KanDao Meeting S User Manual

All-in-one conference camera
Hide thumbs Also See for Meeting S:
Table of Contents

Advertisement

Quick Links

Download this manual
S
User Guide / 说明书 / 說明書 / 取扱説明書

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Meeting S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KanDao Meeting S

Summary of Contents for KanDao Meeting S

  • Page 1 User Guide / 说明书 / 說明書 / 取扱説明書...

  • Page 2: Product Profile

    Product Profile Packing List Kandao Meeting S REMOTE STORAGE BAG CONTROL ��W QUICK GUIDE WARRANTY CARD ADAPTER POWER CABLE USB CABLE (�m) (�.�m)

  • Page 3: Names Of Parts

    Names of Parts Lens Buttons Buttons Indicator Light Input/Output Port Input/Output Port Input/Output Port Input/Output Port...

  • Page 4: Buttons Description

    Buttons Description Power Button Long press for �s to turn the device on and off, short press to enter sleep mode, and another short press to wake up. Volume Buttons Adjust the volume of speakers. HDMI ����P ���p Long press “VOL+” and “VOL-” for �s to switch HDMI output resolution (����p/���p).

  • Page 5: Indicator Light Description

    Indicator Light Description Blinking Green Starting or updating firmware Solid Green Ready to use Solid Blue Camera working Solid Red Microphone on mute...
  • Page 6 Input/Output Ports Description USB-C Power Port For power supply HDMI OUT for TV/displayer connection Ethernet Port Wired Network Connection Micro SD Card Slot Support Micro SD Card in FAT�� format (Maximum ���GB) USB-A Port For mouse/keyboard connection USB-C Audio/Video OUT Port Enable the webcam, microphone, and speaker after connecting the PC...

  • Page 7: Remote Control Description

    �. If the remote control doesn't work and cannot be reconnected, you can connect an external mouse to Kandao Meeting S. Then, go to “Settings” > ” Bluetooth” >” Currently Connected” > Select “Kandao Meeting” > Click “Disconnected” . After that, you can reconnect the remote control.
  • Page 8 Standalone Mode Introduction Preparing �. Use the power cable to connect the USB-C power port and the power adapter. �. Use HDMI cable to connect the TV/displayer with Kandao Meeting S. (HDMI cable is not provided.) Power on Long press the power button to turn on your Kandao Meeting S.

  • Page 9: Pairing Remote Control

    Network Connection Wired network connection： Connect the network cable to the Ethernet port of Kandao Meeting S, and then configure the wired network information in "System initial boot" or "Settings", including DHCP, static IP, network agent, etc. Wireless network connection：...

  • Page 10: Recording A Meeting

    �. Go to the "Settings" menu > Select "Screen Mirroring" > Turn the toggle on. �. Make sure Kandao Meeting S and your Mac or Windows PCs are on the same network. �. Enter the IP address to the browser and enter the meeting link in the webpage.

  • Page 11: Screen Mirroring

    �. Go to the "Settings" menu > Select "Screen Mirroring" > Turn the toggle on. �. Make sure Kandao Meeting S and your IOS devices are on the same network. �. Tap the AirPlay on your Mac / iPad / iPhone and select Kandao Meeting S from the device list.

  • Page 12: Camera Settings

    Camera Settings Go to "Settings" > "Camera Settings" menu in Kandao Meeting S, you can adjust the EV, Video Inversion, Video Flip, and Tracking Sensitivity. �. EV: Adjust the exposure value to adapt to different brightness environment. Press the "Setting"...

  • Page 13: System Updates

    System Updates After being connected to an available network, Kandao Meeting S will pop up an update notification if there is a new firmware. Or enter "System Update" on the setting page to update the firmware. Settings Menu �. Storage: View storage space size and stored files.
  • Page 14 USB Mode Introduction Preparing �. Use the power cable to connect the USB-C power port on Kandao Meeting S and the power adapter. �. Use the USB cable to connect a computer to the other USB-C output port. Note Both the power port and audio/video port are USB-C ports. If you insert the USB C cable into the wrong port, it may cause Kandao Meeting S to not boot or work properly.
  • Page 15 ❶ Enter a video conferencing software （ DingTalk, Skype, ZOOM, Google Meet, Teams and so on) and start an online meeting. ❷ Choose “Kandao Meeting S” as the microphone/speaker/camera device in the conferencing software. Then, an indicator light will turn on in blue and Kandao Meeting S is ready to operate. Note �.
  • Page 16 Meeting Mode Introductions Smart-tracking Mode Ultra-Wide Mode： Cover ���° FOV. Single-Person Mode： Display one attendee, while highlighting the active speaker. Two-Attendee Mode： Display two attendees in two frames, while highlighting the active speaker. Multi-Attendee Mode： Display five attendees, the active speaker will be highlighted and displayed in the main frame.

  • Page 17: Screen Lock Mode

    Screen Lock Mode You can adjust the angle of the view and zoom by the remote control. How to use When in a video conference, short press the "Lock" button of the remote control, and a "Lock" icon will appear in the bottom left and a blue selection border will appear on the screen.
  • Page 18 Tech Specifications Specification Size Outer diameter of main device: ��.� mm; Height: ���.� mm; Remote controller Height: ��� mm; Width: �� mm; Thickness: �� mm Computer System Windows� or higher, MacOS ��.� or higher Requirements Software Compatibility Zoom, Tencent conference, GotoMeeting, Skype, Teams, Bluejeans, Ding Talk, Slack, ViLiN-HD video conference, Polycom, Starleaf, Google Meet, HUAWEI CLOUD Meeting, WoCloud Conference, Cisco WebEx,...
  • Page 19 Specification WIFI �G band �+�.�G Support STA Mode Bluetooth BT�.� System Memory ��G Micro SD Card Support Micro SD Card in FAT�� format (Maximum ���GB) Adapter INPUT: AC���-���V ��/��Hz �.��A Max OUTPUT: DC ��V �.�A Machine Weight ���.�g...

  • Page 20: Product Security

    ❷ When using external power supply connection, please observe all safety rules of third-party power supply equipment. ❸ The lens of Kandao Meeting S is made of glass. If the lens is damaged, be sure to handle it carefully to avoid being scratched by the broken lens/glass.
  • Page 21 封底二 Product Name: Kandao Meeting S Conferencing Camera Model: MT���� Manufacturer: KanDao Technology Co.,Ltd. Address: ��� Sino-Steel building, Maqueling Industrial District, Maling Area, Yuehai Street, Nanshan, Shenzhen 产品名称： Kandao Meeting S视频会议机 型号： MT���� 制造商： 深圳看到科技有限公司 地址： 深圳市南山区粤海街道麻岭社区麻雀岭工业区中钢大厦��� 產品名稱： Kandao Meeting S視頻會議機...
