Screenint SI-H XL 300 Installation Manual

Motorized projector lift

Advertisement

Quick Links

Thank you for purchasing the new SI-H XL 300 Projector Lift.
The SI-H XL 300 is supplied with a set of components and accessories that make it suitable for installation for
the majority of standard AV applications, but note must be made of the restrictions that apply to the weight
capability of this unit and not exceeded.
BEFORE INSTALLING THE LIFT, PLEASE READ THE FOLLOWING INSTRUCTIONS CAREFULLY. Please, always
keep these instructions so that anyone can read them when needed.
THE MANUFACTURER DOES NOT TAKE RESPONSIBILITY FOR ANY DAMAGE TO PROPERTY OR PERSONAL
INJURY IF THE PROJECTOR LIFT IS USED OUTSIDE OF RECOMMENDED SPECIFICATIONS OR IN CASE OF
INCORRECT INSTALLATION.
INSTALLATION OF SI-H XL 300 PROJECTOR LIFT HAS TO BE CARRIED OUT FROM QUALIFIED
PERSONNEL ONLY.
Before installing the projector lift, please read the following instructions carefully:
The projector lift must be used INDOORS ONLY.
IT IS FORBIDDEN TO STAY UNDER THE LIFT AND WITHIN A RANGE OF 3 MT. FROM THE
LIFT.
IN CASE OF MAINTENANCE, UNPLUG THE POWER SUPPLY.
Please confirm that your projected image width will fit your screen from your proposed
mounting location prior to installation.
Incorrect use of the lift, including exceeding the maximum lifting weight, will be
dangerous. The manufacturer does not take responsibility for any damage o property or
personal injury if the lift is used outside of recommended specifications.
This product uses a 230V AC Motor. DO NOT attempt to service the motor. Incorrect
servicing could lead to risk of electric shock.
For any repairing, please contact directly the dealer you purchased the unit from.
Check at least once a year that the screws of the steel cables are well tightened and that
the steel cables are in good conditions. In case they have signs of usage or damages,
replace them promptly with the original ones supplied by the manufacturer.
Check every 6 months that screws, wall plugs and brackets are in good conditions and
well tightened.
The manufacturer and his agents do not take responsibility for any damage to property
or personal injury if the winch is installed/used outside of recommended
specifications.
This product uses a 230 V AC motor. DO NOT attempt to carry out repairs to
the motor, there are no user serviceable parts.
Incorrect servicing could lead to risk of electric shock. In the event of a fault, please
contact the dealer /supplier. Warranty is 24 months Return To Base.
The projector lift SI-H XL 300 is
MOTORIZED PROJECTOR LIFT
MOD. SI-H XL 300
INSTALLATION MANUAL
certified.
(version MAY-2021)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SI-H XL 300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Screenint SI-H XL 300

  • Page 1 Thank you for purchasing the new SI-H XL 300 Projector Lift. The SI-H XL 300 is supplied with a set of components and accessories that make it suitable for installation for the majority of standard AV applications, but note must be made of the restrictions that apply to the weight capability of this unit and not exceeded.
  • Page 2 Warranty is officially voided if the lift has been dismantled or it is returned with collision damage or defective due to incorrect installation. Repairs must be carried out by an Approved ScreenInt Certified Engineer. Warranty is officially voided if (all the following cases are including but not limited): defects not due to deficiencies in the material or workmanship;...
  • Page 3 In order to mount the four metal brackets shown on Fig. “B” above on the upper aluminium frame of the SI-H XL 300, please use screws, washers and crowned nuts mentioned on “C, D, E” of the supplied equipment list; put inside the groove of the aluminium frame the crowned nut as shown on Fig. 1A;...
  • Page 4 FIXING THE PROJECTOR TO LIFT Roll down the SI-H XL 300 by pushing ▼ button on the remote control (Fig. 7A), in order to lower the lift till the lower end-stop (SERVICE mode), preset in the factory at 2,5 mt. ca. In case you wish to modify the lower end-stop (SERVICE mode), please refer to instructions at page 4 and 5.
  • Page 5 Fig. 5F Fig. 5D Fig. 5E In order to adjust ROLLING, please tighten or unloose the nuts that act on the tension of the steel cables. (Fig. 6A) Fig. 6A ADJUSTMENT OF THE END STOPS PLEASE READ CAREFULLY The SI-H XL 500 motorized lift is supplied with a remote control that allows to set three positions: 1- CLOSED LIFT: preset by the factory, in closed upper position.
  • Page 6 Close the connection, for at least 1 second, simultaneously between the white-black, white-orange and white wires in order to reach the INTERMEDIATE stop (PROJECTION mode). The SI-H XL 300 projector lift includes a CABLE MANAGEMENT SYSTEM. In order to fit in the power and signal cables of the projector Move the lift in the lower end stop position (SERVICE MODE), and open the small doors, as shown in Fig.
  • Page 7 MOTOR SPEED 12 rpm ROLL UP/DOWN SPEED 17 sec./metre TERMICAL STOP after 4 minutes of operation NET WEIGHT LIFT SI-H XL 300 kg. 71 MAXIMUM LOAD OF THE PROJECTOR kg. 95 DIMENSIONS SI-H XL 300 CLOSED 790x576x890 (WxHxD in mm.) DIMENSIONS SI-H XL 300 OPENED 790x3576x890 (WxHxD in mm.)
