Model No. WEEMSY87010
Serial No.
Write the serial number in the
space above for future reference.
Serial Number Decal (Under Seat)
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts,
please call:
08457 089 009
Or write:
ICON Health & Fitness Ltd.
Unit 4
Revie Road Industrial Estate
Revie Road
Beeston
Leeds, LS11 8JG
UK
email: csuk@iconeurope.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
All manuals and user guides at all-guides.com
Class HC Fitness Product
USER'S MANUAL
w
Visit our website at
www.weiderfitness.com
Advertisement
Table of Contents
Related Manuals for Weider 8507
Summary of Contents for Weider 8507
- Page 1 All manuals and user guides at all-guides.com Model No. WEEMSY87010 Serial No. USER'S MANUAL Write the serial number in the space above for future reference. Serial Number Decal (Under Seat) QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction.
-
Page 2: Table Of Contents
All manuals and user guides at all-guides.com TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............2 BEFORE YOU BEGIN . -
Page 3: Before You Begin
WEEMSY87010. The serial number can be size and strength, or improve your cardiovascular sys- found on a decal attached to the WEIDER 8507 (see tem, the WEIDER 8507 will help you to achieve the the front cover of this manual). -
Page 4: Assembly
All manuals and user guides at all-guides.com ASSEMBLY Assembly requires two people. Due to the size • Tighten all parts as you attach them, unless and weight of the training system, assemble it in the instructed to do otherwise. location where it will be used. THE FOLLOWING TOOLS (NOT INCLUDED) ARE REQUIRED FOR ASSEMBLY: •... - Page 5 All manuals and user guides at all-guides.com 3. Slide six Weights (25) onto the Weight Guides (72). Be sure that all of the Weights are turned so the pin grooves are on the indicated side. Pin Grooves 4. Press the 1 1/4” Square Inner Cap (57) into the Front Upright (42).
- Page 6 All manuals and user guides at all-guides.com 5. Press the Weight Tube Bumper (79) into the end of the Weight Tube (80). Slide the Top Weight (77) onto the Weight Tube. Be sure that the pins on the Weight Tube are resting in the pin grooves under the Top Weight.
- Page 7 All manuals and user guides at all-guides.com 8. Attach the upper ends of the Weight Guides (72) to the Top Frame (67) with the 5/16” x 6” Bolt (74), two 1/2” x 3/4” Spacers (73), and a 5/16” Nylon Locknut (3).
- Page 8 All manuals and user guides at all-guides.com 11. Press a 1 3/4” Square Inner Cap (44) into each end of an Arm (46). Apply lubricant to the lower axles on the Arm Frame (52). Slide an Arm (46) onto one of the axles. Hold two 1”...
- Page 9 All manuals and user guides at all-guides.com 14. Attach a Large “U” Bracket (56) to one of the Arms (46) with a 3/8” x 2 3/4” Bolt (70), 3/8” Washer (9), and 3/8” Nylon Locknut (21). Be sure that the Swivel Bracket (58) is on the inside as shown.
- Page 10 All manuals and user guides at all-guides.com 16. Remove the 3/8” x 1 3/4” Bolt (48), 3/8” Nylon Jam Nut (5), and 3 1/2” Pulley (15) from the indicated bracket on the Top Frame (67). Insert the end of the Long Cable (66) through the bracket and down Hole through the indicated hole.
- Page 11 All manuals and user guides at all-guides.com 19. Note: The 4 1/2” Pulley (81) shown in this step is pre-attached to the Adjustment “U” Bracket (75). Remove the 3/8” x 1 3/4” Bolt (48), 3/8” Nylon Lock Nut (21), and the 4 1/2” Pulley (81) from the Adjustment “U”...
- Page 12 All manuals and user guides at all-guides.com 21. Attach the 5/16” x 3” Bolt (17), two 5/16” Washers (8), and a 5/16” Nylon Jam Nut (2) to the indicated hole in the Top Frame (67). Slide the end of the Long Cable (66) onto the 5/16” x 3”...
- Page 13 All manuals and user guides at all-guides.com 23. Attach the 5/16” x 3 1/2” Bolt (87), two 5/16” Washers (8), the 1” Metal Spacer (22), and a 5/16” Nylon Locknut (3) to the Front Upright as shown. Wrap the Short Cable (23) around a 3 1/2” Pulley (15).
- Page 14 All manuals and user guides at all-guides.com 26. Press a 1 1/2” Square Inner Cap (32) into the Leg Lever (29). Attach the 5/16” x 2” Eyebolt (62) to the Leg Lever (29) with a 5/16” Washer (8) and a 5/16” Nylon Locknut (3).
- Page 15 All manuals and user guides at all-guides.com 29. Slide a Handgrip (12) onto each end of the Lat Bar (85). 30. Make sure that all parts are properly tightened. The use of all remaining parts will be explained in ADJUST- MENT, beginning on page 16 of this manual.
-
Page 16: Adjustment
All manuals and user guides at all-guides.com ADJUSTMENT The instructions below describe how each part of the training system can be adjusted. IMPORTANT: When attaching the lat bar or nylon strap, make sure that the attachments are in the correct starting position for the exercise to be performed. - Page 17 All manuals and user guides at all-guides.com ATTACHING AND REMOVING THE SEAT Set the bracket on the Seat Frame (36) on the indicated pin on the Front Upright (42). Attach the Seat Frame to the Front Upright with the 5/16” x 2 3/4” Carriage Bolt (14) and Seat Knob (40).
- Page 18 All manuals and user guides at all-guides.com ATTACHING THE LAT BAR OR NYLON STRAP TO THE LOW PULLEY STATION Attach the Lat Bar (85) to the Short Cable (23) with a Cable Clip (83). For some exercises, the Chain (84) should be attached between the Lat Bar and the Short Cable with two Cable Clips.
-
Page 19: Trouble-Shooting And Maintenance
All manuals and user guides at all-guides.com TROUBLE-SHOOTING AND MAINTENANCE Inspect and tighten all parts each time you use the training system. Replace any worn parts immediately. The training system can be cleaned using a damp cloth and mild non-abrasive detergent. Do not use solvents. TIGHTENING THE CABLES Adjustment Screw... -
Page 20: Cable Diagrams
CABLE DIAGRAMS All manuals and user guides at all-guides.com The cable diagrams below show the proper routing of the Short Cable (23) and the Long Cable (66). Use the diagrams to make sure that the two cables are assembled correctly. The numbers show the routing of each cable. Long Cable (66) Short Cable (23) Top Frame... - Page 21 All manuals and user guides at all-guides.com NOTES...
-
Page 22: Part List
PART LIST—Model No. WEEMSY87010 All manuals and user guides at all-guides.com R0901A Key No. Qty. Description Key No. Qty. Description 5/16” x 2 1/2” Carriage Bolt 5/16” Nylon Jam Nut 7” Handle 5/16” Nylon Locknut 3/8” x 1 3/4” Bolt Base 1”... -
Page 23: Exploded Drawing
EXPLODED DRAWING—Model No. WEEMSY87010 All manuals and user guides at all-guides.com R0901A 68 81 27 67... - Page 24 All manuals and user guides at all-guides.com 1/4" Nylon Locknut (7) 1/4" x 1/2" Screw (31) 1/4" Nylon Jam Nut (86) 1/4" x 3/4" Screw (18) 5/16" Nylon Jam Nut (2) 1/4" x 2 1/2" Screw (43) 5/16" Nylon Locknut (3) 3/8"...
- Page 25 All manuals and user guides at all-guides.com 5/16" x 2 1/2" Carriage Bolt (1) 1/2" x 3/8" Spacer (51) 5/16" x 2 3/4" Carriage Bolt (14) 1/2" x 1/2" Spacer (65) 5/16" x 2 3/4" Bolt (11) 1/2" x 3/4" Spacer (73) 3/8"...
- Page 26 All manuals and user guides at all-guides.com 3/4" Round Inner Cap (34) 1" Round Inner Cap (49) 1" Round Cover Cap (55) 5/16" x 2" Eyebolt (62) 1 1/4" Square Inner Cap (57) 1 1/2" Square Inner Cap (32) 1 3/4" Square Inner Cap (44) 2"...
-
Page 27: Ordering Replacement Parts
3. The SERIAL NUMBER of the product (see the front cover of this manual). 4. The KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST on page 22 of this manual). WEIDER is a registered trademark of ICON Health & Fitness, Inc. Part No. 175452 R0901A...
