- Page 1 DCM267 DIGITAL CLAMP METER DIGITALE STROOMTANG PINCE AMPEREMETRIQUE DIGITALE STROMZANGE User Manual Gebruikershandleiding Manuel d’utilisation Gebrauchsanleitung...
- Page 2 DCM267 – DIGITAL CLAMP METER 1. Introduction Thank you for buying the DCM267 ! This device enables the user to measure DC & AC voltages, AC current, resistance, temperatures and frequency. You can also test diodes and continuity. 2. Safety...
- Page 3 • If you insist on calibrating the instrument yourself, you should only do so in the presence of a qualified technician. 4. General Description The DCM267 is a hand-held, battery-operated 3 ½ digital clamp meter for measuring DC and AC voltages, AC current, resistance, frequency, temperature (°C & °F), diodes and continuity. 5. Description of the Front Panel Jaws They pick up the AC current flowing through the conductor.
- Page 4 DCM267...
- Page 5 1) Place the rotary switch in the °C- or °F-position. The current ambient temperature will now appear on the display. 2) Connect the “K”-type thermocouple with the temperature measuring socket on the front panel and touch the object in question with the thermocouple probe. 3) The temperature of the object appears on the display. DCM267...
- Page 6 Display Max. reading is 1999 Reading Rate 2-3 readings/sec. Polarity Indication “-“ is displayed to indicate negative polarity Overrange Indication Only figure “1” is displayed Jaw Opening 55mm (= max. size or Ø of the conductor) DCM267...
- Page 7 2MŸ 1kŸ ±1.5% of rdg ± 5 digits 7.5. Temperature in C° Range Resolution Testing Range Accuracy 0°C to 400°C ±1.0% of rdg ± 3 digits 0°C to 750°C 1°C 400°C to 750°C ±2.0% of rdg ± 1 digit DCM267...
- Page 8 4. Replace the cover and tighten the screw. Remark : Respect all applicable laws when disposing of your old batteries. 9. Accessories • User manual • Set of test leads • “K”-type thermocouple • 9V battery (NEDA1604 or IEC6F22) • Gift box DCM267...
