMENT 1 µm 1. Close the tap water hand valve. 2. Close the storage tank hand valve. 3. Open the water purifier exit hand valve to reduce the water pressure inside the water purifier; on the controller screen is displayed «NO FEED».

  • Page 37: Change Of The Reverse Osmosis Membrane

    Change of the REVERSE OSMOSIS MEMBRANE 1. Close the tap water hand valve. 2. Close the storage tank hand valve. 3. Open the water purifier exit hand valve to reduce the water pressure inside the water purifier; on the controller screen is displayed «NO FEED». Keep the water purifier exit hand valve open. 4.

  • Page 38: Change Of Flow Restrictor

    Change of FLOW RESTRICTOR 1. Close the tap water hand valve. 2. Close the storage tank hand valve. 3. Open the water purifier exit hand valve to reduce the water pressure inside the water purifier; on the controller screen is displayed «NO FEED». Keep the water purifier exit hand valve open. 4.

  • Page 39: Change Of The Ions Exchangers Resins Bottle

    Change of the IONS EXCHANGERS RESINS BOTTLE Hand valve N°1 1. Close the tap water hand valve. 2. Close the storage tank hand valve. 3. Open the water purifier exit hand valve to reduce the water pressure inside the water purifier; on the controller screen is displayed «NO FEED».

  • Page 40: Packing List

    ACKING LIST Picture Picture Item Item water purifier «O maxi+» 76 LITERS PRESSURIZED TANK reference 951300 Reference 950240 OP101+/OP202/OMAXI/OMAXI+ RO MEMBRANE 300GPD RESIN KIT Reference 950243 HAND VALVE 1/4" HAND VALVE 3/8" Reference 950330 Reference 950029 Quantity: 4 TWO WAY DIVIDER 1/4" TEE UNION 1/4"...

  • Page 41: Service

    SERVICE The information in this chapter are reserved exclusively to service technicians. 8.1 ‘SERVICE’ MENU The ‘SERVICE’ menu, reserved to the service technicians, allows operations with risks of degradation and malfunction of the water purifier: Change of delays: flush duration; purge duration; time between 2 automatic flushes Firmware update Switch ON demonstration mode (screens displayed without checking sensors) Display firmware serial number...

  • Page 42: Timing Changes

    Timing changes These operations are reserved to service technicians. 8.1.1.1 Change flush duration TIME SETTINGS FW UPDATE DEMO MODE ABOUT SELECT:PRESS SET 2 SEC Press on ‘+’ or ‘-‘ to adjust the value. Validate by pressing with a tool for 2 seconds on the ‘SET’ button. 8.1.1.2 Change purge duration TIME SETTINGS...

  • Page 43: Firmware Update

    FW UPDATE CONFIRM DEMO MODE ABOUT SELECT:PRESS SET 2 SEC DEMO ON SELECT:PRESS SET 2 SEC Firmware version display COPYRIGHT SERVICE DIASYS TECHNOLOGIES TIME SETTINGS FRANCE FW UPDATE FIRMWARE: DEMO MODE X3110820C ABOUT ABOUT SELECT:PRESS SET 2 SEC Operator’s manual version: 2021.06...

  • Page 44: Management Of The Errors Reported By The Controller

    8.2 M ANAGEMENT OF THE ERRORS REPORTED BY THE CONTROLLER Functional errors In case of malfunction, the controller displays certain causes of error, and one error code. The error code after # contains 3 characters: # X Y Z Short circuit Cut circuit Pressure error Each character is coded in hexadecimal format: it must be converted in binary format to decode the...
  • Page 45 8.2.1.1 Short circuit detection Binary code CAUSE SUGGESTED ACTION XXX1 Purge valve in short circuit Change the purge valve XX1X Production valve in short circuit Change the production valve X1XX Pump and inlet valves in short circuit Change the pump and the inlet valves 1XXX Flush valve in short circuit Change the flush valve...

  • Page 46: Errors With Integrated Conductivty Electrodes

    Errors with integrated conductivty electrodes In case of problem with one integrated conductivity electrode, the controller continues to run, does not display the corresponding conductivity, but instead one error code on the « DETAILS » screen. Problem with the conductivity electrode Error code CAUSE...

  • Page 47: Spare Parts

    8.4 S PARE PARTS Controller Ref.950547 Filter holder 10” white body Ref.950238 Pressurised storage tank 76 Liters Ref.950240 Operator’s manual version: 2021.06...
  • Page 48 Power supply Ref.950577 Booster Pump 300GPD Ref.951301 Solenoid valve Ref.950576 Membrane Conductivity sensor Ref.951107 Membrane pressure sensor 10 Bar Ref.951204 Inlet pressure sensor 10 Bar Ref.951204 Production conductivity sensor Ref.951107 USB communication board Ref.950558 Operator’s manual version: 2021.06...

  • Page 49: Flow Path Diagram

    8.5 F LOW PATH DIAGRAM To drain The hydraulic wiring: Tubing 3/8" Flush Inlet Tubing 1/4” Solenoid pressure valve sensor Inlet Solenoid valves Hand Reverse Osmosis valve Flow restrictor Membrane Purge Inlet Booster Solenoid Check water Pump valve valve Production solenoid valve Production Hand...
  • Page 50 DiaSys Technologies 1682, rue de la Valsière Cap Gamma – Parc Euromédecine II 34790 GRABELS Tél. : 33 (0)4 11 95 03 40 Fax : 33 (0)4 11 95 03 50 Internet : http://www.diasys-diagnostics.com Email : info@diasys-technologies.com Operator’s manual version: 2021.06...
