MX57QM
Intel® QM57 Mini ITX featuring latest two chips design, supports Intel® Core™
i7, i5, i3 Arrandale Mobile processors, DDR3-800/1066 SODIMM up to 8GB,
18/24-bit LVDS, HDMI, DVI-D, Dual Gigabit Ethernet, 6 COM ports with Power
Selection, 5 SATA, PCI Express x16, one min-PCIE.
User's Manual
Ver. 1.1
BCM Advanced Research, An Industrial Leader Since 1990 in Industrial Motherboards & Systems
7 Marconi, Irvine, CA 92618 USA | www.bcmcom.com | (PH)949.470.1888 | (FAX)949.470.0971
For Tech Support, please visit www.bcmcom.com/bcm_support_legacyProductSupport.htm or contact
BCMTechSupport@bcmcom.com
1

Advertisement

Table of Contents
loading

Related Manuals for BCM MX57QM

Summary of Contents for BCM MX57QM

  • Page 1 Selection, 5 SATA, PCI Express x16, one min-PCIE. User’s Manual Ver. 1.1 BCM Advanced Research, An Industrial Leader Since 1990 in Industrial Motherboards & Systems 7 Marconi, Irvine, CA 92618 USA | www.bcmcom.com | (PH)949.470.1888 | (FAX)949.470.0971 For Tech Support, please visit www.bcmcom.com/bcm_support_legacyProductSupport.htm or contact...

  • Page 2: Table Of Contents

    Notice......................... 4 Copyright Notice ......................4 Trademark Acknowledgement..................4 Disclaimer ........................5 Life Support Policy..................... 5 BCM Customer Services.................... 5 Product Warranty ....................... 6 Manual Objectives ..................... 7 Safety Precautions..................... 7 Document Amendment History .................. 7 Chapter 1 ........................8 Block Diagram......................

  • Page 3: Tables

    Tables Table 1 Specification ....................17 Table 2 Jumper List....................25 Table 3 PCIE_JP1 Mini PCIE Version Selection ............25 Table 4 COMS1 Clear CMOS Selection..............25 Table 5 JP2 Backlight Enable Selection ..............26 Table 6 JP3 Backlight Power Selection ..............26 Table 7 JP5 Power mode Selection .................

  • Page 4: Fcc Statement

    For detailed information, please always refer to the electronic user's manual. Copyright Notice Copyright © 2010 BCM Advanced Research, ALL RIGHTS RESERVED. No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer.

  • Page 5: Disclaimer

    Our dealers are well trained and ready to give you the support you need to get the most from your BCM products. In fact, most problems reported are minor and are able to be easily solved over the phone.

  • Page 6: Product Warranty

    Because of BCM high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If any of BCM products is defective, it will be repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement materials, service time, and freight.

  • Page 7: Manual Objectives

    We strongly recommend that you study this manual carefully before attempting to interface with MX57QM or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance.

  • Page 8: Chapter 1

    Chapter 1 This chapter describes the motherboard features and the new technologies it supports. Product Introduction...

  • Page 9: Block Diagram

    Block Diagram Arrandale Processors DDR3 SO-DIMM DDR3 800/1066 MT/s PCIEx16 slot DDR3 SO-DIMM DDR3 800/1066 MT/s Mini-PCIe SSD 5th SATA 4 x SATAs 6 x SATAs 18/24 bit LVDS LVDS SATA Compact Flash Level PATA Shift 8 x USB2.0 Level Shift HDMI BIOS...

  • Page 10: Motherboard Specifications

    Table 1 MX57QM Specification MX57QM Specifications System Socket 989 supports Intel® Mobile Core™ i7, i5, i3, Arrandale Processors AMI® 32Mb SPI BIOS BIOS Intel® QM57 System Chipset One double stack SO-DIMM for dual channel DDR3 800/1066 supported, Memory non-ECC, up to 8GB...

  • Page 11: Before You Proceed

    Before you Proceed Take note of the following precautions before you install motherboard components or change any motherboard settings. Unplug the power cord from the wall socket before touching any component. Use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, before handling components to avoid damaging them due to static electricity...

  • Page 12: Motherboard Overview

    1.1 Motherboard Overview Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Refer to the chassis documentation before installing the motherboard. Make sure to unplug the power cord before installing or removing the motherboard.

  • Page 13: Motherboard Layout

    1.2 Motherboard Layout...

  • Page 14: Central Processing Unit (Cpu)

    1.3 Central Processing Unit (CPU) The motherboard comes with a surface mount designed for the Intel® socket 989 Arrandale processors. Please note the marked corner (with gold triangle) on the CPU. This mark should match a specific corner on the socket to ensure correct installation.

  • Page 15: Install The Cpu

    1.3.1 Installing the CPU 1. Locate the CPU socket on the motherboard. Before installing the CPU, make sure that the socket box is facing towards you. The processor socket comes with a screw to secure the processor, please unlock the screw first.  ...

  • Page 16: Installing The Cpu Heatsink And Fan

    1.3.2 Installing the CPU Heatsink and Fan 1. Screw down two fasteners at a  time in a diagonal sequence to  secure the heatsink and fan  assembly in place.  Connect the CPU fan cable to the connector on the motherboard labeled CPU_FAN1. Do not forget to connect the fan cables to the fan connectors. Insufficient air flow inside the system may damage the motherboard components, and hardware monitoring errors can occur if you fail to plug this connector.

  • Page 17: Uninstalling The Cpu Heatsink And Fan

    1.3.3 Uninstalling the CPU Heatsink and Fan Disconnect the CPU fan cable from the connector on the motherboard. Unscrew each fastener counterclockwise.   Loosen two fasteners at a time in a diagonal sequence to disengage the heatsink and fan assembly from the motherboard Carefully remove the heatsink and fan assembly from the motherboard.

  • Page 18: System Memory

    1.4 System Memory SO-DIMM Sockets Location The motherboard comes with two 204-pin Double Data Rate 3 (DDR3) SO-DIMM sockets. Memory Configurations You can install 1GB, 2GB and 4GB DDR3 SDRAM SO-DIMMs into the SO-DIMM sockets using the memory configurations in this section. Installing DDR3 SO-DIMM other than the recommended configurations may cause memory sizing error or system boot failure.

  • Page 19: Installing The Memory

    1.4.1 Installing a DDR3 SO-DIMM Make sure to unplug the power supply before adding or removing SO-DIMMs or other system components. Failure to do so may cause severe damage to both the motherboard and the components. Locate the SO-DIMM socket on the board. Hold two edges of the SO-DIMM module carefully, and keep away of touching its connectors.

  • Page 20: Unistalling The Memory

    1.4.2 Removing a DDR3 SO-DIMM 1. Press the two ejector tabs on the slot outward simultaneously, and then pull out the SO-DIMM module. Support the SO-DIMM lightly with your fingers when pressing the ejector tabs. The SO-DIMM might get damaged when it flips out with extra force.

  • Page 21: Expansion Slot

    1.5 Expansion slots In the future, you may need to install expansion cards. The following sub‑sections describe the slots and the expansion cards that they support. Make sure to unplug the power cord before adding or removing expansion cards. Failure to do so may cause you physical injury and damage motherboard components.

  • Page 22: Jumpers

    1.6 Jumpers The product has several jumpers which must be properly configured to ensure correct operation. Jumper Connector For a three-pin jumper, the jumper setting is designated “1-2” when the jumper connects pins 1 and 2. The jumper setting is designated “2-3” when pins 2 and 3 are connected and so on.

  • Page 23: Jumper Settings And Pin Definitions

    1.6.1 Jumper Settings and Pin Definitions For jumper and connector location, please refer to the diagrams below. Top View SATA1-5 USB1, 2 SPDIF1 AMP_R1 J8, J7 AMP_L1 J6, 10 J11, J9 COMS1 COM 2 PCIE1 COM 3 CPU SOCKET COM 4 COM 5 COM 6 (BOTTOM SIDE)
  • Page 24 Bottom View Jumper and Connector Locations – Bottom View Rear Panel LAN_USB2 PS2 KB/MS COM1 LINE-IN LAN_USB1 LINE-OUT HDMI Rear panel IO...

  • Page 25: Jumper Settings

    1.6.2 Jumper Settings To ensure correct system configuration, the following section describes how to set the jumpers to enable/disable or change functions. For jumper descriptions, please refer to the table below Table 2 Jumper List Label Function PCIE_JP1 Mini PCIE Rev1.1 & 1.2 Mode Selection COMS1 Clear CMOS Selection Backlight Enable Selection...

  • Page 26: Table 6 Jp3 Backlight Power Selection

    Table 6 JP3 Backlight Power Selection Jumper Status +12V Pitch: 2.0mm Jumper default ( 1-2 ) Table 7 JP5 Power mode Selection Jumper Status Open ATX Mode Short AT Mode Pitch: 2.54mm Default ( ATX Mode ) Table 8 JP6 COM3 Signal / Power Selection Jumper Status Pin 9 of COM3 = +12V...

  • Page 27: Table 10 Jp8 Com2 Signal / Power Selection

    Table 10 JP8 COM2 Signal / Power Selection Jumper Status Pin 9 of COM2 = +12V Pin 9 of COM2 = RI Pin 9 of COM2 = +5V Pitch: 2.0mm Jumper default ( 3-4 ) Table 11 JP9 COM6 Signal / Power Selection Jumper Status Pin 9 of COM6= +12V...

  • Page 28: Rear Panel Pin Assignments

    1.7 Rear Panel Pin Assignments PS2-KBMS1 COM1 HDMI1 DVI_VGA1 LAN1 LAN2 AUDIO1 Rear Panel IO Table 14 Rear Panel Connector List Label Function PS-KBMS1 PS/2 KB/MS Mini-DIN Connector DVI_VGA1 DVI & VGA Connector HDMI1 HDMI1 connector LAN1 10/100/1000 Ethernet RJ-45 Connector LAN2 10/100/1000 Ethernet RJ-45 Connector COM1...

  • Page 29: Table 16 Lan1 Rj-45 + Usb Port-0&1 Connector

    Table 16 LAN1 RJ-45 + USB Port-0&1 Connector Signal Signal Yellow LED Green LED# Orange LED# USB_PWR USB_N0 USB_P0 USB_PWR USB_N1 USB_P1 Yellow LED# USB*2/RJ45*1+TFM+LED(10/100/1000)22P DIP 90° Table 17 LAN2 RJ-45 + USB Port-2&3Connector Signal Signal Yellow LED Green LED# Orange LED# USB_PWR...

  • Page 30: Table 18 Com1 Rs-232 Db-9 Connector

    Table 18 COM1 RS-232 DB-9 Connector Signal DCD, Data carrier detect RXD, Receive data TXD, Transmit data DTR, Data terminal ready GND, ground DSR, Data set ready RTS, Request to send CTS, Clear to send RI, Ring indicator D-SUB 9P 90D (M) with hexagonal screws Table 19 HDMI1 Connector Signal Name...

  • Page 31: Main Board Pin Assignments

    1.8 Main Board Pin Assignments 1.8.1 Internal Connector List Table 21 Internal Connector List Label Function DIMM1 DDR3 Memory SO-DIMM Socket DIMM2 DDR3 Memory SO-DIMM Socket CPU_FAN1 CPU FAN Wafer CHA_FAN1 SYSTEM FAN Wafer MPCIE1 PCIE x 1 Slot rDA Pin Header LVDS1 LVDS Panel Pin Header Panel Backlight Wafer...

  • Page 32: Table 22 Cpu_Fan1 Cpu Fan Wafer

    DIMM 1&2 DDR3 Memory SO-DIMM Slot DDR3 1.5V High=5.2mm STD Table 22 CPU_FAN1 CPU FAN Wafer Signal +12V FAN_CPU_TACH FAN_CPU_CTRL Pitch: 2.54mm WAFER Table 23 CHA_FAN1 SYSTEM FAN Wafer Signal +12V HW_FANIN1 Pitch: 2.54mm WAFER Table 24 IR1 IrDA remote control Wafer Signal Name IRRX IRTX...

  • Page 33: Table 26 Mpcie1 Mini Pcie Connector

    Table 26 MPCIE1 Mini PCIe Connector Signal Signal WAKE# +3.3V Reserved Ground Reserved +1.5V CLKEQ# UIM_PWR Ground UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RESET Ground UIM_VPP Reserved Ground Reserved W_disable# Ground PERST# PERn0 +3VSB PERp0 Ground Ground +1.5V Ground SMB_CLK PETn0 SMB_DATA PETp0 Ground Ground...

  • Page 34: Table 28 Sata5 Serial Ata Connector

    Table 28 SATA5 Serial ATA Connector Signal Name SATA CONNECTOR BLACK Table 29 COM2,COM3,COM4,COM5,COM6 RS-232 Box Header Signal DCD, Data carrier detect RXD, Receive data TXD, Transmit data DTR, Data terminal ready GND, ground DSR, Data set ready RTS, Request to send CTS, Clear to send RI, Ring indicator DIP 10P 2R 180°...

  • Page 35: Table 31 Atxpwr1 24-Pin Atx Power Input Connector

    Table 31 ATXPWR1 24-pin ATX Power Input Connector Signal Signal +3.3V +3.3V +3.3V -12V PS_ON POWER +5VSB +12V +12V +3.3V Pitch: 3.96mm Table 32 FP3 Digital Input / Output Pin Header Signal Signal MIC_L MIC_R ACZ_DET# LIN_R MIC_JD SENSE LIN_L LINE_JD Pitch: 2.54mm Table 33...

  • Page 36: Table 35 Cf1 Cf Type Ii Connector

    Table 35 CF1 CF Type II Connector Signal Name Pin Pin Signal Name IDE Data 3 IDE Data 11 IDE Data 4 IDE Data 12 IDE Data 5 IDE Data 13 IDE Data 6 IDE Data 14 IDE Data 7 IDE Data 15 IDE Chip select IDE Chip select...

  • Page 37: Table 38 Spdif1 S/Pdif Pin Header

    Table 38 SPDIF1 S/PDIF Pin Header Signal Name S/PDIF In S/PDIF Out P-2.54mm Table 39 DIO1 Digital Input / Digital Output Pin Header Signal Signal DIP 18P 2R MALE STRAIGHT TYPE Pitch: 2.54mm Table40 BL1 LVDS Backlight Inverter Wafer Signal Name Backlight Control Backlight Power Backlight Power...

  • Page 38: Table 41 Lvds1 Channel 1 Lvds Connector

    Table 41 LVDS1 Channel 1 LVDS Connector Signal Name Signal Name +3.3V +3.3V DDC_CLK DDC_DATA LVDS0_DATA1 LVDS0_DATA0 LVDS0_DATA#1 12 LVDS0_DATA#0 LVDS0_DATA3 LVDS0_DATA2 LVDS0_DATA#3 18 LVDS0_DATA#2 LVDS1_DATA1 LVDS1_DATA0 LVDS1_DATA#1 24 LVDS1_DATA#0 LVDS1_DATA3 LVDS1_DATA2 LVDS1_DATA#3 30 LVDS1_DATA#2 LVDS1_CLK LVDS0_CLK LVDS1_CLK# LVDS0_CLK# +12V +12V Pitch: 1.25mm...

  • Page 39: Chapter 2

    Chapter 2 This chapter tells how to change the system settings through the BIOS Setup menus. You may need to run the Setup program when: An error message appears on the screen during the system booting up, and requests you to run SETUP. You want to change the default settings for customized features.

  • Page 40: Bios Setup Program

    2.1 BIOS setup program This chapter provides a description of the AMI BIOS. The BIOS setup menus and available selections may vary from those of your product. AMI's ROM BIOS provides a built-in Setup program, which allows the user to modify the basic system configuration and hardware parameters.

  • Page 41: The Menu Bar

    & E x i t M a i n BIOS Information Set the Date. Use Tab to switch Version MX57QM (71301) BIOS V1.00 between Data elem ents. Build Date 12/24/2010 Use [+] or [-] to CPU Information configure system Time.
  • Page 42 Control Keys Move to the previous item <↑> Move to the next item <↓> Move to the item in the left hand <←> Move to the item in the right hand <→> <Enter Select the item > Jumps to the Exit menu or returns to the <Esc>...

  • Page 43: Main Setup

    & E x i t M a i n BIOS Information Set the Date. Use Tab to switch Version MX57QM (71301) BIOS V1.00 between Data elem ents. Build Date 12/24/2010 Use [+] or [-] to CPU Information configure system Time.

  • Page 44: Advanced Bios Setup

    2.5 Advanced BIOS Setup Advanced Menu BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d Onboard LAN 1 Controller [Enabled] Onboard LAN 2 Controller...
  • Page 45 Advanced Menu – CPU Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d CPU Configuration Enabled for Windows XP and Intel®...
  • Page 46 Advanced Menu – Display Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d IGD Memory [32M] IGD Share Memory Size...
  • Page 47 Advanced Menu – Power Management Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d ACPI Sleep State [S3 (suspend to R…] Select the highest ACPI sleep...
  • Page 48 Advanced Menu – North Bridge BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d Memory Information Low MMIO resources align at CPU Type...
  • Page 49 Advanced Menu – South Bridge BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d SB Chipset Configuration SMBus Controller help.
  • Page 50 Advanced Menu – SATA Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d SATA Configuration SATA Port1 Not Present...
  • Page 51 Advanced Menu – Intel TXT (LT) Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d Intel Trusted Execution Technology Configuration SMX Feature Support: [Disabled]...
  • Page 52 Advanced Menu – Super IO Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d Super IO Configuration Set Parameters of Serial Port 1 (COMA)
  • Page 53 Advanced Menu – Super IO Configuration – Serial Port 2 Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d Serial Port 2 Configuration Enable or Disable Serial Port (COM)
  • Page 54 Device Mode Options: Standard Serial Port Mode, IrDA 1.0 (HP SIR) Mode Advanced Menu – Super IO Configuration – Serial Port 4 Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e &...
  • Page 55 Advanced Menu – Super IO Configuration – Serial Port 5 Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d Serial Port 5 Configuration Enable or Disable Serial Port (COM)
  • Page 56 Advanced Menu – Super IO Configuration – Serial Port 6 Configuration BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d Serial Port 6 Configuration Enable or Disable Serial Port (COM)
  • Page 57 Advanced Menu – H/W Monitor BIOS SETUP UTILITY M a i n B o o t S e c u r i t y S a v e & E x i t A d v a n c e d PC Health Status CPU Warning Temperature [Disabled]...

  • Page 58: Boot Setting Configuration

    2.6 Boot Setting Configuration Boot Menu BIOS SETUP UTILITY M a i n A d v a n c e d S e c u r i t y S a v e & E x i t B o o t Boot Configuration Enables/Disables Quiet Boot Quiet Boot...

  • Page 59: Security Setup

    2.7 Security Setup Security Menu BIOS SETUP UTILITY M a i n A d v a n c e d B o o t S a v e & E x i t S e c u r i t y Password Description Set Setup Administrator Password...

  • Page 60: Exit Menu

    2.8 Exit Menu Save & Exit Menu BIOS SETUP UTILITY M a i n A d v a n c e d B o o t S e c u r i t y S a v e & E x i t Save Changes and Exit Exit system setup after saving Discard Changes and Exit...

  • Page 61: Appendix A Dio (Digital I/O) Sample Code

    Appendix A DIO (Digital I/O) Sample Code //============================================ //MX57QM DOS DIO sample program //Please compile with Turbo C 3.0 to utilized the program //============================================ Int main() Int RetVal; /////////// Write Digital Output /////////// // Set all output to 0 RetVal = inp(0x549);...
  • Page 62 // DO6 is bit0 RetVal = inp(0x539); RetVal = RetVal | 0x10; Outp(0x539,RetVal); // DO7 is bit4 /////////// Read Digital Input /////////// RetVal = inp(0xA00); // DI[7:0] is bit[7:0]...

  • Page 63: Appendix B Watchdog Timer Sample Code

    Appendix B WatchDog Timer Sample Code //============================================ //MX57QM DOS Watchdog sample program //Please compile with Turbo C 3.0 to utilized the program //============================================ #include <stdio.h> #include <stdlib.h> #define SMBus_Port 0x00000400 //"AMI BIOS" PCI-SMBus init address for INTEL ICH CHIPSET #define SMBus_ADDR 0x9c...
  • Page 64 delay(25); outp(SMBus_Port,status); status=inp(SMBus_Port); int WaitReady(int base) int STATUS; STATUS=inp(base); }while((STATUS&0x01)!=0); return 1; int SMBUS_Read_Byte(int offset,int DEVID) int RetVal=0; outp(SMBus_Port,0x0fe); outp(SMBus_Port+0x04,DEVID+1); outp(SMBus_Port+0x03,offset+0); outp(SMBus_Port+0x02,0x48); delay(200); if(WaitReady(SMBus_Port)) RetVal=inp(SMBus_Port+0x05); return (int)RetVal; /* =============== This Routine is Write the Device Reg Value =============== */ void SMBUS_Write_Byte(int Dev_id,int Reg_index,int Value) outp(SMBus_Port+0x04,Dev_id);...
  • Page 65 //function WDT //This function is use to set WDT //num is the reset time in sec(max 127 sec) int WDT(int time) int current; printf("SMBUS enable WDT/n"); current=SMBUS_Read_Byte(WDT_Enable_Reg,SMBus_ADDR); current=(current|0x20); SMBUS_Write_Byte(SMBus_ADDR,WDT_Enable_Reg,current); printf("SMBUS Set timer and enable countdown for WDT/n"); current=SMBUS_Read_Byte(WDT_Time,SMBus_ADDR); time=(time|0x80); SMBUS_Write_Byte(SMBus_ADDR,WDT_Time,time); printf("SMBUS WDT will reset in 10 Sec\n");...
