C Technologies C-Pen User Manual page 12

Status field
The area on the left is called the status field. This field
displays the time, the current text settings and the battery
indicator. Text settings are described in Settings, p. 30.
Text quality
(see Settings)
Battery power
Using dialogs
C Pen uses a number of graphic elements on the display
to give information. Some of these require interaction
from the user. The graphic elements are:
Dialogs
Dialog Buttons An on-screen button, e.g. OK, CAN-
12
Current time
Text language (see Settings)
A dialog box appears when you need to
make selections or enter information. A
dialog box contains one or more
elements like buttons, list boxes or edit
boxes.
CEL, YES or NO. To select a button
that appears in a dialog, use the
navigation control; turn Nav until the
button you want to select is marked
with inverted colors, then press Nav.
CANCEL will cancel any changes and
close the dialog.
