KanDao QooCam 8K Manual

Hide thumbs Also See for QooCam 8K:
Table of Contents

Advertisement

Quick Links

Download this manual
Overview

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QooCam 8K and is the answer not in the manual?

Questions and answers

Related Manuals for KanDao QooCam 8K

Summary of Contents for KanDao QooCam 8K

  • Page 1 Overview...

  • Page 2: Button Features

    8. Touch screen 9. 1/4 Threaded hole Button features Q Button When QooCam 8K is idle while turned on, press the button to quickly switch between custom settings. Shutter Button When QooCam 8K is turned on, press the shutter button to take photos or start/stop recording.
  • Page 3 Touchscreen General Setting: Date/Time The camera date and time information is recorded on the file along with the image, so be sure to set it correctly before use. Select language, then click „✔ “ Set current date, then click „✔“...
  • Page 4 Set current time, then click „✔ “ Download QooCam APP Make sure the picture is horizontal. Place the camera on a flat surface and click [Ready] to start IMU calibration. Download QooCam APP, then click „✔“save settings and exit...
  • Page 5 Operating the Touchscreen Swipe down to enter the [Camera settings] menu Include Custom Template Management, Wi-Fi Switch, Volume/Brightness Adjustments, and more. Swipe right to enter [Playback] Swipe left or right to scroll through photos and videos. Preview page will display shooting parameters. You can delete files or view photos/videos by category.
  • Page 6 1. Memory capacity remaining 2. Current shooting mode 3. Wi-fi connection 4. Remaining battery 5. Camera parameters of the current shooting mode...
  • Page 7 Camera settings Swipe down to enter the [Camera Settings] menu 1. Custom template management Click again to save the current shooting parameters as a custom mode. You can save up to 4 custom modes. Short press the Q button to switch between the custom modes.

  • Page 8: More Settings

    More Settings 1. Sports mode: Motion blur reduction. 2. Color depth: 8bit by default, 10bit is also provided. 3. Wireless connection: View device name and password, set Wi-fi band, reset connection and SSID and wi-fi password. 4. Anti-flicker: Prevent the flickering of lights by selecting the frequency according to the local regulations.
  • Page 9 6. Auto power off time: Set the time before camera automatically turns off. 7. USB drive mode: When the camera is connected via. USB cable, depending on the platform (Android/ Ios/ PC); iOS by default 8. Preffered Memory: Set the storage location of the current photo/video 9.
  • Page 10 Then, swipe up to set the shooting parameters in the current shooting mode. Then, press the shutter button to start shooting. When recording, the blue indicator light flashes slowly/ the touchscreen displays the current recording time. When taking a picture, the blue indicator flashes During shooting, touchscreen and Q button are not supported.
  • Page 11 Shooting mode Parameter setting range Video Resolution / frame rate, exposure mode, white balance Photo Exposure mode (auto EV, manual ISO/shutter speed, sports EV), white balance, countdown, file format (JPG, JPG+DNG) Time-lapse (photo) Exposure mode (auto EV, manual ISO/shutter speed, sports EV), white balance, countdown, file format (JPG, JPG+DNG) DNG-8 Exposure mode (auto EV, manual ISO/shutter...
  • Page 12 1. Photo 2. Video 3. Time-lapse-photo 4. DNG 8 5. Customized mode Playback Swipe right to enter [Playback], click 360 to view photos/videos by category.
  • Page 13 1. View photo/ Video/ All 2. Multiple choice 3. Shooting mode...
  • Page 14 4. Enter the playback list 5. Click to view the panorama 6. Delete Connect QooCam APP Method 1: Wi-fi connection In the touchscreen drop-down list, click the wi-fi button in the lower left corner to turn on wi-fi. The button will be highlighted.
  • Page 15 Method 3: Wired connection Connect the camera to the phone using the USB cable provided, the phone will automatically jump to the QooCam APP preview page. QooCam APP Shooting and playback Click the settings button to set the shooting parameters in the current shooting mode. Slide left and right to switch shooting mode (Photo, video, time-lapse) Camera settings includes stabilization, firmware...
  • Page 16 Go to the camera album and click on the thumbnail to playback (preview resolution). Download the clip from the camera album to the APP album for full resolution playback. Edit: QooCam APP Enter the APP album list, select a photo/video and start editing Photo editing: Add filters, change photo to panoramic video, etc.
  • Page 17 Export flat video, which is edited with key points/speed/filters/clip. Export 360 panoramic video Note: The panoramic video is unedited video. The features of key frames, filters, shifting, etc. will not work. SmartClip Go shooting: Shoot footage with the camera, and then download and export edited footage automatically.
  • Page 18 Note: in this process, please make sure the camera is turned on and connected to the phone.
  • Page 19 It’s recommended to turn off the camera during charging Supports shooting during charging Expand storage QooCam 8K has built-in 64 Gb highspeed storage, it also supports external SD card up to 256 Gb (U3 Card is recommended). Note: You can format SD card through the touchscreen [Camera Menu –...

  • Page 20: Status Led Description

    Status LED Description There are two statues LEDs on QooCam 8K. Instructions LED status QooCam 8K is turning on Solid red QooCam 8K is turned on Solid blue When QooCam 8K is turned off, solid red Charging When QooCam 8K is turned on, solid pink...
  • Page 21 Camera Firmware Update Using QooCam APP There will be an update reminder in App when cell phone’s connected via Wi-fi or cable to the camera. Reminder will find latest FW updates. Please follow the steps below to update. Note: Ensure the battery level of the cam is over 30 % when updating Do not operate the camera during the upgrading process.

  • Page 22: Camera Specifications

    Camera specifications Basic specifications Lens F2.0，FOV：200° Sensor 1/1.7” CMOS,20MP Video resolution 7680*3840@30fps 8/10bit 3840*1920@120fps 8/10bit Photo resolution 7680*3840，12bitRAW， Video format Photo format JPG、DNG Audio format Video Encode H.264，H.265 Max. Bitrate (video output) 200Mbps 6-axis IMU Touchscreen 2.4-inch colorful touch screen Photo/video recording Still image, Timed photos, DNG 8, Photo...

  • Page 23: Specifications

    Specifications Design Color Black Weight 245 g Dimension 145 mm * 57 mm * 33 mm Storage and connection Wi-fi 2.4G/5G External interface USB-C Storage Built-in EMMC64GB External SD Card Micro SD card (max.256 GB), suggested U3 Microphone Built-in Microphone Line-in 3.5mm Battery...
  • Page 24 3. If you use an external power connection, please follow all safety guidelines or third-party powered devices. 4. The QooCam 8K camera lens is made of glass. If the lens is damaged, please be careful to avoid scratching by broken glass. Keep it away from children.
