  • Page 1 New-Style Display Sportive Display Original user manual...

  • Page 2: Explanation Of Symbols

    The compact sportive display can be installed close to the handle discreetly. In case of a fall, it is less susceptible to damage. New-style display The big new-style display is easy to read and comes with additional functions. The system is easy-to-operate with its new-style remote. Explanation of symbols The various displays have a similar structure.

  • Page 3: Operating Elements

    The display has a micro-USB-port on the rear side. With a right USB cable, you can charge other devices with it, e.g. your cell phone. ATTENTION The charge current is 0.5 ampere. Consider the permissible charge current of your devices. Assembly Installing the new-style display  Prerequisites Engine and batteries are installed.  Tools Allen key AF 2.5...

  • Page 4: Operation

    3Operation Set the new-style display tilted to 45° to the left on the bracket and turn straight. Connect the display to the engine by the intermediate cable. Taking off the new-style display Separate the display from the intermediate cable. Turn the new-style display to 45° left and take it off from the top.
  • Page 5 3Operation Changing the support level  Instructions Press the rocker switch to increase the support level.  Press the rocker switch Down to lower the support level. Enabling the pushing help For Pedelec user  Instructions Press the button pushing help for three seconds.

  • Page 6: Change The Settings

    3Operation Switching over to multi-functional display  Instructions Tap on the touch field Menu. Change the settings 3.7.1 New-style display Overview Following settings can be made: Table 4 Field Value Settings Reset trip Set the run time, calories burned, distance,...
  • Page 8 Am Sportplatz 30 63791 Karlstein Phone no.: 06188 9956-0 Fax: 06188 9956-900 Email: kontakt@bmz-gmbh.de © 2015 BMZ GmbH. Subject to modifications. BMZ assumes no liability for technical or editorial errors. Product Item No. New-style display 27937 identification Item No. Sportive display: 27938 Country of origin: Germany Symbol: [CE, TÜV, etc.]...
