GPSmap 60C
Appendix
Interface Wiring Diagram
(-) Ground
Data In
(+) Power
Unit Power/Data Port View
80
this manual. The input/output lines on your GPSmap 60C are RS-232
compatible, allowing easy interface to a wide range of external devices,
including PC' s , differential beacon receivers, marine autopilots and /or a
second GPS receiver.
GPSmap 60C and enables the unit to drive up to three NMEA devices.
Data Out
NMEA 0183 Version 3.01 Approved Sentences:
Garmin Proprietary Sentences:
version 2.0 format through the "Data In" line. Beacon receivers with the
correct RTCM format may be used, but may not correctly display status
or allow tuning control from the GPS unit.
Interface formats are selected from the Interface Setup on page 46 of
The NMEA 0183 version 3.01 interface format is supported by the
GPGGA, GPGLL, GPGSA, GPGSV, GPRMB, GPRMC, GPRTE, GPVTG,
GPWPL, GPBOD
PGRME (estimated error), PGRMM (datum string), PGRMZ (altitude),
PSLIB (beacon receiver control)
DGPS (Differential GPS) corrections are accepted in RTCM SC-104
The USB Interface Cable provided with
this unit allows you to connect your
GPSmap 60C to a PC-compatible
computer' s USB port.
