- Page 1 All manuals and user guides at all-guides.com BMZ Drive Systems V7 Operating Instructions...
- Page 2 Phone number for E-Bike dealers: +49 6188 9956-9833 Phone number for technical questions about the drive system: +49 6188 9956-680 Fax number: +49 6188 9956-699 E-Mail: cs.ebike@bmz-group.com Document Operating Instructions BMZ Drive Systems V7 identification Article number: #31329 Version: 1.1 (21 Jun 2017) Subject to change.
-
Page 3: Table Of Contents
All manuals and user guides at all-guides.com Contents Contents Motor Safety guidelines Intended use Explanation of the figure Operation Cycling and advice Maintenance and cleaning Inspection Transport Waste Disposal 1.10 Technical data Display Safety guidelines Intended use Explanation of the figures Description 2.4.1 Variants... - Page 4 All manuals and user guides at all-guides.com Waste Disposal 2.10 Technical data Rechargeable battery Safety guidelines Intended use Explanation of the figures Assembly 3.4.1 Insertion and removal of the rechargeable battery 3.4.2 Locking and unlocking the rechargeable battery latch Commissioning 3.5.1 Check the rechargeable battery before using it for the first time...
-
Page 5: Motor
All manuals and user guides at all-guides.com 1 Motor Motor Safety guidelines WARNING There is a risk of danger, if the safety instructions are not observed. Non-observance of safety information and instructions can lead to an electrical shock, fire and/or serious injuries. ... -
Page 6: Explanation Of The Figure
The E-Bike system is only functional when the display is mounted. Cycling and advice When does the The BMZ E-Bike system provides electromotor support to the cyclist in a Pedal E-Bike drive work? Electric Cycle (Pedelec). The support provided depends on the force applied by the cyclist onto the pedals. -
Page 7: Maintenance And Cleaning
E-Bike. Inspection On reaching a mileage of 15,000 km, the drive belt needs to be replaced by a service centre authorised by BMZ. You can obtain information about your responsible service centre from your bicycle dealer. Transport When transporting a complete E-Bike, please note the transport information pertaining to the rechargeable batteries (see 3.8). -
Page 8: Technical Data
All manuals and user guides at all-guides.com 1 Motor 1.10 Technical data Table 1 Motor Technical data motor Art. No. #23084 Dimensions (mm) 213 x 150 x 128 Weight 3,400 g Rated voltage 36 V DC Type of protection: IP56 Max. -
Page 9: Display
Please keep these instructions for future reference. Intended use The display and control unit is only intended for use with the BMZ E-Bike system. It serves to display driving and status-relevant information and to control the motor. Explanation of the figures All illustrations are outlines only and details may vary on your E-Bike. -
Page 10: Charging Status Display
All manuals and user guides at all-guides.com 2 Display Figure 2 Symbols Display symbols new Pushing mode style (left) and: Sportive (right) Lighting Warning Charging status (2.4.3) Speed Unit (km/h, mph) Support level (2.4.4) Performance ratio cyclist Performance ratio motor 10 Multifunctional display (2.4.5) 2.4.3... -
Page 11: Multifunctional Display
All manuals and user guides at all-guides.com 2 Display 2.4.5 Multifunctional display Table 4 Key functions. In order to… Unit Multifunctional display Time (Time of Day) hh:mm (24 h or 12 h am/pm) Tour dist. (Trip Distance) km | mi Tour kcal (Trip Calories) kcal Tour time (Trip Time) -
Page 12: Remove New-Style Display
All manuals and user guides at all-guides.com 2 Display Allen 2.5 mm Tools Allen 3 mm Intermediate cable Figure 5 18 New-Style Display Mount the New-Style 19 Display bracket display Instructions Mount the control unit within reach on the handlebars. (allen 2.5 mm) Mount the display bracket in the centre of the handlebar (allen 3 mm). -
Page 13: Operation
All manuals and user guides at all-guides.com 2 Display It is only fully functional if the speed sensor and the cables have been mounted NOTE: correctly and the rechargeable battery is adequately charged. Operation 2.7.1 Switching on the E-Bike system Press the LED button on the rechargeable battery. -
Page 14: Switchover The Multifunctional Display
All manuals and user guides at all-guides.com 2 Display 2.7.6 Switchover the multifunctional display Instructions Touch the touch field Menu 2.7.7 Change the settings on the New-Style Display Overview You can make the following settings: Table 5 Range Value Settings New-Style Reset trip Reset all values for driving time, calorie... -
Page 15: Waste Disposal
All manuals and user guides at all-guides.com 2 Display Waste Disposal Motor, display, rechargeable battery, speed sensor, accessories and packaging should be disposed of in an environmentally-compatible manner. Do not dispose of your E- Bike and its components in the household waste system. Only for EU countries In compliance with the European Directive 2012/19/EU electrical devices that are no longer serviceable, and in compliance with the European Directive 2006/66/EG faulty... -
Page 16: Rechargeable Battery
(e.g. paper clips, nails, screws, keys etc.) away from the rechargeable battery. These could bridge the contacts. All warranty claims toward BMZ will become invalid in case of short circuit damage resulting from this. Risk of skin irritation or burns from leaking fluids: if used incorrectly, ... -
Page 17: Intended Use
Explanation of the figures All illustrations are outlines only and serve as examples. The details may vary from your own E-Bike because the BMZ E-Bike system can be combined with a number of different rechargeable battery variants. You can obtain detailed information about the rechargeable battery used in your E-Bike from your cycle manufacturer and your bicycle dealer. -
Page 18: Assembly
Insertion of the rechargeable battery The BMZ E-Bike system can be combined with a number of different rechargeable battery variants. The assembly and removal of the rechargeable battery depends on the rechargeable battery model used. You can obtain detailed information about this from your cycle manufacturer and your bicycle dealer. -
Page 19: Commissioning
All manuals and user guides at all-guides.com 3 Rechargeable battery and unlocking the rechargeable battery from your cycle manufacturer and your bicycle dealer. Commissioning 3.5.1 Check the rechargeable battery before using it for the first time The rechargeable battery is partially charged when delivered. Therefore, test the rechargeable battery before you charge it for the first time or use it with your E-Bike. -
Page 20: Charging Status Display
All manuals and user guides at all-guides.com 3 Rechargeable battery The LED status display of the charger should now be active (see 4.5.3). Rechargeable battery not on the E-Bike Connect the charger connector to the charging socket of the ... -
Page 21: Operation
All manuals and user guides at all-guides.com 3 Rechargeable battery corresponds to about 20% of the capacity. The flashing LED shows the charging of the next 20 %. During the charging process, the charging status display is presented as follows: Table 8 LEDs Charging status... -
Page 22: Transport
All manuals and user guides at all-guides.com 3 Rechargeable battery The service life of the rechargeable battery can be extended if it is maintained and, in Service life particular, stored in the right conditions. Temperature: 18-23°C Air humidity: 0-80 % ... -
Page 23: Charger
(e.g. rain, snow etc.). Risk of fire and explosion if the wrong batteries are charged. Only use the charger supplied for the rechargeable battery in your BMZ E-Bike system. The rechargeable battery voltage and charging voltage of the charger must match. -
Page 24: Intended Use
All illustrations are outlines only and serve as examples. The details may vary from your own E-Bike because the BMZ E-Bike system can be combined with a number of different chargers. You can obtain detailed information about the charger supplied with your E-Bike from your cycle manufacturer and your bicycle dealer. -
Page 25: Charging Process
All manuals and user guides at all-guides.com 4 Charger Insert the charging connector of the charger into a matching charging slot on the rechargeable battery. Charging begins. Rechargeable battery Charging the rechargeable battery on the E-Bike on the E-Bike See Figure 9, page 19. -
Page 26: Maintenance And Cleaning
All manuals and user guides at all-guides.com 4 Charger 4-A charger trickle charging Error green and red LED flash Maintenance and cleaning If the charger fails, please contact an authorised dealer. Use a soft dry cloth to clean the charger. Do not use water or other cleaning fluids! Waste Disposal The charger, accessories and packaging should be disposed of in an environmentally- compatible manner. -
Page 27: Other Lists/Indices
All manuals and user guides at all-guides.com 5 Other lists/indices Other lists/indices List of figures Figure 1 Motor with design cover and mounted cranks ..........6 Figure 2 Display symbols new style (left) and: Sportive (right) ........10 Figure 3 Control elements.................... - Page 28 All manuals and user guides at all-guides.com © 2017 BMZ GmbH. Subject to change. BMZ assumes no liability for technical or editorial errors. BMZ France S.A.R.L. BMZ GmbH Am Sportplatz 28 45 boulevard Vincent Auriol 63791 Karlstein am Main 75013 Paris...
