UK Tents 5m Series Quick Start Manual

Advertisement

Quick Links

5m - series
ECONOMY Prime
Party Tent
Please read instructions COMPLETELY before assembly. This tent MUST be securely anchored.
This tent is a temporary structure and should be disassembled at harsh weather conditions as stormy

Warnings

Prior to installation, consult with all local municipal codes regarding installation of temporary shelters. The
owner of the tent has the sole responsibility to make sure that these local rules are followed and that the
mounting is correct.
We are not responsible for damage to the unit or the contents from acts of nature.
It is always recommended that you secure your tent properly with storm straps and ground pegs when you
put up the structure. Proper Anchoring system selection is your responsibility. Heavy duty Anchor are sold
separately and are not included in this product.
Periodically check the anchors to ensure stability of shelter.
In case of extreme weather conditions, the tent cover must be removed.
Any shelter that is not anchored securely has the potential to fly away causing damage. We are not
responsible for any shelter that blows away.
This canopy is intended to protect against the effects of sun, rain, light snow, etc. It is not designed to hold
the loads that can accompany wind, rain, snow or ice storms. This structure is not tested for specific snow,
rain and wind loads.
Do not use open fire, welding equipment or other ignition sources in the tent.

Cleaning and Storage

A tight cover ensures longer life and performance. Always maintain a tight cover. Loose fabric can
accelerate deterioration of cover fabric.
Immediately remove any accumulated water, snow or ice from the roof structure.
DO NOT use bleach or harsh abrasive products to clean the fabric cover. Cover is easily cleaned with mild
soap and water.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5m Series and is the answer not in the manual?

Questions and answers

Summary of Contents for UK Tents 5m Series

  • Page 1 5m - series ECONOMY Prime Party Tent Please read instructions COMPLETELY before assembly. This tent MUST be securely anchored. This tent is a temporary structure and should be disassembled at harsh weather conditions as stormy Warnings Prior to installation, consult with all local municipal codes regarding installation of temporary shelters. The owner of the tent has the sole responsibility to make sure that these local rules are followed and that the mounting is correct.
  • Page 2 5m - series ECONOMY Prime Safety Instructions Please use gloves and stable shoes when assembling the metal frame portion of this unit. The metal components may have sharp edges and be oily cause of the metal processing. Snow must be removed from the tarpaulin in a timely manner. Temporary accommodation as tents should be taken down in adverse weather condition like heavy wind, snowfall and ice.
  • Page 3 5m - series ECONOMY Prime Step2. Lift one side of the tent frame and attach the legs (3). Place the roof (18) onto the frame and use the bungees (13) to fasten it. Be sure not to put too much tension on the bungees in order not to make attaching the other side more difficult.
  • Page 4 5m - series ECONOMY Prime Step3. Attach the legs on the other side. Make sure, that the leg pipes are in vertical position, to avoid overtention on another side. Use the big ground pegs (11) to fasten the legs to the ground. Attach the side covers to the pipes (3) using hooks (17).
  • Page 5 5m - series ECONOMY Prime Step 4.Unfold the side walls (19) and the end walls (20) and attach the side walls to the frame using the bungees (13). Attach the end walls directly to the roof using the short bungees (14). Use the small ground pegs (12) to fasten the end walls to the ground.
  • Page 6 5m - series ECONOMY Prime Parts List Quantity Name Drawing 5x4m 5x6m 5x8m 5x10m 5x12m Rafter Poles 510mm Cross Poles 1930mm Leg pole 1898mm Connecting Pole 200mm 3-way-corner 110° ( Leg connector) 4-way-corner 110°( Leg connector) 3-way-corner 140° ( roof connectors) 4-way-corner 140°( roof connectors) Bolt with wing nut...
  • Page 7 5m - series ECONOMY Prime Guy rope 3m Spanner Hook Roof Side wall End wall...
