Robolink CoDrone Pro Quick Start Manual

Install - USB Driver
Step 1. Connect the BLE board to PC
Connect BLE board to PC with a Micro USB Cable(5-pin).
Press the button on BLE board to change the color of LED
to red.
※ Yellow : Upload mode / Red : Bluetooth(communication) mode
Step 2. Download CoDrone's USB Helper Drive
Go to Software Download ▶ VCP Drivers page in silabs.com,
then download proper file for your operating system
Download USB Helper Download at the bottom of Products
menu in download page. (
Run USBHelper_vX.exe, select the port you connected the
board, and click CP210X Driver Setup.
Download Software
Drone Simulator
Download Drone Simulator on your PC.
Download the program from [CoDrone]▶Drone Simulator
in robolinksw.com.
Step 3. Pairing
▶ Change LED light of BLE Board into
(Please refer Step 2.)
Extract Drone Simulator's zip file to run the program.
Press the Connect button at the top of the screen to connect
CoDrone.
Insert the battery Searching for signal (blinking)
For information related with Rokit Brick, Arduino, and Mobile application, go to robolinkSW.com.
for
robolink.co.kr/download_eng.html )
"X" is version information.
Red
Connected (solid)
Components - CoDrone Pro
・ CoDrone ・ Joystick modules
・ Smart Inventor Board ・ Extra propellers
・ Bluetooth Module (BLE) ・ 4-pin cable
・ Micro USB cable ・ 3-pin cable
Components - CoDrone Pro Lite
・ CoDrone
・ Bluetooth Module (BLE)
・ Battery
・ Battery Charger
・ Micro USB cable
・ Extra propellers
・ Propeller Replacement tool
・ Quick Start Guide
Step 4. Control CoDrone
Drone Simulator
Up Forward
Turn Down Turn
Left Backward Right
left Right
Move up / down Move Forward /
Turn left / right Backward / Left / Right
Take off : Press W
key !
Software
Through Smart Inventor
Board, You can program
SMART
with joystick, analog
INVENTOR BOARD
sensors, and digital
sensors.
What do I need?
You can do not only the
flight practice through si-
PC SOFTWARE
mulation but also control
real drone, record the fli-
ght pattern, trim, and so
on with Drone Simulator
on PC .
What do I need?
Check with the video
CoDrone page
http://robolink.co.kr
/sw_eng/codrone/
01_codrone.html
・ Battery case ・ Propeller Replacement tool
・ Battery charger ・ Feet (Blue board)
・ Battery ・ Screwdriver
Handfuls of Bolts, Nuts, ・ Quick Start Guide
and Supporting beams
Warning!
Remember how to Once : Landing
initiate an emergency
Twice : Emergency
stop before flight! Stop
Rokit BRICK is based on the
way of Scratch's Drag & drop
LEARN TO
so that beginners can use it
CODE
easily.
What do I need?
Use your smartphone app-
lication to control the drone,
MOBILE APP drive kit, and camera kit.
(FPV : First-person view)
What do I need?
for
Download (eng)
http://robolink.co.kr
/download_eng.html
