INSTALLATION MANUAL PROJECTOR ARM B-24
First of all congratulations
for your choice.
We are pleased to showcase
you this universal
projector ceiling
which is easy to install and can
be used for nearly all LCD and
DLP projectors up to 15 Kg.
Before you install the ceiling
bracket, read all instructions
carefully and follow
installation procedures step by
step.
Inside the packaging you
will find the
items:
- 01 ceiling mounting plate
A
STEP 1
G
C
E
A
Fig. 2
H
Fig. 4
Join the mounting plates using the socket head screws (H), in
order to create the spider system (Fig. 6) that will enable you to
fix the bracket to the projector.
NOTE: You will find 4 straight plates and 4 "S" form plates (convex
shape).
- 01 plate for central joint
B
video
bracket,
+
C
the
E
- 01 column 248 mm. long
following
- 08 mounting plates for the
F
spider system - measures:
- 02 socket head screws
G
Take items (A), (E), (C) and
(G) like in fig. 2. Mount
(A), (C) and (E) using the 2
screws (G).
In case you would like not
to use the column, please
follow the instructions
under Step 1/B at page 2.
Fig. 5
D
- 01 central joint
85x23 mm.
(LxW)
6x16 mm.
Fig. 3
STEP 3
First you should mount the straight plates to (B) and afterwards
you can proceed with the "S" form plates.
In order to mount correctly the "S"form plates, the convex part of
the S" should result downwards (see Fig. 5).
- 08 socket head screws
H
5x6 mm.
I
- 04 knurled socket head
screws 6x10 mm.
J
- 04 crowned head screws
3x10 mm. (diameter x length)
- 04 crowned head screws
4x10 mm. (diameter x length)
- 04 crowned head screws
5x10 mm. (diameter x length)
K
- 01 flanged nut M6
- 04 washers
L
STEP 2
Take items (B) and (D)
and join them with two
screws (I), like on Fig.
B 3.
I
D
Fig. 6
