Summary of Contents for Verde VER-EVC-7
- Page 1 AC CHARGER USER MANUAL VER-EVC-7...
-
Page 2: Table Of Contents
Contents Safety Instruction ............................- 2 - 1 Product Overview ............................- 3 - 1.1 Product Introduction ........................- 3 - 1.2 Schematic Diagram ........................- 3 - 1.3 Specification Parameter ........................ - 3 - 1.4 Performance and Characteristics ............Error! Bookmark not defined. 1.5 Working Environment ........................ -
Page 3: Safety Instruction
Please contact Verde in case of above conditions. DO NOT attempt to dissemble, repair, refit the charger. If necessary, please contact the Verde for assistance. Improper operation will result in device damage, electric leakage, etc. Please take caution while charging in the rain or where lightning is present. -
Page 4: Product Overview
1 Product Overview 1.1 Product Introduction The single-phase AC charger is used for electric vehicle’s AC charging, with the function of charging by scanning the RFID card. The RFID card is a key component to start or stop the charging session. The LED indicator on the front panel helps you understand what is happening with the charger by indicating different colors. -
Page 5: Specification Parameter
1.3 Specification Parameter Model No. VER-EVC-7 User Interface LED indicator, RFID card reader Housing Material Plastic Installation Wall-mount (default), Floor-stand (optional) Card Quantity 2pcs Configuration Charging Outlet One charging gun type 2 Product 325*181*87mm ( L*W*H ) Dimension Net Weight 3.01KG... -
Page 6: Performance And Characteristics
1.4 Performance and Characteristics Performance: ➢ LED Indicator: Different color lights indicate different working status of the charger. RFID Card: Built-in card reader to realize the function of charging with RFID card. ➢ Scan RFID card first to start charging, and scan RFID card again to end charging Characteristics: ➢... -
Page 7: Product Naming
1.6 Product Naming EVC - 7 Charger version Electric Vehicle Charger Product Code of AC charger - Verde 1.7 Product Structure 1.7.1 External Structure - 6 -... -
Page 8: Internal Structure
1.7.2 Internal Structure - 7 -... -
Page 9: Operation Instruction
2 Operation Instruction 2.1 Product Installation 2.1.1 Package Verification Unpack to check and verify following items after receiving the charger: ⚫ Visual inspection on external appearance. Anything broken or damaged, notify the seller immediately. ⚫ Check accessory type and quantity. If you have received an incorrect type or quantity, contact the seller at once. -
Page 10: Installation Process
2.1.3 Installation Process 1) Installation Notice a) Electrical device should be installed, operated, serviced, and maintained only by qualified personnel. No responsibility is assumed by the manufacturer for any consequences arising out of the use of this device. A qualified person is one who has skills and knowledge related to the construction, installation and operation of electrical device and who has received safety training to recognize and avoid the hazards involved. -
Page 11: Power-On Checking
2.2 Power-on Checking 1) Check before Power-on Please check the followings before any operation: The charger’s location is easy for operation and repairing. Double confirm the charger is installed properly. AC input’s current leakage protection switch is reasonable. No other stuff or component left on the top of the charger. 2）Power-on Charger 1. -
Page 12: Charging Operation
2.3 Charging Operation 2.3.1 Connect Charger to EV Park EV near to the charger and plug its charging gun into the EV. After charger is plugged-in, please check the gun is correctly and tightly connected. With appropriate connection, the charger LED indicator will change to a flashing yellow light, which indicates that the charger is ready for charging but not charging. - Page 13 Flashing red, 500ms on, 500ms off, 7 times, Over voltage fault Fault 3S off, Cycle Flashing red, 500ms on, 500ms off, 8 times, Overload fault Fault 3S off, Cycle Flashing red, 500ms on, 500ms off, 9 times, Over frequency fault Fault 3S off, Cycle Flashing red, 500ms on, 500ms off, 10 times,...
-
Page 14: Disposal
Leakage current to 1. Shut off the leakage current protection switch of Over leakage the earth may be power distribution cabinet immediately. current too high. 2. Check whether there is broken of AC output cables or low resistance connection to the earth. Leakage current Detection of leakage 1. - Page 15 please contact your local city office, your household waste disposal service or the shop where you purchased the device. - 14 -...
- Page 16 Unit 4 Courtstown Industrial Estate, Little Island, Cork, Ireland T45 R778 www.verdeenergygroup.com Due to the Verde’s policy of continual product development; specifications, colours and details of our products and those mentioned in this manual are subject to change without notice.
