Page 1: Operating Instructions
Operating instructions Combi-Steam XSL Combi-steam cooker... - Page 2 Product family Size system CSTXSLZ60 23005 60-450 CSTXSLZ60c 23005 60-450 CSTXSLZ60Y 23006 60-450 Variations depending on the model are noted in the text. Colour operating instructions can be downloaded from the internet from www.vzug.com. © V-ZUG Ltd, CH-6302 Zug, 2018...
-
Page 3: Table Of Contents
Table of contents BakeOmatic ............ 28 Safety precautions 5 Professional baking.......... 29 Symbols used............ 5 Soft roasting............ 30 General safety precautions........ 5 RegenerateOmatic.......... 32 Appliance-specific safety precautions .... 6 Wellness * .............. 33 Instructions for use.......... 7 Hygiene *.............. - Page 4 10.17 Factory settings............ 42 Care and maintenance 42 11.1 Cleaning the exterior........... 43 11.2 Cleaning the cooking space...... 43 11.3 Cleaning the appliance door ...... 43 11.4 Cleaning the door seal ........ 44 11.5 Replacing the door seal ........ 44 11.6 Replacing the halogen light bulb ..... 44 11.7 Cleaning the accessories and shelf guides ... 44 11.8...
-
Page 5: Safety Precautions
Safety precautions Symbols used General safety precautions Denotes important safety precau- tions. Failure to observe said precautions ▪ Read the operating instruc- can result in injury or in damage to tions before using the appli- the appliance or fittings! ance for the first time! Information and precautions that should be observed. -
Page 6: Appliance-Specific Safety Precautions
1 Safety precautions ently installed electrical install- lishments; by guests in hotels, ation in accordance with the motels and other accommod- installation regulations. ation establishments; in bed ▪ If the mains cable of this ap- and breakfast establishments. pliance is damaged, it must ▪... -
Page 7: Instructions For Use
1 Safety precautions ▪ Any repairs, modifications or manipula- rooms where there are spe- tions to the appliance, especially any cial conditions such as, for in- electrically live parts, may only be car- stance, a corrosive or explos- ried out by the manufacturer, its Cus- tomer Services or a similarly qualified ive atmosphere (dust, steam person. - Page 8 1 Safety precautions Caution: Risk of burns! Caution: Risk to life! ▪ The appliance gets very hot when in ▪ Danger of suffocation! Keep packaging use. The appliance door also gets hot. material, e.g. plastic film and poly- ▪ Steam and/or hot air may escape from styrene, away from children.
-
Page 9: Using For The First Time
Using for the first time Before operating the newly installed appliance for the first time, the following steps should be taken: ▸ Remove packaging and transport materials as well as any protective blue film from out of the cooking space. ▸... -
Page 10: Appliance Description
3 Appliance description Appliance description Construction Operating and display elements Ventilation opening Door handle Appliance door Operating and display elements 12:00 Display Action buttons Digital display Adjusting knob / switching on (duration/timer/time) appliance Menu buttons Overview of touch buttons Operating modes GourmetGuide EasyCook User settings... -
Page 11: Cooking Space
3 Appliance description Cooking space Using protective inserts or aluminium foil can damage the appliance. Do not place any protective insert or aluminium foil on the floor of the cooking space. Appliance door Water tank compartment Door seal Temperature sensor Knurled nut Steam inlet Cooking space illumination... - Page 12 3 Appliance description ▸ Only use the normal way round – not upside down. Stainless steel tray ▪ Use together with the wire shelf or perforated cooking tray as a drip tray. ▪ Baking tin e.g. for aperitif nibbles and biscuits ▪...
-
Page 13: Operating Modes
4 Operating modes Operating modes Overview of operating modes All the operating modes are described below. Follow the advice given in «Tips and tricks» (see page 37) and in «EasyCook». Steam Temperature range 30–100 °C Recommended value 100 °C Level 1 to 4 The cooking space is heated simultaneously by steam and hot air. -
Page 14: Regeneration
4 Operating modes A heating element behind the back wall of the cooking space heats up the air inside the cooking space, which is circulated evenly. With condensing steam, the energy is trans- ferred more efficiently to the food than when cooking with hot air, which accelerates the cooking process. -
Page 15: Using The Appliance
5 Using the appliance Uses ▪ Roasting, braising Using the appliance The different main menus and functions are selected by pressing the corresponding touch button. Selected touch buttons and functions are illuminated in white; other select- able functions are illuminated in orange. Settings and functions that cannot be selected or changed are greyed out in the various menus. -
Page 16: Selecting And Starting The Operating Mode
5 Using the appliance Selecting and starting the operating mode ▸ If the appliance is switched off: first press the adjusting knob. ▸ If the appliance is in another menu: press the touch button. – The selection of operating modes appears in the display. ▸... -
Page 17: Setting A Duration
5 Using the appliance Setting a duration The operating mode selected ends automatically when the operating time is up. ▸ Select the desired operating mode. ▸ Select in the operating mode settings. ▸ Set the desired duration – max. 9 hours and 59 minutes – and confirm. –... -
Page 18: Food Probe Temperature
5 Using the appliance Food probe temperature Only use the supplied food probe. Do not clean the food probe in the dishwasher. Always keep the plug clean. The food probe is used to measure the temperature inside the food (referred to as the food probe temperature). -
Page 19: Changing The Operating Mode
5 Using the appliance – The following appears in the display: « Residual heat» and, for example: « air cancelled». – If the food probe is plugged in, the food probe temperature is displayed. * * Depending on the software version ▸... -
Page 20: End Of Operation
5 Using the appliance When the timer finishes When the set duration is up: – An acoustic signal is emitted. – «Timer finished» appears in the display. ▸ To close the message, select Switching the timer off before time ▸ Press the touch button. -
Page 21: Switching The Appliance Off
5 Using the appliance Removing food from cooking space Risk of scalding! Hot steam or hot air may escape from the cooking space when the appliance door is opened. The accessories get hot. Use protective gloves or oven cloths. ▸ Take the food out of the cooking space when done. ▸... -
Page 22: Emptying The Water Tank
6 GourmetGuide 5.12 Emptying the water tank Risk of scalding! The water in the tank may be hot. If «Please do not remove the water tank» ap- pears in the display, the temperature of the residual water is too high. Do not re- move the water tank! For safety reasons, the residual water is not pumped off until the temperature has fallen below a certain level. -
Page 23: Own Recipes
6 GourmetGuide ▸ Select «Yes». ▸ Enter the password using the on-screen keypad and confirm by selecting – The recipe book is now unlocked. Starting a recipe For recipes that do not require preheating, place the food in the cold cooking space. - Page 24 6 GourmetGuide Creating your own recipe ▸ If the appliance is switched off: first press the adjusting knob. ▸ Press the touch button. ▸ Select ▸ Select ▸ To create a new recipe, select – The selection of operating modes including professional baking appears in the dis- play.
- Page 25 6 GourmetGuide Cancelling recipe entry/change ▸ Select in the overview of the set steps. – The following appears in the display: «Do you really want to cancel the recipe entry?» ▸ To cancel the recipe entry, select «Yes». – The menu for your own recipes or, if a recipe from a recipe book was changed, the menu for the recipe book is displayed.
-
Page 26: Vacuisine
6 GourmetGuide Saving a changed recipe ▸ Select ▸ Select storage space, enter the recipe name and confirm by pressing – The changed recipe is now saved. A storage space that is already being used can be overwritten. Recipes that have been amended from recipe books are not saved in the recipe book, but under «Own recipes». - Page 27 6 GourmetGuide ▸ Attach a sealing pad to the bag con- taining the vacuumed food, having first ensured that the bag is clean and dry. ▸ Insert the food probe through the seal- ing pad and the bag, and into the meat.
-
Page 28: Bakeomatic
6 GourmetGuide BakeOmatic BakeOmatic comprises applications for different food groups. The size and shape of the food are recognized and the duration and cooking space climate are adjusted auto- matically. BakeOmatic is suitable for the following foods and dishes: Fresh aperitif nibbles Frozen pizza (F) * Frozen aperitif nibbles (F) * Flan... -
Page 29: Professional Baking
6 GourmetGuide ▸ Select the degree of browning or, for frozen products, the appropriate time indicated on the packaging. – The BakeOmatic settings are displayed. ▸ Set an end time or delayed start, if required. ▸ To start BakeOmatic, select . –... -
Page 30: Soft Roasting
6 GourmetGuide ▸ Select ▸ Select the desired application. – The operating mode settings are displayed. ▸ Set the temperature, duration and, if necessary, an end time or delayed start and con- firm. ▸ To start professional baking, select . The filled water tank must be in position in the water tank compartment. - Page 31 6 GourmetGuide «Soft roasting seared» ▸ Season or marinate the meat. Remove any marinade made with herbs, mustard, etc. from the meat before sear- ing. These ingredients burn easily. ▸ Salt the meat immediately before searing. ▸ Briefly sear the meat all over for no longer than 5 minutes. ▸...
-
Page 32: Regenerateomatic
6 GourmetGuide ▸ If the appliance is switched off, first press the adjusting knob. ▸ Press the touch button. ▸ Select ▸ Select the desired soft roasting method. ▸ Select the desired type of meat. ▸ Select the desired cut. ▸... -
Page 33: Wellness
6 GourmetGuide Degree of moisture With RegenerateOmatic, you can choose between «Regenerate moist» and «Re- generate crispy». Degree of moisture Uses Foods that should not dry out e.g. vegetables, meat, pasta Foods that should be crispy after regeneration e.g. pizza, flans, aperitif nibbles Regeneration time Sensors detect when the food is hot. -
Page 34: Hygiene
6 GourmetGuide Caution hot! Feel the temperature of the heated objects with your hand first before placing them on any other parts of the body. Hot towels Before starting the application: ▸ Wet and wring out the towels. ▸ Open the towels and place in the perforated cooking tray or: ▸... -
Page 35: Easycook
7 EasyCook If the cooking space is already hot, open the appliance door and allow the cooking space to cool down for 3 to 4 minutes before starting the «Keep warm» function. This ensures that the food does not overcook. The longer the food is kept warm, the greater the changes may be to the consist- ency of the food. -
Page 36: Favourites
8 Favourites – Preheating necessary / not necessary – Accessories needed – Level – Possible tips ▸ Select ▸ The operating mode summary is displayed. ▸ To start operation, select . You can change the set values to a limited extent. Favourites Up to 24 operating modes, GourmetGuide and EasyCook applications together with the settings made can be saved as favourites. -
Page 37: Tips And Tricks
9 Tips and tricks Tips and tricks Unsatisfactory cooking result... … when baking and roasting Result Solution ▪ The baking or roast looks good ▸ Next time, set a lower temperature and on the outside but is still doughy lengthen the operating time. or raw on the inside. -
Page 38: General Tips
10 User settings General tips ▪ Several foods can be cooked simultaneously to save energy, e.g. rice or pulses to- gether with vegetables with similar cooking times. ▪ With the appropriate amount of liquid, grains, e.g. rice or millet, and pulses, e.g. len- tils, cook directly in suitable tableware. -
Page 39: Language
10 User settings ▸ Select the desired user setting or submenu. ▸ Adjust the desired user setting and press the adjusting knob to confirm. – Either the user settings main menu or the relevant submenu appears in the display. ▸ To exit a submenu and return to the user settings main menu, select ▸... -
Page 40: Notifications
10 User settings Time format The time can be displayed in the European 24-hour time format or the US 12‑hour format (a.m./p.m.). Time display With the «Show time» setting (factory setting), the time is dimmed between 00:00 and 06:00 (24-hour format) or 12:00 a.m. and 06:00 a.m. (12-hour format). If «Hide time»... -
Page 41: Assistance Functions
10 User settings 10.11 Assistance functions Illumination The «Automatic» setting switches on the cooking space illumination: ▪ 3 minutes before a cooking process ends, e.g. in the case of an automatic pro- gramme or an operating mode with a set duration, ▪... -
Page 42: Childproof Lock
11 Care and maintenance 10.13 Childproof lock The childproof lock is to prevent children accidentally switching on the appliance. When the childproof lock is activated, the appliance can only be operated after first en- tering a code. The code is displayed in reverse order when unlocking. The childproof lock activates 3 minutes after the appliance is switched off. -
Page 43: Cleaning The Exterior
11 Care and maintenance 11.1 Cleaning the exterior ▸ Remove any soiling or excess cleaning solution immediately. ▸ Clean the surfaces with a soft cloth dampened with water and a little washing-up liquid – for metallic surfaces rub in the direction of the original polish lines. ▸... -
Page 44: Cleaning The Door Seal
11 Care and maintenance ▸ Open the appliance door as far as it will go. ▸ Fold the clips 2 on both door hinges 1 forward. 30° ▸ Close the appliance door as far as its at-rest position (about 30°). ▸... -
Page 45: Descaling
11 Care and maintenance Removing the shelf guides ▸ Unscrew the knurled nuts 1 in the front of the shelf guides in an anti-clockwise dir- ection. ▸ Pull the shelf guides 2 to the side of the screws and remove from the front. Reassembling the shelf guides ▸... - Page 46 11 Care and maintenance Descaler durgol swiss steamer Using the wrong descaler can damage the appliance! Only use «durgol swiss steamer» to descale your appliance. The descaler contains highly effective acid. Immediately rinse away any splashes with water. Follow the manufacturer's instructions.
- Page 47 12 Trouble-shooting For safety reasons, once started the descaling process cannot be cancelled. Replacing the rinsing solution ▸ As soon as the corresponding message appears in the display, remove the water tank, pour the rinsing solution away and fill it with 1 l warm water. ▸...
- Page 48 12 Trouble-shooting … just the illumination is not working Possible cause Solution ▪ The halogen light is defective. ▸ Call Customer Services..the cooking time seems unusually long Possible cause Solution ▪ The appliance only has a ▸ Establish a two-phase connection. single-phase connection.
- Page 49 12 Trouble-shooting … the clock is not running correctly Possible cause Solution ▪ Irregular mains frequency ▸ Switch off the mains synchronization. ▪ Internal pulse generator is im- ▸ Call Customer Services. precise when mains synchron- ization is switched off. …...
-
Page 50: Accessories
13 Accessories and spare parts … the following appears in the display Descaling failed. Appliance was not descaled. Possible cause Solution ▪ Used unsuitable descaler. ▸ Descale again using the recommended descaler. ▪ Descaling was not carried out ▸ If the message does not disappear after repeating correctly. -
Page 51: Special Accessories
14 Technical data 13.2 Special accessories For information see: www.vzug.com 13.3 Spare parts Shelf guides left/right Knurled nut Lid for water tank Water tank Sealing pad for Vacuisine with food probe durgol swiss steamer descaler The descaler is also available from specialist retailers. Technical data External dimensions ▸... -
Page 52: Note For Testing Institutes
Own measurements can be im- precise and are not suitable for checking the accuracy of the temperature. 14.3 Product fiche In accordance with EU Regulation No.: 66/2014 Brand – V-ZUG Ltd Type of appliance – Steam cooker Model designation – CSTXSL... -
Page 53: Ecostandby
15 Disposal 14.4 EcoStandby To prevent unnecessary energy consumption, the appliance is equipped with the auto- matic energy-saving «EcoStandby» function. To reduce power consumption to a minimum, select «Hide time» in the user set- tings. Despite EcoStandby, all safety functions remain active. 14.5 Reference to «Open Source»... - Page 54 Index Failed ............. 50 Rinsing phase .......... 47 Accessories ..........11, 50 Starting............ 46 Cleaning ............ 44 Disposal............. 53 Acoustic signals ..........40 Door handle ............41 Activating/deactivating steam supply ..14 Door seal Appliance disposal .......... 53 Cleaning ............ 44 Appliance door Replacing ............
- Page 55 16 Index Language............39 Safety precautions Levels ..............11 Appliance-specific .......... 6 Load capacity ........... 52 Before using for the first time....... 7 Long cooking time........... 48 Correct use ............ 7 Loudness ............40 General ............. 5 Saving energy..........38, 52 Service & Support..........59 Setting the time ..........
- Page 56 Warranty extensions ........59 Water hardness ..........40 Water tank ............41 Automatic ejection........ 41 Cleaning ............ 44 Emptying............ 22 Filling.............. 15 Wellness ............33 Wire shelf............12...
- Page 57 Notes...
- Page 59 V‑ZUG service centre. Technical questions, accessories, warranty extensions V-ZUG is happy to help you with any general administrative or technical queries, to take your orders for accessories and spare parts and to inform you about our progressive service agreements.
- Page 60 You can use the adjusting knob to operate and navigate within the menu; additional submenus can also be called up. The function buttons give you direct access to independent functions such as the timer or switching off the appliance . J23005352-R07 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug info@vzug.com, www.vzug.com...
