Solid State Logic MADI OPTI-COAX Quick Start Manual page 3

Unpacking
IEC Cable
Connecting Your MADI Opti-Coax Unit
1. Connect the supplied IEC power cable to the mains inlet on the rear of the unit.
The POWER indicator on the front of the unit will light when the unit is powered.
NOTE: The cable should bear the approval mark of the country in which it is to be used.
2. Connect the MADI COAXIAL and MADI OPTICAL connections on the front of the unit
to your MADI equipment.
Ensure the OUT and IN ports are connected in the correct orientation.
