- Page 1 PG 1 OF 10 SOFA CMC71 CLC71 LOVESEAT CMC47 CLC47 ASSEMBLY INSTRUCTIONS 12/20/2012...
- Page 2 Sections needed for Sections needed for SOFA LOVESEAT box - CLC23R box - CLC23R box - CLC23C box - CLC23L box - CLC23L CLC71 CLC47 Sections needed for Sections needed for LOVESEAT SOFA box - CMC23R box - CMC23R box - CMC23L...
-
Page 3: Sofa Assembly
PG 3 OF 10 SOFA ASSEMBLY CLC71 shown ASSEMBLY INSTRUCTIONS 12/20/2012... -
Page 4: Tools Needed
Sofa Assembly PG 4 OF 10 Layout Parts Backs Seat supports Cushions Seats (3) Back Back rails Sideframes (3) Seat Center legs Layout Hardware Tools Needed note: you will need hardware pack from CLC23C box 4mm Hex Key - included A - .27 X 3 SOCKET WAFER A Qty 20 4mm Hex Bit for screw gun - included Phillips head screwdriver... - Page 5 PG 5 OF 10 Sofa Assembly note: use course thread on 1,2,3,4,5 Step 2 Step 1 Attach Back to Seat Attach Seat support using (2) 3” chair screws using (2) 3” chair screws Step 3 Repaet until all seat/back assemblies are complete Step 4 Step 5 Attach Right side frame and Right back rail...
- Page 6 Sofa Assembly PG 6 OF 10 note: use fine thread bolts for 7, 8, 9 Step 6 Fit all sections together with Center legs → Step7 Attach small center legs with (2) 3 1/4" chair bolts and (2) barrel nuts Step 8 Attach Rails to Back legs using (2) 1 1/2"...
- Page 7 PG 7 OF 10 LOVESEAT ASSEMBLY CLC47 shown ASSEMBLY INSTRUCTIONS 12/20/2012...
- Page 8 PG 8 OF 10 Loveseat Assembly Backs Seat supports Seats Back rails Sideframes Center legs Layout Hardware Tools Needed 4mm Hex Key - included A - .27 X 3 SOCKET WAFER A Qty 16 4mm Hex Bit for screw gun - included Phillips head screwdriver B - 1/4-20 x 1/2"...
- Page 9 PG 9 OF 10 Sofa Assembly note: use course thread on 1,2,3,4,5 Step 2 Step 1 Attach Back to Seat Attach Seat support using (2) 3” chair screws using (2) 3” chair screws Step 3 Repaet until all seat/back assemblies are complete Step 4 Step 5 Attach Right side frame and Right back rail...
- Page 10 Loveseat Assembly PG 10 OF 10 note: use fine thread bolts for 7, 8, 9 Step 6 Fit all sections together with Center legs → Step 7 Attach small Center leg with (1) 3 1/4" chair bolt and (1) barrel nut Step 8 Attach Rails to Back leg using (1) 1 1/2"...
