Temperatur Control Technology
www.hb-therm.ch
2022-01
Page
Assembly Instructions M8110-EN
Spare part cooling valve 2
– Guide sleeve with seal (O/ID T25931)
– Hydraulic part complete (O/ID T25930)
M8110-EN 2022-01
Purpose
Replacement of cooling valve 2 (M 4)
Precondition
WARNING!
Danger for unauthorized persons!
Conversion work may only be carried out by
specialist staff who have been trained accordingly.
Therefore:
– Keep unauthorized persons away from the work
area.
NOTE!
Knowledge of the Instruction Manual is a
precondition for carrying out conversion work on
the unit.
Procedure
DANGER!
Danger to life caused by electric current!
Touching conductive parts causes a direct danger
to life.
Therefore:
– For all work on the electrical system, for
maintenance, cleaning or repair work,
disconnect from the mains or disconnect all
phases of the external power supply and secure
them against being switched on again. Check
unit is isolated from power supply.
WARNING!
Danger of crushing due to rolling away or
tipping
With an uneven floor or when the castors are not
locked, there is a danger that the unit tips over or
rolls away causing crushing.
Therefore:
– Only install the unit on an even floor.
– Ensure that the castors are locked.
1/4
Advertisement
Table of Contents
Related Manuals for HB-THERM M8110-EN
Summary of Contents for HB-THERM M8110-EN
- Page 1 Temperatur Control Technology www.hb-therm.ch 2022-01 Page Assembly Instructions M8110-EN Spare part cooling valve 2 – Guide sleeve with seal (O/ID T25931) – Hydraulic part complete (O/ID T25930) Purpose Replacement of cooling valve 2 (M 4) Precondition WARNING! Danger for unauthorized persons! Conversion work may only be carried out by specialist staff who have been trained accordingly.
- Page 2 Assembly Instructions M8110-EN Proceed as follows in order to cool down the unit and empty the mould (mould evacuation) Display menu page Functions. Select the function Cooling and activate with the key. Select the function Mould evacuation and activate with the key.
- Page 3 Assembly Instructions M8110-EN Proceed as follows in order to assemble new parts: Assemble the new guide bush with the mounting rod and fix with the Torx screw. NOTICE! Do not remove the mounting rod to re-assemble the guide bush.
- Page 4 Assembly Instructions M8110-EN 7. Proceed as follows in order to check the service function of cooling valve 2 (M 4): Readjust the parameter Positioning KV 2 in menu Service \ Support. (0 valve closed; 295 valve opened)
