HN-G-01/ 02 Filter Series
Manual
NOTICE
Changes or modifications not expressly approved by Rain Bird
could void the user's authority to operate the equipment.
WARNING
It is extremely dangerous to open the filter, or control tubing
while under pressure. Always depressurize before performing
any maintenance or troubleshooting.
Rain Bird Corporation
6991 East Southpoint Rd.
Tucson, AZ
85756
D42056
Advertisement
Table of Contents
Related Manuals for Rain Bird HN-G-01 Series
Summary of Contents for Rain Bird HN-G-01 Series
- Page 1 HN-G-01/ 02 Filter Series Manual NOTICE Changes or modifications not expressly approved by Rain Bird could void the user’s authority to operate the equipment. WARNING It is extremely dangerous to open the filter, or control tubing while under pressure. Always depressurize before performing any maintenance or troubleshooting.
- Page 2 1. Introduction Congratulations for purchasing the HN-G automatic self-cleaning filter. Rain Bird filters are being used in various irrigation applications as well as industrial water applications. The HN-G filter is easy to install, does not require special skills or tools to operate and is Ideal for filtering out silt, scale, sand, rust and dirt from a variety of irrigation water sources.
-
Page 3: Operation
1.3 Overview Filter Components HN-G models are automatic, self-cleaning screen-type water filters. The filtration system consists of a filter body, hydraulic piston, filter screen, Self-Clean mechanism and drain valve. Piston Piston Shaft Piston O-Ring Filter Cover O-Ring Plate Seal Screen O-Rings Inlet Disc Seal Housing Inlet Disc... -
Page 4: Installation
2. Installation 2.4.1 Location: IMPORTANT The HN-G filter should be installed vertically Allow a minimum clearance of 10” (ten inches) above the HN-G for safe removal of the filter cover. Locate the HN-G filter as close to a drain as possible. This will maximize the efficiency of the automatic self-cleaning. An AC to 12VDC power source is required for the Backwash Controller if batteries are not used (HN-G-01-1-XXX, HN-G-02-1-XXX models only). - Page 5 2.4.2 Installation requirements When installing the ¼” plastic tubing into the appropriate fittings – push the tubing in hard, it should go in about a ¼”. It should be tight into the fitting and does not come out when you pull on it. The drain pipe should be a minimum of 1.25”...
-
Page 6: Mechanical Installation
3. Mechanical Installation Piston O-ring Filter assembly 3.4.1 Piston Installation The Filter unit ships without the piston installed Ensure that the o-ring is in place on the threads of the Piston. Push the piston into the main body of filter. Ensure that the push to connect fitting at the top of the piston lines up with the 1/4"... -
Page 7: Electrical Installation
This section relates to the following models only: HN-G-01-1-XXX, HN-G-02-1-XXX 4. Electrical Installation 4.4.1 If 110 VAC is Available Plug in AC power adapter. IMPORTANT If installed outdoors power adapter must be plugged into a weather protected outlet. 4.4.2 If Battery Powered Remove the top gray cover (push up the sides over the indent). -
Page 8: Maintenance
5. Maintenance This filter, while automatic in function, is not maintenance free. It is expected that the screen will require pressure washing on a periodic schedule to remove contaminants that have stapled into the screen. Depending on the contaminant, the frequency can vary from once a week to twice a year. - Page 9 21. Carefully replace the Hydraulic Motor and Plate into the Filter Housing , ensuring that the Piston Shaft is inserted into the hole in the middle of the Inlet Disc 22. Push down firmly on the Plate . When correctly in place the central collar of the Plate will be flush with the top of the Housing .
- Page 10 area and solenoid. It is usually easier to just unscrew the top of the valve cover and drain the diaphragm area that way. Manually cleaning the Filter Screen element before storage is also a good idea. That will prevent debris from drying on the screen and becoming difficult to remove the following season.
- Page 11 This section relates to the following models only: HN-G-01-1-XXX HN-G-02-1-XXX 6. FILTRON 1-10 (DC) Manual The Filtron 1-10 requires minimal to no user programming, the following sections are only related to site specific programming requirements. 6.1 Features • Modular backflushing controller for automatic filters of 1 to 2 stations. •...
- Page 12 Notice that before the first use of the unit, it may be necessary to pass through the configuration process prior to defining the flushing program in order to adjust the features of controller to the specific application. The configuration process is described below. 6.2.1 The chain of editable fields Below is the chain of editable fields.
- Page 13 6.2.4 The Flush Mode The Flush Mode defines how the flushing cycles is triggered. The selectable options are as follows: OFF - No flushing will take place By time – In this case the flushing cycles will be repeated in a selected interval or will be triggered by the DP signal depending on what happens first.
-
Page 14: Low Battery
Looping limit the number of consecutive flushing cycles triggered by the DP sensor before deciding that there is an endless looping problem. The options are: 1-10 or “no” which means ignoring the looping problem. Alarm Yes/No – allocating one output for alarm activation. Delay Valve Yes/No –... - Page 15 A. Appendix A.1 DC MODEL The drawing below shows the wiring of the DC model of the controller. Notice that: The External DP sensor is optional and it is intended for use in cases there is no Embedded Electronic DP included. The powering of the unit is by (4) D Cell Batteries or 110/ 220 AC to 12 VDC adapter or 12 VDC battery The solenoids will be of 9-12 VDC.
-
Page 16: Troubleshooting
Remove the Filter Screen and manually clean it. Follow instructions in Section 5a above Wait Time between Self-Cleaning cycles is too long. Solution: • Adjust Interval timer in Backwash Controller Problems with Solenoid/Backwash Controller Unit. • Solution: Contact Rain Bird GSPpumpteam1@rainbird.com A.6.2 Problem: Valve malfunction Possible causes: Ruptured Diaphragm • Replace Diaphragm Solenoid malfunction •... -
Page 17: Appendix C (System Specification)
B. Appendix C (System Specification) B.1 Estimate flow rate and record pressure Place a 5 gallon bucket at the water source and allow it to flow without restriction into the bucket. Time how long it takes to fill to the 5 gallon point. Example Volume of Bucket (in gallons) x 60... -
Page 18: Installation Example
C. Installation Example 1 How your filter is installed will depend on how your system is structured and the specific requirements of your site. This example illustrates a stand-alone filter installation with minimal added components in discharge plumbing like what is located on a municipal feed water source (or pumped water where the pump is located remotely). - Page 19 D. Installation Example 2 This example illustrates a filter installation in discharge plumbing located on the output of a pump and also a controlled outlet valve on the discharge of the filter to accommodate low flow rate applications where all pressure and flow must be utilized for backwash (the controlled outlet valve can also be applied in installation example A and C).
- Page 20 E. Installation Example 3 This example illustrates a bypass configuration. Piston 1” Hydraulic drain valve Union fitting* Pressure gauge* Pressure gauge* Union fitting* Isolation valve* Union fitting* Isolation valve* Bypass valve* Drain (to drain) Inlet (from pump) Outlet (to irrigation) * User to supply...
-
Page 21: Parts List
F. Parts List Piston MTFC-09 Piston Shaft MTFC-09 Piston O-Ring MTFC-014 Filter Cover O-ring MTFC-015 Plate Seal MTFC-012 Screen O-ring MTFC-013 Inlet Disc Seal MTFC-011 Housing MTFC-10-01 Inlet Disc MTFC-02 Inlet Bearing MTFC-03 Filter Screen MTFC-10-04-X Plate MTFC-10-06 Clamp MTFC-08 Cover MTFC-07 Hydraulic Motor... - Page 22 G. Dimensions 12 1/8" REF 6" FILTER SERVICE AREA Ø 5 3/4” PESB SCRUBBER VALVE 7 1/16” 1” PVC SOCKET CONNECTION 1" Models 2" Models 1" 2" 1" 2" 7 1/8" 7 1/4" 22 13/16" 25 5/8" 9 15/16" 10 9/16" 6"...
