Display; Safety Guidelines; Intended Use; Explanation Of The Figures - BMZ Drive Systems V7 Operating Instructions Manual

2
2.1
There is a risk of danger, if the safety instructions are not observed.
Non-observance of safety information and instructions can lead to an electrical
shock, fire and/or serious injuries.
2.2
The display and control unit is only intended for use with the BMZ E-Bike system. It
serves to display driving and status-relevant information and to control the motor.
2.3
All illustrations are outlines only and details may vary on your E-Bike.
2.4
2.4.1
Sportive Display
The compact Sportive Display is a display and control unit in one. It can be installed
unobtrusively near the handle and is less susceptible to damage in case of a fall.
New-Style Display
The large New-Style display is easy to read and has additional functions. The system
is controlled easily via the control unit near the handle.
2.4.2
The various displays have a similar design. The New-Style display also has a
multifunctional display and a display that shows the ratios of the performance by the
rider and that of the motor.
