EN
4. Tool Overview
Blade screw
A
B
Blade
C
Cutting edge
Sole
D
Base
E
Grip (on both sides)
F
G
Blade adjustment wheels
H
Blade adjustment slots
Lever cap
I
Clamping screw
J
5. Assembly/Disassembly
NOTICE
To disassemble the tool, follow the steps below in a
reverse order�
1� Place the blade (B) onto the base (E)� The flat surface of the
blade has to face upwards� The adjustment slots (H) of the
blade must fit around the rings of the adjustment wheels (G)�
6
A
B
C
D
E
F
J
I
H
G
