ROCKY RV11 Quick Guide
A. LCD Panel Opened
1. Embedded Antennas (Optional):
GPS, WWAN, WiFi/Bluetooth x 2
2. Embedded Mic
3. LED Indicators
(Please see "F" for details.)
4. Power Button
5. Touchpad
6. Touchpad Right and Left Button
B. Bottom View
1. Multi Bay Port
2. Battery Pack
C. Right View
1. 2.5" SATA III 7mm SSD
D. Left View
1. 1. GLAN RJ45
2. USB 3.0 x 1
3. USB 3.0 x 1 with Fast Charger
4. SD Card Slot x 1 + SIM Card Slot x 1
