- Page 1 V-ZUG-Home Install the app, network your appliances and benefit from a wide range of useful functions. Operating instructions CombairSteamer V2000 Steamer...
- Page 2 CombairSteamer V2000 76 CS2T-23040 60-762 CombairSteamer V2000 7UC CS2T-23056 55-762 CombairSteamer V2000 7U CS2T-23059 60-762 CombairSteamer V2000 6U CS2T-23098 60-600 CombairSteamer V2000 6UC CS2T-23100 55-600 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6302 Zug, 2021...
-
Page 3: Table Of Contents
Wellness .............. 42 Preheating ............. 22 5.20 Hygiene.............. 43 4.10 Setting to start later .......... 23 5.21 Recipe book ............ 43 4.11 Application tips............. 23 V-ZUG-Home 45 4.12 Favourites.............. 24 Conditions .............. 45 4.13 Pinning .............. 25 Initial set-up............ 45 4.14 Timer .............. 26 User settings 46... - Page 4 V-ZUG Home ............ 48 7.10 Appliance information ......... 49 7.11 Factory settings............ 49 7.12 EcoManagement.......... 49 7.13 Customer Services .......... 50 Care and maintenance 50 Cleaning the exterior........... 50 Cleaning the cooking space...... 50 Cleaning the baking tray ........ 50 Steam cleaning ............ 51 Cleaning the appliance door ...... 51 Cleaning the door seal ........ 53...
-
Page 5: Safety Precautions
Safety precautions Symbols used Cleaning and user mainten- ance shall not be undertaken Denotes important safety precau- tions. by children without supervi- Failure to observe said precautions sion. can result in injury or in damage to ▪ If an appliance is not the appliance or fittings! equipped with a mains cable Information and precautions that... -
Page 6: Instructions For Use
1 Safety precautions to touch the heating ele- disconnected from the mains ments. Children under 8 power supply to avoid pos- years of age must be kept sible electric shock. away from the appliance un- ▪ To avoid overheating, the ap- less they are constantly su- pliance must not be installed pervised. - Page 7 1 Safety precautions ▪ Never use the appliance to dry animals, ▪ Objects that could pose a danger if the textiles, paper, etc.! appliance were accidentally switched ▪ Do not use the appliance as a room on should not be stored in the cooking heater.
- Page 8 1 Safety precautions Caution: Risk of injury! ▪ Be careful not to put fingers in the door hinges as there is otherwise a risk of in- jury if the appliance door is moved. Par- ticular care should be taken when chil- dren are around.
-
Page 9: Using For The First Time
Using for the first time Before operating the newly installed appliance for the first time, the following steps should be taken: ▸ Remove packaging and transport materials as well as any protective blue film from out of the cooking space. ▸... -
Page 10: Appliance Description
3 Appliance description Appliance description Construction Operating and display elements Ventilation opening Door handle Appliance door Heatable appliance drawer (depending on model) Operating and display elements App view List view Favourite for bread Here is where you can make User settings all key settings and customize your appliance. - Page 11 Heatable appliance drawer (depending on model) List view Cooking space illumination App view Open water compartment flap Switch off Display lock Quiet mode Clock V-ZUG-Home Ready to start Steam 15min 13:21 Start Application Start operation Main value Setting options Options...
-
Page 12: Cooking Space
3 Appliance description Cooking space Using protective inserts or aluminium foil can damage the appliance. Do not place any protective insert or aluminium foil on the floor of the cooking space. Appliance door Water tank compartment Door seal Temperature sensor Cooking space illumination Grill / top heat Knurled nut... - Page 13 3 Appliance description ▪ Baking tin e.g. for flans, bread and biscuits ▪ Use together with the wire shelf as a drip tray. ▪ If not fully covered by the baking, its shape can become distorted during baking. This is normal. As it cools down, it will go back to its original form.
-
Page 14: Heatable Appliance Drawer (Depending On Model)
3 Appliance description ▸ Ensure that the «sloped» side 1 of the cooking tray is to the back of the cooking space. ▪ Not suitable for use with the applications. Wire shelf ▪ For standing roasting and baking tins on. ▪ For standing meat, frozen pizza, etc. on. ▸... -
Page 15: Operation
4 Operation Operation Operating the display Switching the appliance on The appliance is operated using the display. The clock is only visible in EcoStandby if enabled in the user settings. ▸ Long touch the display. – The start screen appears. Changing the start screen view The start screen can be displayed in one of two ways: as an app view (see page 10) or as a list view. -
Page 16: Filling The Water Tank
4 Operation Expanding the right function bar The right function bar can be expanded at any time. ▸ Drag the bar 3 to the left. – The function bar expands. – More functions appear in the display. Using the CircleSlider ▸... -
Page 17: Selecting And Starting An Application
4 Operation Selecting and starting an application ▸ Long touch the display. – The start screen appears. Selecting an application group Either: ▸ In the app view, touch the desired application group. – The submenu with the associated applications appears in the display. ▸... -
Page 18: Changing An Application
4 Operation Adjusting vales ▸ If necessary, adjust the main value 1 using the CircleSlider (see page 21). ▸ If necessary, touch and define, adjust or activate the values of other options (see page 21). Saving values ▸ Permanently save and pin the adjusted main value 1 for the selected application, if re- quired (see page 25). - Page 19 4 Operation – If preheating is selected or preset, the end time is the approximate preheating time plus the set duration. The operating time set only starts to run when preheating has finished. ▸ Press «Start» to start the application. –...
-
Page 20: Delayed Start / End
4 Operation Delayed start / end The delayed start is activated when for the application selected both the operating time and end are set. The appliance switches automatically on and off again at the desired times. No delayed start can be set for Sabbath applications Setting a delayed start ▸... -
Page 21: Options
4 Operation Options Overview Each application offers different options. Your appliance has the following options: Preheat (see page 22) Steaming (see page 36) Start later (see page 23) Selecting and starting options ▸ Select an application from the desired application group and confirm with «OK», if re- quired (see page 17). -
Page 22: Preheating
4 Operation Preheating If the «Preheat» option has been turned on, do not put the food into the cooking space until the acoustic signal is emitted and the corresponding message ap- pears. With «Preheat», the cooking space is quickly heated up to the desired temperature. Overview Preheating is only possible for the following applications: Top/bottom heat... -
Page 23: Setting To Start Later
4 Operation 4.10 Setting to start later With «Start later», an application and its settings can be predefined and set to start at a later time. The application does not start automatically, but instead only through the in- teraction of the user. The appliance remains ready to start and does not switch back to EcoStandby. -
Page 24: Favourites
4 Operation 4.12 Favourites Creating a favourite Favourites can be created from all applications, with the exception of the cleaning pro- grammes. And all options, with the exception of «End», can be saved. Up to 50 favour- ites in total can be created. ▸... -
Page 25: Pinning
4 Operation Deleting favourites The favourite can only be deleted in the app view. ▸ If required, touch – The start screen appears as an app view. ▸ Press and hold the favourite 1. – Quick information appears above the app. ▸... -
Page 26: Timer
4 Operation 4.14 Timer The timer functions like an egg timer. It can be used independently of other functions and applications. Setting and starting the timer ▸ Touch the «Timer» function button in the right function bar. – The timer is shown in the display. –... -
Page 27: Illumination
4 Operation 4.15 Illumination The cooking space illumination can be switched on and off at any time. The cooking space illumination switches on automatically 3 minutes before the set duration is up. If the cooking space illumination is turned either on or off when a Sabbath applica- tion is started it will remain unchanged until the end of operation. -
Page 28: Time
4 Operation Turning off the quiet mode ▸ Expand the function bar. ▸ Touch the «Quiet mode» function button. – The quiet mode is shown in the display. ▸ Touch the «Quiet mode» switch. – «Quiet mode» is turned off. –... -
Page 29: End Of Operation
4 Operation If the application has been running for less than 1 minute when cancelled, the ready to start screen appears. Sabbath applications can only be cancelled using the function button (see page 36). Ending an application before time ▸ Press and hold the function button. -
Page 30: Subsequent Steps
4 Operation 4.21 Subsequent steps Subsequent steps are applications that can be used to continue operation after an ap- plication has ended or been cancelled. They are used, for example, to brown food off. The selection of subsequent steps available depends on the application that has just ended or been cancelled. -
Page 31: Emptying The Water Tank
4 Operation ▸ Hold the function button depressed. – Any running application is ended; if switched on, the timer will remain active. – If turned on, the display lock is deactivated. – The display goes dark. – The appliance is in EcoStandby. Display after switching off Depending on the application and settings, the following is shown in the darkened dis- play. -
Page 32: Applications
5 Applications Applications Top/Bottom heat Temperature range 30–230 °C Recommended value 200 °C Level The cooking space is heated by the top and bottom heating elements. Uses ▪ Classic application for cooking and baking on one level ▪ Cakes, biscuits, bread and roasts For crispy results, use a dark enamelled tray. -
Page 33: Bottom Heat
5 Applications Uses ▪ Roasts, gratins, savouries and biscuits When baking using this application, do not preheat. This lowers the energy con- sumption. The cooking time can be longer than with classical top/bottom heat. For crispy results, use a dark enamelled tray. Bottom heat Temperature range 4 levels... -
Page 34: Grill-Forced Convection
5 Applications Application ▪ Flat food for grilling, e.g. chicken parts and sausages ▪ Gratinate ▪ Toast ▸ Place the food to be grilled directly on the wire shelf. ▸ Line the baking tray with aluminium foil and then place it underneath the wire shelf. For best results, preheat the cooking space for 3 minutes using the option be- fore introducing the food. -
Page 35: Hot Air Humid
5 Applications Hot air humid Temperature range 30–230 °C Recommended value 180 °C Level 2 or 1 + 3 A heating element behind the back wall of the cooking space heats up the air inside the cooking space, which is circulated evenly. The natural humidity produced is largely re- tained in the cooking space. -
Page 36: Hot Air With Steaming
5 Applications 5.11 Hot air with steaming Temperature range 80–230 °C Recommended value 180 °C Level 2 or 1 + 3 The cooking space is heated by hot air. Bursts of steam ensure that the energy is trans- ferred more efficiently to the food. This speeds up the cooking process slightly and the food comes out really crispy. - Page 37 ▪ Do not leave food in the appliance for too long before use. The timer and heatable appliance drawer cannot be operated at the same time. They are turned off when the application is started. V-ZUG-Home is not available during operation.
-
Page 38: Steam
5 Applications Sabbath top/bottom heat Temperature range 30–140 °C Recommended value 85 °C Level The cooking space is heated by the top and bottom heating elements. Uses ▪ For heating up or keeping pre-cooked, crispy food and bakery goods warm on one level ▪... -
Page 39: Regeneration
5 Applications Uses ▪ Steaming vegetables, rice, cereal products, pulses and egg dishes ▪ Poaching meat, poultry and fish ▪ Extracting juice from fruit and berries ▪ Making yogurt ▪ Preserving, bottling Possible to steam on several levels simultaneously. ▸ Put the stainless steel tray under the perforated cooking tray to make cleaning the cooking space easier. -
Page 40: Vacuisine
5 Applications Classical «Professional baking classical» is based on a process that gives pastries, e.g. puff pastries, a shiny finish, without the need for an egg or other wash. It starts with a cold ap- pliance and a steam phase. This is followed by a hot air phase. The appliance door must not be opened during the steam phase. -
Page 41: Keep Warm
5 Applications Temperature range 30–95 °C Recommended value 60 °C Level 1 to 4 Recommended maximum cooking 72 hours time The cooking space is heated simultaneously by steam and hot air. The food is heated or cooked by steam. Tips for best results ▪... -
Page 42: Warming Plates In The Cooking Space
5 Applications 5.18 Warming plates in the cooking space If the cooking space is already hot, open the appliance door and allow the cooking space to cool down for 3 to 4 minutes before starting the «Plate warmer» function. This is to protect the tableware from damage through stress cracking. ▸... -
Page 43: Hygiene
5 Applications 5.20 Hygiene «Hygiene» can be used for sterilizing containers. The following applications are avail- able: Sterilizing baby bottles Final sterilization of jam jars Sterilizing preserving jars Sterilizing baby bottles This application replaces the need to boil feeding bottles in water. Before starting the application: ▸... - Page 44 5 Applications ▸ To view the individual recipe steps, open the overview of the steps in the left content pane of the display. Select «1. Step». The overview of the steps opens and information on each step such as the application, temperature and operating time can be viewed. The action information contains instructions on what actions need to be taken.
-
Page 45: Zug-Home
– A 6-digit PIN appears in the display of the appliance. ▸ Enter the 6-digit PIN in the V-ZUG App and confirm the bluetooth pairing request. – The name of the active WLAN/Wi-Fi appears in the V-ZUG App and then you are prompted to enter the WLAN/Wi-Fi password. -
Page 46: User Settings
7 User settings User settings Adjusting user settings ▸ Long touch the display. – The start screen appears. ▸ Select «User settings» and confirm with «OK», if required (see page 17). ▸ Select the desired user setting. – The main menu for the desired user setting or another submenu with more user settings appears in the display. -
Page 47: Individual Settings
7 User settings Sound worlds The tonality of the acoustic signals and feedback tones can be changed. Feedback tones The volume of the feedback tones can be adjusted up or down or turned off completely. Certain feedback tones are not muted for legal and safety reasons. A short feedback tone is emitted when the appliance is switched off even if the set- ting is set to «Off»... -
Page 48: Date And Time
If set to «On», a short preheat tone is emitted when it is time to put the food into the cooking space. Date and time Time synchronization The «Internet» setting is set automatically when connecting to V-ZUG-Home. The time, date and time zone are then synchronized directly from the app. Date The date can be called up and changed. - Page 49 7 User settings Resetting Disconnects all connections to mobile devices. Further information about V-ZUG-Home and availability can be found at home.vzug.com or in the Operating instructions for V-ZUG-Home. 7.10 Appliance information Identification numbers The serial number (SN) and article number are displayed.
- Page 50 8 Care and maintenance 7.13 Customer Services This part of the menu is intended for service staff and is password-protected. Care and maintenance Risk of burns from hot surfaces! Allow the appliance and the accessories to cool down before cleaning. Incorrect handling can result in damage to the appliance! Use soft cloths only.
- Page 51 8 Care and maintenance Steam cleaning The appliance must have cooled down before starting. Remove accessories, cookware or other objects from the cooking space, leaving the shelf guides. Stay close to the appliance: The cooking space needs to be wiped during the cleaning process. How it functions The cleaning programme «Steam cleaning»...
- Page 52 8 Care and maintenance ▸ Open the appliance door as far as it will go. ▸ Fold the clips 2 on both door hinges 1 forward. ▸ Close the appliance door as far as its airing position (about 30°). ▸ Lift the appliance door out evenly and at an angle.
- Page 53 8 Care and maintenance ▸ Reassemble the glass panels as follows: Insert the middle door glass 3 into the door frame and gently push it back towards the hinges. – The markings on the glass must be legible. ▸ Reinstall the intermediate door glass seal 2. ▸...
- Page 54 8 Care and maintenance Removing the shelf guides ▸ Unscrew the knurled nuts 1 in the front and back of the shelf guides in an anti-clockwise direction. ▸ Pull the shelf guides 2 to the side of the screws and remove. Reassembling the shelf guides ▸...
- Page 55 8 Care and maintenance See «Accessories and spare parts» for where to obtain this descaler. «durgol swiss steamer» was developed especially for this appliance. Standard descaling solutions are not suitable as they may contain foam- creating additives or not be effective enough. Using a different descaler could cause ▪...
- Page 56 9 Trouble-shooting Ending the descaling process ▸ As soon as the corresponding message appears: Remove, empty and dry the water tank. ▸ Confirm the message with «OK». – The following appears in the display: «Appliance was descaled successfully.» ▸ Confirm the message with «OK». –...
- Page 57 9 Trouble-shooting Message Possible cause Solution ▪ «Residual heat ▪ The temperature of ▸ Wait for it to cool down (this can take – Do not re- the water in the boiler up to 30 minutes). move the water is too high. For safety reasons, the water is not tank.»...
- Page 58 9 Trouble-shooting Problem Possible cause Solution ▪ Steam is not ▪ The temperature of No solution required: Steam over visible during the cooking space is 100° C is not visible. steam cycle over 100 °C. ▪ Water in door- ▪ When using applica- The door-mounted condensate trough is mounted con- tions with steam,...
- Page 59 10 Accessories and spare parts After a power failure The user settings remain unchanged. Brief power failure during operation – The current operation of the appliance is cancelled. – The following appears in the display when the appliance is switched on: «Process was cancelled due to a power failure».
- Page 60 11 Technical data 10.3 Spare parts Shelf guides, left/right Knurled nut durgol swiss steamer descaler Lid for water tank Water tank The descaler is also available from specialist retailers. Technical data External dimensions ▸ See installation instructions Electrical connection ▸ See identification plate 1 11.1 Note for testing institutes Placing thermocouples between the appliance door and the seal can cause lack of leak-...
- Page 61 11 Technical data 11.3 Product fiche In accordance with EU Regulation No.: 66/2014 Brand – V-ZUG Ltd Type of appliance – Steam cookers Model designation – CS2T Model number 23035, 23036, 23039, 23040, 23056, 23059 Mass of appliance without appliance drawer...
- Page 62 12 Tips and tricks Tips and tricks 12.1 Unsatisfactory cooking result... … for baking and roasting Result Solution ▪ The baking or roast ▸ Next time, set a lower temperature and lengthen the operat- looks good on the ing time. outside but is still doughy or raw on the inside.
- Page 63 13 Disposal 12.2 General tips ▪ A variety of food can be cooked at the same time, e.g. rice or pulses together with ve- getables that have similar cooking times, saving energy. ▪ Cook grains (e.g. rice and millet) and pulses (e.g. lentils), adding an appropriate amount of liquid, directly in suitable tableware.
- Page 64 Index Accessories ..........12, 59 Date ..............48 Cleaning ............ 53 Date and time ........... 48 App view ............10 Date and time format ........48 Appliance disposal .......... 63 Delayed start............. 20 Appliance door Demo mode ............49 Descaler............. 54 Cleaning ............
- Page 65 14 Index Hot massage stones ........42 Action required.......... 44 Hot wraps ............42 Cancelling ............. 45 Hygiene.............. 43 Starting............ 43 Refilling the water tank ........16 Refreshing towels ..........42 Regeneration ..........39, 62 Identification numbers........49 Resetting............49 Identification plate..........
- Page 66 Vacuisine ............41 Validity..............2 Version numbers..........49 Volume Acoustic signals........... 47 Feedback tones ........... 47 V-ZUG App ............45 V-ZUG-Home..........48, 49 Warming plates in the cooking space ..42 Water compartment flap ......... 47 Water hardness ..........47 Water tank Emptying............
- Page 67 Your repair order Call the free service number 0800 850 850 to contact your nearest V-ZUG service centre. You can arrange an on-site visit by us by phone if you wish. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our pro- gressive service agreements.
- Page 68 Page change Adjustable value Favourite Temperature The temperature can be set using the CircleSlider. 1063318-04 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug Tel. +41 58 767 67 67, Fax +41 58 767 61 61 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
