- Page 1 BEDIENUNGS- UND MONTAGEANWEISUNG EN User Manual EMWG6260...
-
Page 2: Table Of Contents
Contents Safety Information ..........................29 Safety Instructions ..........................32 The advantages of microwaves ........................ 33 Description of microwave oven ........................ 34 Basic settings ............................36 Basic functions ............................37 When the oven is working........................39 Defrosting ............................. 40 Cooking with a microwave oven ....................... 42 Cooking with the grill .......................... -
Page 3: Safety Information
Safety Information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference. CHILDREN AND VULNERABLE PEOPLE SAFETY Warning! Risk of suffocation, injury or permanent disability. - Page 4 Safety Information Warning! The oven cannot be used if: - The door is not closed correctly; - The door hinges are damaged; - The surfaces of the contact between the door and the oven front are damaged; - The door window glass is damaged; - There is frequent electrical arcing inside the oven even though there is no metal object inside.
- Page 5 Safety Information Do not use harsh abrasive cleaners or sharp metal scrapers to clean the glass door since they can scratch the surface, which may result in shattering of the glass. Do not use a steam cleaner to clean the appliance. ...
-
Page 6: Safety Instructions
Safety Instructions Warning! Do not heat pure alcohol or alcoholic Do not switch on the oven without the turntable drinks in the microwave. FIRE RISK! support, the turntable ring and the respective plate Beware! being in place. ... -
Page 7: The Advantages Of Microwaves
The advantages of microwaves In conventional ovens, heat radiated by electrical elements or Why food heats up gas burners slowly penetrates the food from outside to Most foods contain water and water molecules vibrate when inside. On account of this there is a major amount of energy subjected to microwaves. -
Page 8: Description Of Microwave Oven
Description of microwave oven 1. – Door window glass 7. – High grille 2. – Catches 8. – Lamp 3. – Turntable support 9. – Control panel 4. – Turntable ring 10. – Grill 5. – Turntable plate 11. – Mica cover 6. - Page 9 Description of microwave oven Description of Functions Function Microwaves Power Foods Slow defrosting for delicate foods; keeping food hot 180 W Cooking with little heat; boiling rice. Rapid defrosting 300 W Melting butter. Heating baby food Microwave 550 W Cooking vegetables and food. Cooking and heating carefully. Heating and 750 W cooking small portions of food.
- Page 10 Basic settings Setting the clock After your microwave oven is first plugged-in or after a power failure, the clock display will flash to indicate that the time shown is not correct. 1,2,4 12:45 1. Press the “+“ and “-“ keys until the current time 3.
-
Page 11: Basic Settings
Basic Settings Child Lock function The Oven function can be blocked (for example, to stop it being used by children). 12:45 1. To block the oven, press the Child lock key for 3 2. To unblock the oven, press the STOP key again for 3 seconds. -
Page 12: Basic Functions
Basic functions Grill Use this function to brown the surface of food quickly. 12:45 3. Press the Start/Stop key. The cooking process will 1. Turn the function selector to the grill position. begin. The duration icon and the numbers begin to flash. Please note: The position of the microwave selector does not affect the operation. -
Page 13: When The Oven Is Working
When the oven is working... Interrupting a cooking cycle Altering parameters You can stop the cooking process at any time by pressing The operating parameters the Stop key once or by opening the oven door. Time (with the “+“ and “-“ keys) In both cases: ... - Page 14 Defrosting To defrost food you should select Microwave function with The table below shows different defrosting and standing times one of the following Power Levels: (in order to ensure the food temperature is evenly distributed) for different types and weights of food, plus recommendations. Position Power Level Power...
-
Page 15: Defrosting
Defrosting General instructions for defrosting 1. When defrosting, use only dishes that are appropriate 8. Place poultry on an upturned plate so that the meat for microwaves (china, glass, suitable plastic). juices can run off more easily. 2. The defrost function by weight and the tables refer to 9. -
Page 16: Cooking With A Microwave Oven
Cooking with a microwave oven When heating liquids, use containers with a wide Warning! Read the section “Microwave Safety” before opening, so that the steam can evaporate easily. cooking with your microwave. Prepare the foods as per the instructions and keep in mind Follow these recommendations when cooking with your the cooking times and power levels indicated in the tables. - Page 17 Cooking with a microwave oven Tables and suggestions – Cooking vegetables Addition of Power Time Standing Food Quantity (g) Instructions liquids (Watt) (min.) Time (min.) Cauliflower 100 ml 9-11 Divide into florets Broccoli 50 ml Cut into slices Mushrooms 25 ml Turn 1 x, cover Peas &...
-
Page 18: Cooking With The Grill
Cooking with the grill For good results with the grill, use the grid iron supplied with 4. If the grill is used for extended period of time it is the oven. normal to find that the elements will switch themselves off temporarily due to the safety thermostat. - Page 19 Cooking with the Grill Tables and suggestions – Microwave + Grill the grill work simultaneously. The microwave cooks and the The microwave + grill function is ideal for cooking quickly grill toasts. and, at the same time, browning foods. Furthermore, you can also grill and cook cheese covered food.
-
Page 20: What Kind Of Ovenware Can Be Used
What kind of ovenware can be used? Microwave function Keep in mind the manufacturer’s recommendations For the microwave function, keep in mind that microwaves written on the packaging. are reflected by metal surfaces. Glass, china, clay, plastic, The aluminium containers cannot be more than 3 cm and paper let microwaves pass. - Page 21 What kind of ovenware can be used? Table of Ovenware The table below gives you a general idea of what type of ovenware is suitable for each situation. Microwave Operating mode Microwave + Grill Defrosting / Grill Cooking Type of ovenware heating Glass and china Home use, not flame resistant, can be used in...
-
Page 22: Oven Cleaning And Maintenance
Oven Cleaning and Maintenance Cleaning is the only maintenance normally required. Oven interior Warning! Your microwave oven should be cleaned regularly, After each time the oven is used, clean the inside walls with a with all food remains being removed. If the microwave is not damp cloth since this is the easiest way to remove splashes kept clean its surfaces may deteriorate, reducing the oven’s or spots of food that may have stuck to the inside. - Page 23 Oven Cleaning and Maintenance The mica cover (3) located in the ceiling must always be Oven ceiling kept clean. Any food remains that collect on the mica cover can cause damage or provoke sparks. If the oven ceiling is dirty, the grill can be lowered to make cleaning easier.
-
Page 24: What Should I Do If The Oven Doesn't Work
What should I do if the oven doesn’t work? The food is too hot, dried out or burnt! Check if you WARNING! Any type of repair must only be done by a selected the correct operating time and power level. specialised technician. -
Page 25: Technical Characteristics
Technical characteristics Specifications AC Voltage ......................230-240 V / 50 Hz Power required....................... 3300 W Grill power......................1500 W Microwave output power..................1000 W Microwave frequency … ..................2450 MHz Exterior dimensions (WHD)................595 455 472 mm ... -
Page 26: Installation Instructions
Installation instructions Before installation After installation Check that the input voltage indicated on the The oven is equipped with a power cable and a plug for characteristics plate is the same as the voltage of the power single phase current. outlet you are going to use. -
Page 27: Installation
Einbau / Installation Die Mikrowelle in die Nische einschieben und entsprechend anpassen. Die Tür der Mikrowelle öffnen und das Gerät mit den vier mitgelieferten Schrauben am Küchenmöbel Bild dargestellt befestigen. Push oven completely into the cabinet and centre it. - Page 30 Küppersbusch Hausgeräte GmbH Postfach 10 01 32, D-45801 Gelsenkirchen, Küppersbuschstr. 16, D-45883 Gelsenkirchen Telefon: (02 09) 4 01-0, Telefax: (02 09) 4 01-3 03 www.kueppersbusch.de Teka Austria GmbH Eitnergasse 13, A-1230 Wien Telefon: (01) 8 66 80-15, Telefax: (01) 8 66 80-50 www.kueppersbusch.at...
